Oracle Sun X4800 Server

Oracle Sun X4800 Server Oracle Sun X4800 Server Sun Servers SUN FIRE x4800

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*



    Processor
    Number 2 or 4 6-Core or 8-Core CPU Modules (CMODs)
    Each CMOD contains two Intel Xeon Processor 7500 Series
    Architecture Type: Intel Xeon 7500 Processor Series
    CPUs Intel 2.00GHz 6-Core Xeon E7540, 105W
    Intel 2.00GHz 8-Core Xeon X7550, 130W
    Intel 2.00GHz 8-Core Xeon X7560, 130W
    Cache memory 256KB unified (data and instruction) Level 2 cache
    12MB, 18MB or 24MB shared inclusive Level 3 cache
    Main Memory
    Capacities DIMM slots: 128 DIMM slots, 32 DIMMs per CMOD
    DIMM type: Registered DDR3-1066/PC3-10600 ECC DIMMs
    Registered DDR3-1066/PC3-8500 ECC DIMMs
    DIMM size: 2GB, 4GB, 8GB
    Maximum capacity: 1TB
    Standard Integrated Interfaces
    USB Internal: One USB Port (supported for CMOD0/BL0 only)
    PCI Interfaces I/O is offered in two form factors:
    • PCI Express ExpressModules (EM):
      • Up to eight rear, hot-swappable PCIe 2.0 ExpressModule slots.
      • Each EM has a x8 electrical/x8mechanical PCIe 2.0 bus.

      and

    • PCI Express Network Express Modules (NEM):
      • Two hot-swappable NEMs, each NEM provides:
      • Four 10GbE network ports via SFP+ connectors.
      • Four 1GbE network ports via RJ-45 connectors.
      • Two x4 mini SAS-2 ports (not supported)
    Internal Mass Storage
    Disks Up to 8 hot-swappable disks
    Drive Type Density Speed Form Factor
    SAS-2 300GB 10,000 RPM 2.5″
    Power Supplies
    • Four redundant, Hot-Swappable front accessible power supplies.
    • AC power: 200-240VAC (47 Hz-63 Hz)
    Environment
    Temperature Operating: 5° C to 35° C (41° F to 95° F)
    Nonoperating: -40° C to 70° C (-40° F to 158° F)
    Humidity Operating: 10% to 90% relative humidity noncondensing.
    Nonoperating: up to 93% relative humidity noncondensing.
    Altitude Operating: Up to 3,048 m (10,000 ft.), maximum ambient temperature is derated by 1° C for every 300 m (985 ft) above 900 m (2,952 ft).
    Nonoperating: Up to 12,000 m (39,370 ft).
    Acoustic Noise Emissions LwAd (1B= 10dB) at max ambient: 7.7 B operating and 6.8 B idling.
    Management Environment
    Service Processor (SP) Module
    • Hot-swappable SP providing:
    • Oracle Integrated Lights Out Manager (ILOM).
    • Two 10/100Base-T management (NET MGT) (port 1 not used).
    • One RJ-45 management serial port (SER MGT).
    • Universal Connector Port (UCP) for connection to the multi port (dongle) cable.
    • Multi Port (dongle) cable connection to UCP provides:
      • USB: Two USB ports.
      • Serial: One Serial RJ-45 port.
      • VGA: One VGA 1024x768x16bit@60Hz graphics controller port.
    • Chassis status LEDs.
    • Remote power control.
    • Remote Keyboard, Video, Mouse and virtual Storage (RKVMS).
    • Secure remote access via Web-GUI interface over SSL.
    • DMTF-style Command Line Interface over Serial or SSH 2.0.
    • Authentication via Local, RADIUS, LDAP, or Active Directory.
    • IPMI 2.0, SNMP v1, v2c, and v3
    Regulations
    Meets or exceeds the following requirements:
    Safety IEC 60950-1, UL/CSA60950-1, EN60950-1, CB scheme with all country differences
    EMC: FCC CFR 47 Part 15 Class A, EN 55022:2006 Class A, EN 61000-3-2:2000+A2:2005, EN 61000-3-3:1995 +A1:2001, EN55024:1998 +A1:2001 +A2:2003, EN300-386.
    Certifications Country certifications safety/EMC: UL/cUL, CE, S-Mark, CSA C22.2 No. 60950- 03 EN 60950-01:2001, 1st Edition, IEC 60950-01:2001, 1st Edition, FCC, VCCI, ICES-003, C-Tick, KCC, GOST-R, BSMI Class A.
    Other: Complies with WEEE (Waste Electrical and Electronic Equipment) Directive (2002/96/EC) and RoHS Directive (2002/95/EC).
    RoHS Compliance Level RoHS:Y
    Dimensions and Weight
    Height 218.75 mm (8.61 in.)
    Width 445 mm (17.5 in.)
    Depth 700 mm (27.56 in.)
    Weight 81.65 kg (180 lb.)
    Backplane/Centerplane
    Option # Manufacturing
    Part #    		 Description
    n/a 330-4398 Busbar Bolt Cover, RoHS:Y
    n/a 341-3592 Busbar Spacer, RoHS:Y
    n/a 540-7640 Centerplane Assembly, RoHS:Y
    • 271-1096
    • Signal Link Board, RoHS:Y
    • 371-4512
    • Busbar Assembly, RoHS:Y
    • 511-1057
    • Power Distribution Board, RoHS:Y
    • 511-1058
    • Centerplane, RoHS:Y
    Batteries
    Option # Manufacturing
    Part #    		 Description
    n/a 150-1204 3V Lithium battery, RoHS:Y
    CPU Module
    Option # Manufacturing
    Part #    		 Description
    X8500A 1 × 2.00GHz Intel 6-Core Xeon E7540, 105W, RoHS:Y
    371-4693 2.00GHz Intel 6-Core Xeon E7540, RoHS:Y
    • 310-0225
    • CPU Heatsink, RoHS:Y
    X8501A 1 × 2.00GHz 8-Core Xeon X7550 CPU Module, RoHS:Y
    371-4692 2.00GHz 8-Core Xeon X7550 CPU Module, RoHS:Y
    • 310-0225
    • CPU Heatsink, RoHS:Y
    X8502A 1 × 2.26GHz 8-Core Xeon X7560 CPU Module, RoHS:Y
    371-4860 2.26GHz 8-Core Xeon X7560 CPU Module, RoHS:Y
    n/a 250-1802 Alcohol Wipe Cleaner
    n/a 310-0065 Thermal Grease, Syringe, RoHS:Y
    n/a 541-3426 System Board, RoHS:Y
    • 511-1124
    • 0MB Board, RoHS:Y
    • 150-3993
    • Panasonic BR2032 Battery, RoHS:Y
    Cables
    Option # Manufacturing
    Part #    		 Description
    n/a 530-3936 USB/VGA/RJ45 Dongle Cable Adapter, RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    X4219A-Z 375-3605 Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express ExpressModule, RoHS:Y
    Disk Backplane
    Option # Manufacturing
    Part #    		 Description
    n/a 511-1062 8-Slot Disk Backplane, RoHS:Y
    n/a 530-4214 SAS0 HDD 2 Cable, RoHS:Y
    n/a 530-4215 SAS1 HDD 0 Cable, RoHS:Y
    n/a 530-4216 Backplane Power Cable, RoHS:Y
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRA-SS2CM-300G10K2 542-0300 300GB – 10000 RPM, Disk Assembly with 1 bracket and 1 disk:, RoHS:Y
    • 390-0449
    • Seagate ST93000SSUNG [ST930003SSUN300G]
      (300GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0451
    • Hitachi HUC103030CSS600 [H103030SCSUN300G]
      (300GB – 10000 RPM – SAS Disk), RoHS:Y
    • 371-4760
    • Manta Ray Bracket, RoHS:Y
    n/a 350-1524 Mantaray Filler (8516A)
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X1110A-Z 375-3616 Dual 10-Gigabit SFP+ Ethernet ExpressModule, RoHS:Y
    X2129A-N 530-4449 10Gbps Short Wave Pluggable (SFP+) Transceiver, RoHS:Y
    X2130A-1M-N 530-4441 Sun 10Gbps SFP+ TwinX Cable, 1m, RoHS:Y
    X2130A-3M-N 530-4442 Sun 10Gbps SFP+ TwinX Cable, 3m, RoHS:Y
    X2130A-5M-N 530-4443 Sun 10Gbps SFP+ TwinX Cable, 5m, RoHS:Y
    X4871A-Z 375-3648 Dual 10-Gigabit Ethernet Fabric Expansion Module (FEM), RoHS:Y
    X7284A-Z 375-3498 x4 PCI Express Quad Gigabit Ethernet UTP ExpressModule
    X8508A 540-7637 Network Express Module (NEM), RoHS:Y
    • 511-1056
    • NEM Board, RoHS:Y
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 371-4579 Fan Assembly, RoHS:Y
    n/a 540-7672 Fan Interconnect Module,RoHS:Y
    • 511-1063
    • Fan Board, RoHS:Y
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    SG-XPCIEFCGBE-E8-Z 371-4666 8Gb/sec PCI Express Dual Fibre Channel ExpressModule Host Adapter, Emulex, RoHS:Y
    SG-XPCIEFCGBE-Q8 371-4522 8Gb/sec PCI Express Dual Fibre Channel ExpressModule Host Adapter, QLogic, RoHS:Y
    Memory
    Option # Manufacturing
    Part #    		 Description
    X8460A 542-0244 2 × 2GB DDR3-1066 DIMMs, RoHS:Y
    • 371-4774
    • 2GB DDR3-1066 DIMM, RoHS:Y
    X8461A 542-0245 2 × 4GB DDR3-1066 DIMMs, RoHS:Y
    • 371-4775
    • 4GB DDR3-1066 DIMM, RoHS:Y
    X8462A 542-0246 2 × 8GB DDR3-1066 DIMMs, RoHS:Y
    • 371-4776
    • 8GB DDR3-1066 DIMM, RoHS:Y
    Power
    Option # Manufacturing
    Part #    		 Description
    n/a 300-2159 1030W/2060W AC Input Power Supply, Type A239,RoHS:Y
    Rack
    Option # Manufacturing
    Part #    		 Description
    X8511A 371-4742 Universal Rack Mount Kit, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SGX-SAS6-R-REM-Z 371-4746 6Gigabit SAS RAID PCI Battery Module, BBU07, RoHS:Y
    371-4982 6Gigabit SAS RAID PCI Battery Module, BBU08, RoHS:Y
    375-3647 6Gbps SAS-2 RAID Expansion Module, B2/B4 ASIC, RoHS:Y
    SGX-SAS6-REM-Z 375-3643 6Gbps SAS-2 RAID Expansion Module (REM), RoHS:Y
    System Board
    Option # Manufacturing
    Part #    		 Description
    n/a 150-3993 Panasonic BR2032 Battery, RoHS:Y
    System Service Processor
    Option # Manufacturing
    Part #    		 Description
    X8510A 540-7645 Service Processor (SP), RoHS:Y
    • 511-1345
    • SP Board, RoHS:Y
    • 150-1204
    • 3V Lithium battery, RoHS:Y
