Disks
|
||
Disk Configuration | ||
Sun Storage J4200, RoHS:YL Array | Up to twelve disk drives as follows:
|
|
Capacity
|
||
Supported drives/system per tray capacity:raw, unformatted | ||
73GB SAS Disk drives | 12 × 73GB = 876GB | |
146GB SAS Disk drives | 12 × 146GB = 1.75TB | |
300GB SAS Disk drives | 12 × 300GB = 3.6TB | |
400GB SAS Disk drives | 12 × 400GB = 4.8TB | |
250GB SATA Disk drives | 12 × 250GB = 3.0TB | |
500GB SATA Disk drives | 12 × 500GB = 6.0TB | |
750GB SATA Disk drives | 12 × 750GB = 9TB | |
1TB SATA Disk Drives | 12 × 1TB = 12.0TB | |
2TB SATA Disk Drives | 12 × 2TB = 24.0TB | |
Drive Specifications |
Form factor: 3.5 in., low-profile Interface: Dual-ported SAS |
|
Interfaces | ||
Host interfaces/link speeds | Two 3 Gb/s “x4 wide” SAS host interfaces | |
Other interfaces | SAS/SATA drive support | |
Serial | Up to two RS-232 Serial Mgt ports | |
Environment
|
||
Heat Dissipation | 344.47 BTU/hr. | |
AC Power | 500 watts (+5V @ 19A/+12V @ 35A) | |
Input Voltage | 88 -264VAC | |
Power Consumption | 106.54 VA, 100.4 W | |
Operating Temperature | 0° C to 35° C (32° F to 95° F) | |
Operating Relative Humidity | 20% to 95% relative humidity, noncondensing | |
Operating Altitude | -50 to 10,000 feet | |
Shock | 31 Gs, 2.6msec, half-sine wave pulse | |
Vibration | 0.25Gs @ 3 Hz to 200Hz | |
Dimensions and Weights
|
||
Height | 87.4 mm (3.44 in) | |
Width | 445 mm (17.52 in) | |
Depth | 619.39 mm (24.39 in) including bezel and SAS connector 610.4 mm (24.03 in) including bezel and power supply handles |
|
Weight (maximum) | 28 kg (61.73 lb) with 12 disks |
Array Controller | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
XTA-4200-IOM | 375-3658 | SAS Expansion Tray I/O Module (IOM), RoHS:Y | ||
n/a | 371-4058 | SAS Interface Module Filler Panel, RoHS:Y | ||
n/a | 375-3575 | SAS Expansion Tray I/O Module (IOM) |
Cables | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
XTA-0.5M-SAS | 530-3886 | 4X Mini SAS Cable, SFF-8088 to SFF-8088, 0.5M, RoHS:YL | ||
XTA-1.0M-SAS | 530-3882 | 4X Mini SAS Cable, SFF-8088 to SFF-8088, 1M, RoHS:YL | ||
XTA-2.0M-SAS | 530-3883 | 4X Mini SAS Cable, SFF-8088 to SFF-8088, 2M, RoHS:Y | ||
XTA-6.0M-SAS | 530-3887 | 4X Mini SAS Cable, 6M, RoHS:YL | ||
n/a | 530-3884 | 4X Mini SAS Cable, 3M, RoHS:YL |
Disks | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
XTA-SS1NJ-300G15K | 540-7987 | 300GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:YL | ||
|
|
|||
|
|
|||
XTA-SS1NJ-450G15K | 540-7850 | 450GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y | ||
|
|
|||
|
|
|||
XTA-SS1NJ-600G15K | 542-0186 | 600GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y | ||
|
|
|||
|
|
|||
XTA-ST1NJ-1T7K | 540-7910 | 1TB – 7.2K RPM SATA Disk Assembly with brackets and 1 of the following disks, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
XTA6ST1NJ-500G7K | 6× 500GB – 7200 RPM SATA Disk Option, RoHS:YL | |||
540-7605 | 500GB – 7200 RPM SATA Disk Assembly with brackets and 1 of the following disks:, RoHS:YL | |||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
XTA-JBOD-6AMS | 540-7651 | Disk Drive Filler Panel/Air Management Sled, RoHS:Y | ||
XTA-SS1NJ-146G15K | 540-7986 | 146GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:YL | ||
|
|
|||
|
|
|||
XTA-SS1NJ-73G15K | 540-7606 | 73GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:YL | ||
|
|
|||
|
|
|||
|
|
|||
XTA-ST1NJ-250G7K | 540-7604 | 250GB – 7200 RPM Disk Assembly with 1 bracket and 1 disk:, RoHS:YL | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
XTA-ST1NJ-2T7K | 542-0185 | 2TB – 7200 RPM SATA Disk Assembly with brackets and 1 of the following disks, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
XTA-ST1NJ-500G7K | 540-7605 | 500GB – 7200 RPM SATA Disk Assembly with brackets and 1 of the following disks:, RoHS:YL | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
XTA-ST1NJ-750G7K | 540-7556 | 750GB – 7200 RPM SATA Disk Assembly with brackets and 1 of the following disks:, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
XTA6SS1NJ-146G15K | 6× 146GB – 15000 RPM SAS Disk Option, RoHS:YL | |||
540-7607 | 146GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:YL | |||
|
|
|||
|
|
|||
|
|
|||
XTA6SS1NJ-300G15K | 6× 300GB – 15000 RPM SAS Option, RoHS:YL | |||
540-7987 | 300GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:YL | |||
|
|
|||
|
|
|||
XTA6SS1NJ-600G15K | 6 x 600Gb – 15000 RPM SAS Option, RoHS:Y | |||
542-0186 | 600GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y | |||
|
|
|||
|
|
|||
XTA6SS1NJ-73G15K | 6× 73GB – 15000 RPM SAS Option, RoHS:YL | |||
540-7606 | 73GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:YL | |||
|
|
|||
|
|
|||
|
|
|||
XTA6ST1NJ-1T7K | 6× 1TB – 7200 RPM SATA Disk Option, RoHS:YL | |||
540-7910 | 1TB – 7.2K RPM SATA Disk Assembly with brackets and 1 of the following disks, RoHS:Y | |||
|
|
|||
|
|
|||
|
|
|||
XTA6ST1NJ-250G7K | 6× 250GB – 7200 RPM SATA Disk Option, RoHS:Y | |||
540-7604 | 250GB – 7200 RPM Disk Assembly with 1 bracket and 1 disk:, RoHS:YL | |||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
XTA6ST1NJ-2T7K | 6× 2TB – 7200 RPM SATA Disk Option, RoHS:Y | |||
542-0185 | 2TB – 7200 RPM SATA Disk Assembly with brackets and 1 of the following disks, RoHS:Y | |||
|
|
|||
|
|
|||
|
|
|||
XTA6ST1NJ-750G7K | 6× 750GB – 7200 RPM SATA Disk Option, RoHS:YL | |||
540-7556 | 750GB – 7200 RPM SATA Disk Assembly with brackets and 1 of the following disks:, RoHS:Y | |||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
n/a | 540-7560 | 300GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:YL | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
n/a | 540-7594 | 1TB – 7.2K RPM SATA Disk Assembly with brackets and 1 of the following disks, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
n/a | 542-0396 | 300GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y | ||
|
|
|||
|
|
|||
542-0397 | 1TB – 7.2K RPM SATA Disk Assembly with brackets and 1 of the following disks, RoHS:Y | |||
|
|
|||
|
|
|||
|
|
Fan | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
XTA-4200-2UFAN-KIT | 371-3992 | Fan Tray Assembly, RoHS:Y |
Power | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
XTA-4200-2UAC-KIT | 300-2166 | 500W AC Input Power Supply, RoHS:Y |
Rack | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
XTA-4200-2URK-19U | 594-5318 | Sun Storage J4200 2U Universal Rack Mount Kit |
