Oracle Sun ZFS Storage ZS3-BA Server

REQUEST A PRICE QUOTE:

Brand:	Oracle / Sun Microsystems
Condition:	Refurbished and new (limited availability)
Availability:	Contact
Shipping Area:	Worldwide to most countries
Shipping Method:	Fedex (most orders), UPS, DHL, Freight Courier
Price:	Please use the quote form above for quick pricing
Payment:	Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
Guarantee:	All items are tested by Oracle trained technicians & backed by a 100% warranty
Questions?	Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements

Specs and Information:

Processor

Number

4 8-Core

Architecture

Intel Xeon E7 Processor Series

CPUs

Intel 2.0GHz 8-Core Xeon E7-4820, 105W

Cache memory

256KB unified (data and instruction) Level 2 cache
18MB or 30MB shared inclusive Level 3 cache

Main Memory

Capacities

DIMM slots: 64 DIMM slots total, only 32 DIMM slots being used, DIMMs slots populated: 0,2,4,6
DIMM type: Registered DDR3-1333/PC3-10600 ECC DIMMs
DIMM size: 16GB
Maximum capacity: 512GB

Standard Integrated Interfaces

Network

Four Integrated 10/100/1000 Base-T Gigabit Ethernet

Network Management

One 10/100 Base-T Ethernet management port

Serial Management

One TIA/EIA-232-F asynchronous RJ45 serial port

USB

Front: 2 USB 2.0 Ports
Rear: 2 USB 2.0 Ports
Internal: 1 USB 2.0 Port

PCI Express

10 PCI Express 2.0 Slots

2 slots (3 and 5) are either x8 or x16 electrical interface (x16 connector)
6 slots are x8 PCI-E slots
2 slots are x4 PCI-E slots

Note: Slots 3 and 5 operate as x16 interfaces only when an x16 capable card is
installed and the adjacent slot (4 or 6) is unpopulated.

Video

One Rear and One Front HD15 VGA port

Internal Mass Storage

Disks

Two boot disks in the Sun Server X2-4 & 24 hot-swappable disks in the Oracle DE2-24C

Drive Type	Density	Speed	Form Factor	Supported In
SAS	4TB	7,200 RPM	3.5″	DE2-24C
SAS	900GB	10,000 RPM	2.5″	Sun Server X2-4 (boot disk)
SAS SSD (Solid State Drive)	73GB	NA	3.5″	DE2-24C (Logzilla)
SAS SSD (Solid State Drive)	1.6TB	NA	2.5″	Sun Server X2-4 (Readzilla)

Power Supplies

Dual redundant, hot swappable power supplies
2000W Capacity (From 200 Volts to 240 Volts)

Environment

AC power

100-127 VAC/200-240 VAC (50-60Hz)

Maximum Input Current

12A @ 100VAC / 12A @ 200VAC

Maximum Power Consumption

1800W

Maximum Heat Output

6143 BTU/hr

Temperature

Single, non-rack system:
Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -40° C to 68° C (-40° F to 154° F)

Humidity

Single, non-rack system:
Operating: 10% to 90% relative humidity noncondensing
Nonoperating: up to 93% relative humidity noncondensing

Altitude

Single, non-rack system:
Operating: Up to 3048 m (10,000 ft.), maximum operating temperature is derated by 1° C for every 300 m (985 ft) above 900 m (2,952 ft).
Nonoperating: Up to 12,000 m (39,370 ft.)

Acoustic Noise Emissions

LwAd (1B= 10dB) at max ambient: 8.9 B (idle and operating room temperature)
LpAm bystander at max ambient: 75 dBA

Regulations
Meets or exceeds the following requirements:

Safety

IEC 60950, UL/CSA60950, EN60950, CB scheme with all country differences

RFI/EMI

FCC CFR 47 Part 15 Class A, EN55022 Class A, EN300-386, EN 61000-3-2, EN 61000-3-3

Immunity

EN 55024 ,EN 300 386

Certifications

Safety: UL/cUL, UL DEMKO, CCC, CE, BSMI, GOST-R, S-Mark
EMC: CE, FCC, VCCI, ICES, C-Tick, MIC, CCC, GOST-R, BSMI Class A
Other: Labeled per WEEE (Waste Electrical and Electronic Equipment) Directive (2002/96/EC) and RoHS Directive (2002/95/EC)

Dimensions and Weight (Sun Server X2-4)

Height

129.85 mm (5.1 in.)

Width

436.5 mm (17.2 in.)

Depth

732 mm (28.8 in.)

Weight

Maximum: 38.5 kg (85 lb.)
Minimum: 29.5 kg (65 lb.)

Rack Mounting

Oracle ZFS Storage ZS3-BA Racks

Racks are as follows:

Sun Rack II 1242
Sun Rack II 1042

Array Controller
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7043628 [C]	6Gbps SAS-2 I/O Controller Module	n/a

Batteries
Option #	Manufacturing Part #	Description	Previous Part #
n/a	150-3993 [C]	3V Lithium Coin Cell Battery	n/a

CPU Module
Option #	Manufacturing Part #	Description	Previous Part #
n/a	371-5056 [F]	2.0GHz 8-Core Xeon E7-4820 CPU Module	n/a
n/a	7046121 [F]	CPU Heatsink	n/a

Cables
Option #	Manufacturing Part #	Description	Previous Part #
7104500	7056300 [C]	Mini SAS to HD Cable, SFF-8088 to SFF-8644, 6M	n/a
7106737	7023009 [C]	Mini SAS to HD Cable, SFF-8088 to SFF-8644, 3M	n/a
X2121A-5M-N	530-4446 [C]	10Gbps QSFP to QSFP Cable, 5m	n/a
n/a	530-3771 [C]	Ethernet Cable, Category 5/5E, RJ45 to RJ45, 1m, Grey	n/a
n/a	530-3886 [C]	4X Mini SAS Cable, SFF-8088 to SFF-8088, 0.5M	n/a
n/a	530-4436 [C]	Ethernet Cable, Category 5/5E, RJ45 to RJ45, 7′ Black	n/a
n/a	530-4526 [C]	Ethernet Cable, Category 5/5E, RJ45 to RJ45, 7-Foot, Green	n/a
n/a	530-4527 [C]	Ethernet Cable, Category 5/5E, RJ45 to RJ45, 7-Foot, Yellow	n/a
n/a	560-2951 [C]	Cable Kit	n/a
	530-4118	4x Mini SAS Cable, SFF-8087 to SFF-8087, 780mm	n/a
	530-4287	Fan Board to System Board Signal Cable	n/a
	530-4288	Fan Board to System Board Power Cable	n/a
	530-4289	System Board to PDB Cable	n/a
	530-4290	System Board to Disk Backplane Signal Cable	n/a
	530-4291	System Board to Disk Backplane Power Cable	n/a
	530-4352	SFF-8087 to SFF-8087/SATA Splitter Cable, 780mm	n/a
n/a	7075861 [C]	Ethernet Cable, CAT6A, RJ45 to RJ45, 20-foot, Black	n/a
n/a	7083458 [C]	Bootless Ethernet Cable, Category 5/5E, RJ45 to RJ45, 7-Foot, Green	n/a
n/a	7083459 [C]	Bootless Ethernet Cable, Category 5/5E, RJ45 to RJ45, 7-Foot, Yellow	n/a
n/a	7083460 [C]	Bootless Ethernet Cable, Category 5/5E, RJ45 to RJ45, 7-Foot, Black	n/a

Communication
Option #	Manufacturing Part #	Description	Previous Part #
X4242A	375-3696 [C]	Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter	n/a
X4242A	7092767 [C]	Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter	n/a
n/a	7056175 [C]	Cluster Heartbeat Assembly	n/a
	511-1496	Cluster Heartbeat Card	n/a
	541-4350	EMI Gasket	n/a
n/a	7089470 [C]	Cluster Heartbeat Assembly	7056175 [C]
	541-4350	EMI Gasket	n/a
	7087050	Cluster Heartbeat Card	n/a

Disk Backplane
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7039459 [F]	6-Slot Disk Backplane	n/a

Disks
Option #	Manufacturing Part #	Description	Previous Part #
7104204 ¹⁰	7097377 ⁹ [C]	1.6TB SAS-3 Solid State Drive Assembly	n/a
	7094629	HGST HUSMR1616ASS200 [HSCAC2DA2SUN1.6T] (1.6TB – 2.5″ Solid State – SAS-3 Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
n/a	7044376 [C]	900GB 10000 RPM SAS Disk Drive Assembly	n/a
	7045230	Hitachi HUC109090CSS900 [H109090SESUN900G] (900GB 10000 RPM SAS Disk Drive)	n/a
	7044311	2.5″ Evo Disk Mounting Bracket	n/a
n/a	7044379 [C]	73GB SAS Solid State Drive Assembly	n/a
	7045627	Stec Z16IZF2E-73UCU [Inquiry Unknown] (73GB – 2.5″ Solid State – SAS-2 Disk)	n/a
	7044311	2.5″ Evo Disk Mounting Bracket	n/a
n/a	7044396 [C]	73GB SAS Solid State Drive Assembly	n/a
	7045627	Stec Z16IZF2E-73UCU [Inquiry Unknown] (73GB – 2.5″ Solid State – SAS-2 Disk)	n/a
	7044392	3.5″ Heron Disk Mounting Bracket	n/a
	7063417	2.5″ to 3.5″ Adapter Bracket	n/a
n/a	7046052 ³ [C]	1.6TB SAS-2 Solid State Drive Assembly	n/a
	7045914	SanDisk LB1606R [LB1606R SUN1.6T] (1.6TB – 2.5″ Solid State – SAS-2 Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
n/a	7046425	SSD Filler Panel	n/a
n/a	7046427	Disk Filler Panel	n/a
n/a	7046432	SSD Filler Panel	n/a
n/a	7046434	Disk Drive Filler Panel	n/a
n/a	7066831 [C]	4TB 7200 RPM SAS Disk Drive Assembly	n/a
	7065489	Hitachi HUS724040ALS640 [H7240AS60SUN4.0T] (4TB – 7200 RPM – SAS Disk)	n/a
	7044392	3.5″ Heron Disk Mounting Bracket	n/a
	7096032	3.5″ Heron Disk Mounting Bracket	n/a
n/a	7066874 [C]	900GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks;	n/a
	7045230	Hitachi HUC109090CSS900 [H109090SESUN900G] (900GB 10000 RPM SAS Disk Drive)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
n/a	7087183 ⁴ [C]	1.6TB Common SAS-2 Solid State Drive Assembly	n/a
	7045914	SanDisk LB1606R [LB1606R SUN1.6T] (1.6TB – 2.5″ Solid State – SAS-2 Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
	7044311	2.5″ Evo Disk Mounting Bracket	n/a
	7087210	Bracket Assembly Instructions	n/a
n/a	7094120 ⁵ [C]	200GB SAS Solid State Drive Assembly	n/a
	7093646	HGST HUSMM1640ASS200 [HSCAC2DA6SUN200G] (200GB – 2.5″ Solid State – SAS Disk)	n/a
	7044392	3.5″ Heron Disk Mounting Bracket	n/a
	7096030	2.5″ to 3.5″ Cabrio Adapter Bracket	n/a
	7096032	3.5″ Heron Disk Mounting Bracket	n/a
n/a	7094126 ⁶ [C]	200GB SAS Solid State Drive Assembly	n/a
	7093646	HGST HUSMM1640ASS200 [HSCAC2DA6SUN200G] (200GB – 2.5″ Solid State – SAS Disk)	n/a
	7044311	2.5″ Evo Disk Mounting Bracket	n/a
n/a	7097385 ⁷ ⁸ [C]	1.6TB Common SAS-3 Solid State Drive Assembly	n/a
	7094629	HGST HUSMR1616ASS200 [HSCAC2DA2SUN1.6T] (1.6TB – 2.5″ Solid State – SAS-3 Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
	7044311	2.5″ Evo Disk Mounting Bracket	n/a
	7087210	Bracket Assembly Instructions	n/a

³ Assembly 7046052 or 7087183 is used to replace SSD Assembly 7046052.
⁴ Assembly 7087183 is shipped when 7046052 or 7078599 are ordered. Bracket 541-2123 is installed.
⁵ 200GB SAS Solid State Drive Assembly PN#7094120 requires a minimum firmware version of 2013.1.2.9
⁶ 200GB SAS Solid State Drive Assembly PN#7094126 requires a minimum firmware version of 2013.1.2.9
⁷ Assembly 7097385 is shipped when 7097377 or 7097382 are ordered. Bracket 541-2123 is installed.
⁸ AK software update is required to support Hitachi SSDs.
⁹ AK software update is required to support Hitachi SSDs.
¹⁰ Assembly 7097377 replaced assembly 7046052 in option 7104204.

Ethernet
Option #	Manufacturing Part #	Description	Previous Part #
X1109A-Z	7051223 [C]	Dual 10-Gigabit PCI Express Ethernet SFP+ LP	n/a
X2129A-N	530-4449 [C]	10Gb/Sec Short Wave SFP+ Transceiver	n/a

Fan
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-3539 [C]	92mm Fan Module	n/a
n/a	7057262 [F]	Fan Cage Assembly	n/a
	530-4349	LED Flex Circuit	n/a
	7057260	Fan Board with USB and VGA	n/a

Fibre Channel
Option #	Manufacturing Part #	Description	Previous Part #
7101674	7023303 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, QLogic	n/a
7101676	7023325 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101676	7023324	16Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a

Memory
Option #	Manufacturing Part #	Description	Previous Part #
n/a	371-5002 [C]	4GB USB 2.0 Flash Drive	n/a
n/a	7051516 [F]	Memory Riser Assembly	n/a
	350-1830	Memory Riser Tray Assembly	n/a
	341-5773	Memory Riser Tray	n/a
	7051515	Memory Riser Board	n/a
n/a	7059236 [C]	32GB Memory Assembly (2 × 16GB DDR3-1066 DIMMs)	n/a
n/a	7058861	16GB 1.35V DDR3-1066 DIMM (2-rank)	n/a

Power
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7043627 [C]	580 Watt AC Input Power Supply	n/a
n/a	7052431 [F]	Power Distribution Board / Power Supply Backplane	n/a
	371-4446	Bus Bar	n/a
	7052430	Power Distribution Board / Power Supply Backplane	n/a
n/a	7060596 [C]	Type A239E 2000 Watt AC Input Power Supply	n/a
n/a	7081064 [C]	Type A239A 2000 Watt AC Input Power Supply	7060596 [C]

Rack
Option #	Manufacturing Part #	Description	Previous Part #
n/a	330-5319	1U Filler Panel	n/a
n/a	371-4791 [C]	Tool-less Slide Rail Rack Mount Kit	n/a
n/a	371-4812 [C]	Cable Management Arm	n/a
n/a	7015399 [C]	10A/250V 90° IEC 320 Sheet E to IEC 320 C13 Cord, 1M	n/a
n/a	7015400 [C]	10A/250V 90° IEC 320 Sheet E to IEC 320 C13 Cord, 2M	n/a
n/a	7044619 [C]	Mounting Rail Kit	n/a
n/a	7063682 [C]	Mounting Rail Kit	n/a

SCSI
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7047852 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
n/a	7067091 [C]	4×4-Port PCIe-3, 6Gbps SAS-2 HBA	n/a

System Board
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7071038 [F]	System Board Assembly	n/a
	150-3993 [C]	3V Lithium Coin Cell Battery	n/a
	341-5567	System Board Tray	n/a
	7051520	Rear I/O Board	n/a
	7071037	System Board	n/a
	530-3510	Interlock Switch Cable	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
