Oracle Sun V210 Server

Oracle Sun V210 Server Oracle Sun V210 Server Sun Servers SUN FIRE V210 copy

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*


    Processor
    Number One or two
    Architecture 1GHz, 1.33GHz UltraSPARC® IIIi, 64 bit, 4-way Superscalar SPARC® V9
    Cache memory 64 KB data, 32 KB instruction and 1 MB integrated L2
    Main Memory
    Capacities Oracle Sun V210 Server Oracle Sun V210 Server bullet 4 DIMM slots per processor, registered DDR-1 SDRAM
    Oracle Sun V210 Server Oracle Sun V210 Server bullet (PC2100/PC2700) 128 bit + ECC databus
    Oracle Sun V210 Server Oracle Sun V210 Server bullet System configurations from 512 MB to 16 GB
    Standard Interfaces
    Ethernet Oracle Sun V210 Server Oracle Sun V210 Server bulletFour 10/100/1000 BaseT Ethernet
    Oracle Sun V210 Server Oracle Sun V210 Server bulletOne 10 BaseT Ethernet (Network Management)
    PCI One 64 bit 33/66 MHz 3.3V full-length slot (PCI 2.2 compliant)
    Note:Nominal power = maximum 25W
    SCSI One Ultra-320 SCSI multimode (SE/LVD)
    Serial Oracle Sun V210 Server Oracle Sun V210 Server bullet One TIA/EIA-232-F asynchronous (DB9) Port
    Oracle Sun V210 Server Oracle Sun V210 Server bullet One TIA/EIA-232-F (RJ45) Port (Serial Management)
    System Configuration Reader and Card Front accessible for transfer of system configuration information, including host ID
    USB Two OHCI-1.0 Compliant Interfaces, supporting dual speeds of 12 and 1.5 Mbits/sec each
    Internal Mass Storage
    Disks Up to two hot-swap Ultra-320 SCSI 36GB, 73GB, or 146GB Disks
    DVD-ROM One Slim-line ATAPI DVD-ROM (Optional)
    Environment
    AC input 90 – 264 VAC (47 – 63 Hz)
    Input power 459 W
    Nominal power
    (calculated at 240V/50Hz)
    Minimum configuration: 206 Watts
    (1 × 1.34GHz processor, 2 × 256MB DIMMs, 1 × 73GB HDD)
    Maximum configuration: 411 Watts
    (2 × 1.34GHz processors, 8 × 1GB DIMMs, 2 × 73GB HDDs, Crypto 500,
    1 × DVD-ROM, 1 × PCI card [max power spec 25W])
    Typical Minimum configuration: 179 Watts
    (1 × 1.34GHz processor, 2 × 256MB DIMMs, 1 × 73GB HDD)
    Typical Maximum configuration: 296 Watts
    (2 × 1.34GHz processors, 8 × 1GB DIMMs, 2 × 73GB HDDs, Crypto 500,
    1 × DVD-ROM, 1 × PCI card [max power spec 25W])
    Heat dissipation Minimum configuration: 704 BTU/hr
    Maximum configuration: 1406 BTU/hr
    Temperature Operating: 5° C to 40° C (41° F to 104° F)
    Nonoperating: -40° C to 65° C (-40° F to 149° F)
    Humidity Operating: 10% to 90% relative humidity noncondensing, 27°C max wet bulb
    Nonoperating: Up to 93% relative humidity, noncondensing, 38°C max wet bulb
    Altitude Operating: Up to 3000 m, maximum ambient temperature is derated by 2° C per 500 m above 500 m
    Nonoperating: Up to 12000 m
    Acoustic noise Operating: Less than 7.3 B sound power in ambient temperature of up to 24° C
    Regulations
    Meets or exceeds the following requirements:
    Safety IEC60950, UL/CSA60950, EN60950
    Emissions FCC Class A, Part 15 47 CFR, EN55022, CISPR 22
    Immunity EN55024
    Certification Safety: cULus Mark, TUV GS Mark, CE Mark
    EMC: CE Mark (93/68/EEC), FCC authorized Class A, VCCI, BSMI, CTICK
    Dimensions and Weights
    Height 43.2 mm (1.7 in.) (1 RU)
    Width 425 mm (16.73 in.)
    Depth 635 mm (25 in.)
    Weight 12 kg (26.4 lb.) fully configured; 15.6 kg (34.31 lb.) with rack-mount rails and cable management arm
    Batteries
    Option # Manufacturing
    Part #
    Description
    n/a 371-0090 3V Lithium Battery BR2032
    Boot PROM
    Socket Manufacturing
    Part #
    Patch
    U55 254-0078 116056
    U55 254-0090 116056
    CPU Module
    Option # Manufacturing
    Part #
    Description
    X7406A 595-7222 1GHz processor for V210/V240 (includes 1 of the following CPUs)
    • 370-7786
    • CPU Fan/Heatsink
    • 527-1087
    • 1.064GHz USIIIi
    • 527-1140
    • 1.064GHz USIIIi
    Cables
    Option # Manufacturing
    Part #
    Description
    X311L Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-1097 IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
    X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X314L Localized Power Cord Kit – Swiss, RoHS:Y
    180-1994 IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
    X317L Localized Power Cord Kit – U.K., RoHS:Y
    180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X320A Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-2164 IEC 320 C13 to NEMA 6-15P – 10A/250V 2.0M Black, RoHS:Y
    X383L Localized Power Cord Kit – Danish, RoHS:Y
    180-1995 IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
    X384L Localized Power Cord Kit – Italian, RoHS:Y
    180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386L Localized Power Cord Kit – Australian, RoHS:Y
    180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    n/a 370-5137 Cable Kit
    n/a 530-1351 IEC 320 C13 to NEMA 6-15 – 10A/250V 2.0M Black, RoHS:Y
    n/a 530-1819 Localized Power Cord Kit – Danish
    n/a 530-2961 RJ45 Cat5 Ethernet Cable, RoHS:Y
    n/a 530-3100 RJ45F to DB9F Adapter, RoHS:Y
    n/a 530-3566 RME KEY SWITCH Cable, RoHS:Y
    Card/Reader
    Option # Manufacturing
    Part #
    Description
    n/a 370-5127 System Configuration Card Reader
    n/a 370-5155 System Configuration Card, RoHS:Y
    n/a 371-0795 System Configuration Card with 10 MAC Addresses, RoHS:Y
    n/a 371-3551 System Configuration Card with 10 MAC Addresses, Polycarbonate, RoHS:Y
    Communication
    Option # Manufacturing
    Part #
    Description
    X1355A-2 371-0982 2M, 80-Pin, 4-Port, DB37, RS449 Breakout Cable,RoHS:Y
    375-3296 Quad Port High Speed Serial Interface PCI-X (HSI/U), RoHS:Y
    X1157A 501-3028 SunATM-155/MFiber PCI 4.0
    X2156A 375-0100 Serial Asynchronous Interface PCI (SAI/P) 3.0
    X4011A 501-6039 Crypto Accelerator 4000 UTP (copper)
    X4012A 501-6040 Crypto Accelerator 4000 MMF (fiber)
    X4111A 501-6039 Crypto Accelerator 4000 UTP (copper)
    X4112A 501-6040 Crypto Accelerator 4000 MMF (fiber)
    X7405A 370-5464 Hardware Cryptographic Module (Crypto Accelerator 500)
    X7405A-4 371-0991 Hardware Cryptographic Module (Crypto Accelerator 500), RoHS:YL
    Disks
    Option # Manufacturing
    Part #
    Description
    X5267A 540-4904 36.4GB – 10000 RPM, Disk Assembly with 1 bracket, 1 of the following plates and 1 of the following disks:
    • 340-5928
    • Plate
    • 340-7269
    • Plate, RoHS:Y
    • 390-0109
    • Seagate ST336607LC [ST336607LSUN36G]
      (36.4GB – 10000 RPM – SCSI Disk)
    • 390-0111
    • Hitachi DK32EJ-36NC [DK32EJ36NFSUN36G]
      (36.4GB – 10000 RPM – SCSI Disk)
    • 390-0156
    • Fujitsu MAP3367NC [MAP3367N SUN36G]
      (36.4GB – 10000 RPM – SCSI Disk)
    • 540-3024
    • 1″ SPUD Bracket, RoHS:Y
    X5268A 540-6602 146.8GB – 10000 RPM, Disk Assembly with 1 bracket, 1 plate and 1 of the following disks, RoHS:Y
    • 341-1986
    • Plate, RoHS:Y
    • 390-0253
    • Fujitsu MAW3147NC [MAW3147NCSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0266
    • Hitachi HUS103014FL3800 [HUS10143ASUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0276
    • Seagate ST3146707LC [ST314670LSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 540-3024
    • 1″ SPUD Bracket, RoHS:Y
    XRA-SC1CB-73G10K 540-6600 73.4GB – 10000 RPM, Disk Assembly with 1 bracket, 1 plate and 1 of the following disks, RoHS:Y
    • 341-1986
    • Plate, RoHS:Y
    • 390-0252
    • Fujitsu MAW3073NC [MAW3073NCSUN73G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0265
    • Hitachi HUS103073FL3800 [HUS10733ASUN72]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0275
    • Seagate ST373207LC [ST373207LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 540-3024
    • 1″ SPUD Bracket, RoHS:Y
    n/a 540-5455 73.4GB – 10000 RPM, Disk Assembly with 1 bracket, 1 of the following plates and 1 of the following disks:
    • 340-5928
    • Plate
    • 340-7269
    • Plate, RoHS:Y
    • 390-0106
    • Seagate ST373307LC [ST373307LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0108
    • Hitachi DK32EJ-72NC [DK32EJ72NSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0157
    • Fujitsu MAP3735NC [MAP3735N SUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0174
    • Seagate ST373207LC [ST373207LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0175
    • Fujitsu MAT3073NC [MAT3073N SUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0176
    • Hitachi HUS103073FL3800 [HUS10733ASUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0252
    • Fujitsu MAW3073NC [MAW3073NCSUN73G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0265
    • Hitachi HUS103073FL3800 [HUS10733ASUN72]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0275
    • Seagate ST373207LC [ST373207LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 540-3024
    • 1″ SPUD Bracket, RoHS:Y
    n/a 540-6064 146.8GB – 10000 RPM, Disk Assembly with 1 bracket, 1 plate, and 1 of the following disks:
    • 340-7269
    • Plate, RoHS:Y
    • 390-0154
    • Fujitsu MAP3147NC [MAP3147N SUN146G]
      (146.8GB – 10000 RPM – SCSI Disk)
    • 390-0155
    • Hitachi DK32EJ-14NC [DK32EJ14NSUN146G]
      (146.8GB – 10000 RPM – SCSI Disk)
    • 390-0177
    • Seagate ST3146707LC [STST314670LSUN146G]
      (146GB – 10000 RPM – SCSI Disk)
    • 390-0178
    • Fujitsu MAT3147NC [MAT3147N SUN146G]
      (146GB – 10000 RPM – SCSI Disk)
    • 390-0179
    • Hitachi HUS103014FL3800 [HUS10143ASUN146G]
      (146GB – 10000 RPM – SCSI Disk)
    • 390-0253
    • Fujitsu MAW3147NC [MAW3147NCSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0266
    • Hitachi HUS103014FL3800 [HUS10143ASUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0276
    • Seagate ST3146707LC [ST314670LSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 540-3024
    • 1″ SPUD Bracket, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #
    Description
    X4150A-2 501-7415 GigaSwift Ethernet UTP (GCS), RoHS:Y
    X4151A-2 501-7430 GigaSwift Ethernet MMF (GFS), RoHS:Y
    X4445A 501-6738 Quad GigaSwift PCI-X Ethernet (QGE-X), RoHS:Y
    X1033A 501-5019 Sun FastEthernet PCI Adapter (FE/P) 2.0
    X1034A 501-5406 Quad FastEthernet PCI (QFE/P)
    X1141A 501-4373 Gigabit Ethernet PCI (GBE/P) 2.0
    X1150A 501-5902 Sun GigaSwift Ethernet UTP (Copper)
    X1151A 501-5524 Sun GigaSwift Ethernet MMF (Fiber)
    X3150A 501-5902 Sun GigaSwift Ethernet UTP (Copper)
    X3151A 501-5524 Sun GigaSwift Ethernet MMF (Fiber)
    X4150A 501-6719 GigaSwift Ethernet UTP (GCS)
    X4151A 501-6762 GigaSwift Ethernet MMF (GFS)
    X4444A 501-6522 Quad GigaSwift Ethernet UTP (QGE)
    Fan
    Option # Manufacturing
    Part #
    Description
    X7418A 370-6455 4-Fan Assembly
    40mm 13000RPM Fan, Delta FFB0412SHN
    Bracket 34471050004
    n/a 370-5133 4-Fan Assembly
    40mm 9500RPM Fan, Delta FFB0412VHN
    Bracket 34471050004
    n/a 371-0837 CPU Fan/Heatsink, RoHS:Y
    n/a F370-5126 CPU Fan/Heatsink FRU
    • 370-5126
    • CPU Fan/Heatsink
    • 370-7786
    • CPU Fan/Heatsink
    Fibre Channel
    Option # Manufacturing
    Part #
    Description
    SG-XPCI1FC-EM4-Z 375-3398 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QF4 375-3354 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM4-Z 375-3399 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF4 375-3294 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI1FC-EM2 375-3304 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-JF2 375-3156 JNI 2Gb PCI Single FC Host Adapter
    SG-XPCI1FC-QF2 375-3102 2Gb PCI Single FC Host Adapter
    SG-XPCI1FC-QL2 375-3383 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM2 375-3305 2Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-JF2 375-3157 JNI 2Gb PCI Dual FC Host Adapter
    SG-XPCI2FC-QF2 375-3108 2Gb PCI Dual FC Host Adapter
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    SG-XPCI2FC-QF2-Z 375-3363 2Gb PCI Dual FC Host Adapter, RoHS:Y
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    X6727A 375-3030 PCI Dual FC Host Adapter+, RoHS:YL
    X6767A 375-3102 2Gb PCI Single FC Host Adapter
    X6768A 375-3108 2Gb PCI Dual FC Host Adapter
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    X6799A 375-3019 PCI Single FC Host Adapter
    Graphics
    Option # Manufacturing
    Part #
    Description
    X3685A 375-3069 XVR-500 Graphics Accelerator
    X3768A 370-4362 PGX64 8/24-Bit Color Frame Buffer
    X3769A 375-3126 XVR-100 Graphics Accelerator (32MB)
    X3770A 375-3181 XVR-100 Graphics Accelerator (64MB)
    X3780A 375-3153 XVR-600 Graphics Accelerator
    X7296A 375-3290 XVR-100 Graphics Accelerator (64MB), RoHS:Y
    I/O
    Option # Manufacturing
    Part #
    Description
    n/a 370-5129 Lower Interface Board
    Memory
    Option # Manufacturing
    Part #
    Description
    X7703A-4 1GB DDR Memory Option, (2 × 512MB DIMMs), RoHS:YL
    370-7972 512MB PC2700 DIMM, RoHS:Y
    371-1116 512MB Registered ECC DDR1 DIMM (SPD 0.0 or 1.0) PC2100 & faster, RoHS:YL
    X7402A 512MB DDR Memory Option (2 × 256MB DIMMs)
    370-5565 256MB Registered DDR DIMM (SPD 0.0)
    X7403A 1GB DDR Memory Option (2 × 512MB DIMMs)
    370-4939 512MB Registered DDR DIMM (SPD 0.0)
    X7404A 2GB DDR Memory Option (2 × 1GB DIMMs)
    370-4940 1GB Registered DDR DIMM (SPD 0.0)
    X7602A 512MB DDR Memory Option, SPD 1.0 (2 × 256MB DIMMs)
    370-6201 256MB Registered DDR DIMM (SPD 1.0)
    X7603A 1GB DDR Memory Option, SPD 1.0 (2 × 512MB DIMMs)
    370-6202 512MB Registered DDR DIMM (SPD 1.0)
    X7604A 2GB DDR Memory Option, SPD 1.0 (2 × 1GB DIMMs)
    370-6203 1GB Registered DDR DIMM (SPD 1.0)
    X7702A 512MB DDR Memory Option, SPD 0.0 or 1.0 (2 × 256MB DIMMs)
    370-7680 256MB Registered DDR DIMM (SPD 0.0 or 1.0) PC2100 & faster
    X7702A-4 512MB DDR1 Memory Option, (2 × 256MB DIMMs), RoHS:YL
    371-1115 256MB Registered ECC DDR1 DIMM (SPD 0.0 or 1.0) PC2100 & faster, RoHS:YL
    X7703A 1GB DDR Memory Option, SPD 0.0 or 1.0 (2 × 512MB DIMMs)
    370-7670 512MB Registered DDR DIMM (SPD 0.0 or 1.0) PC2100 & faster
    X7704A 2GB DDR Memory Option, SPD 0.0 or 1.0 (2 × 1GB DIMMs)
    370-7671 1GB Registered DDR DIMM (SPD 0.0 or 1.0) PC2100 & faster
    X7704A-4 2GB DDR1 Memory Option, (2 × 1GB DIMMs), RoHS:YL
    370-7973 1GB PC2700 DIMM, RoHS:Y
    371-1117 1GB Registered ECC DDR1 DIMM (SPD 0.0 or 1.0) PC2100 & faster, RoHS:YL
    X7711A-4 4GB DDR Memory Option, SPD 0.0 or 1.0 (2 × 2GB DIMMs), RoHS:YL
    370-7672 2GB Registered DDR DIMM (SPD 0.0 or 1.0) PC2100 & faster, RoHS:YL
    370-7974 2GB PC2700 DIMM, RoHS:Y
    n/a 540-6228 512MB DDR FRU, SPD 1.0 (2 × 256MB DIMMs)
    • 370-6201
    • 256MB Registered DDR DIMM (SPD 1.0)
    n/a 540-6229 1GB DDR FRU, SPD 1.0 (2 × 512MB DIMMs)
    • 370-6202
    • 512MB Registered DDR DIMM (SPD 1.0)
    n/a 540-6230 2GB DDR FRU, SPD 1.0 (2 × 1GB DIMMs)
    • 370-6203
    • 1GB Registered DDR DIMM (SPD 1.0)
    n/a 540-6399 512MB DDR FRU, SPD 0.0/1.0 (2 × 256MB DIMMs)
    • 370-7680
    • 256MB Registered DDR DIMM (SPD 0.0 or 1.0) PC2100 & faster
    n/a 540-6400 1GB DDR FRU, SPD 0.0/1.0 (2 × 512MB DIMMs)
    • 370-7670
    • 512MB Registered DDR DIMM (SPD 0.0 or 1.0) PC2100 & faster
    n/a 540-6401 2GB DDR FRU, SPD 0.0/1.0 (2 × 1GB DIMMs)
    • 370-7671
    • 1GB Registered DDR DIMM (SPD 0.0 or 1.0) PC2100 & faster
    n/a 540-6402 4GB Memory FRU (2 × 2GB DIMMs), RoHS:YL
    • 370-7672
    • 2GB Registered DDR DIMM (SPD 0.0 or 1.0) PC2100 & faster, RoHS:YL
    • 370-7974
    • 2GB PC2700 DIMM, RoHS:Y
    n/a 540-6775 512MB Memory FRU (2 × 256MB DIMMS), RoHS:YL
    • 371-1115
    • 256MB Registered ECC DDR1 DIMM (SPD 0.0 or 1.0) PC2100 & faster, RoHS:YL
    n/a 540-6776 1GB Memory FRU (2 × 512MB DIMMS), RoHS:YL
    • 370-7972
    • 512MB PC2700 DIMM, RoHS:Y
    • 371-1116
    • 512MB Registered ECC DDR1 DIMM (SPD 0.0 or 1.0) PC2100 & faster, RoHS:YL
    n/a 540-6777 2GB Memory FRU (2 × 1GB DIMMS), RoHS:YL
    • 370-7973
    • 1GB PC2700 DIMM, RoHS:Y
    • 371-1117
    • 1GB Registered ECC DDR1 DIMM (SPD 0.0 or 1.0) PC2100 & faster, RoHS:YL
    Miscellaneous
    Option # Manufacturing
    Part #
    Description
    X2132A 375-3051 SunPCi IIpro 733MHz coprocessor card
    X7042A 370-4294 SunPCi II 128MB memory expansion
    X7044A 370-4295 SunPCi II 256MB memory expansion
    X7045A 370-4430 SunPCi IIpro 512MB memory expansion
    n/a 371-2356 PCI Card Rail and Clip
    Power
    Option # Manufacturing
    Part #
    Description
    n/a 300-1566 320W AC Input Power Supply (Type A177)
    n/a 300-1847 320W AC Input Power Supply (Type A177), RoHS:YL
    Rack
    Option # Manufacturing
    Part #
    Description
    n/a 371-0066 Rack Mount/Cable Management Kit, RoHS:Y
    • 370-7668
    • Cable Management Arm, RoHS:Y
    • 370-7669
    • Slide Rail Kit, RoHS:Y
    Removable Media
    Option # Manufacturing
    Part #
    Description
    X7410A 370-5128 Internal Slimline DVD-ROM (ATAPI)
    X7410A-4 371-1108 Internal 8X Slimline DVD-ROM/CD-ROM, RoHS:YL
    • 371-0721
    • 8X Slimline DVD-ROM/CD-ROM, RoHS:YL
    • 390-0400
    • 8X Slimline DVD-ROM/CD-ROM, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #
    Description
    SGXPCI2SCSILM320-Z 375-3365 PCI Dual Ultra320 SCSI Adapter, RoHS:YL
    X4422A-2 501-7490 Dual GigabitEthernet / Dual SCSI PCI Adapter, RoHS:Y
    SG-XPCI2SCSI-LM320 375-3191 PCI/PCI-X Dual Ultra320 SCSI Adapter
    X1032A 501-5656 Single-Ended Ultra/Wide SCSI/FastEthernet (SunSwift PCI)
    X2222A 501-5727 Dual FastEthernet / Dual SCSI PCI Adapter
    X4422A 501-6635 Dual GigabitEthernet / Dual SCSI PCI Adapter
    X6540A 375-0005 Dual Single-Ended Ultra/Wide SCSI (PCI)
    X6541A 375-0006 Dual Differential Ultra/Wide SCSI (UDWIS/P)(HVD)
    X6758A 375-3057 PCI Dual Ultra3 SCSI Host Adapter (LVD)
    System Board
    Option # Manufacturing
    Part #
    Description
    n/a 375-3119 Motherboard w/ 1 × US IIIi 1GHz, 0MB
    (Tomatillo 2.2)
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3107
    • 0MB Motherboard, Tomatillo 2.2
    • 527-1087
    • 1.064GHz USIIIi
    • F370-5126
    • CPU Fan/Heatsink FRU
    • 370-5126
    • CPU Fan/Heatsink
    • 370-7786
    • CPU Fan/Heatsink
    n/a 375-3122 Motherboard w/ 2 × US IIIi 1GHz, 0MB
    (Tomatillo 2.2)
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3107
    • 0MB Motherboard, Tomatillo 2.2
    • 527-1087
    • 1.064GHz USIIIi
    • F370-5126
    • CPU Fan/Heatsink FRU
    • 370-5126
    • CPU Fan/Heatsink
    • 370-7786
    • CPU Fan/Heatsink
    n/a 375-3149 Motherboard w/ 1 × US IIIi 1GHz, 0MB
    (Tomatillo 2.3)
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3148
    • 0MB Motherboard, Tomatillo 2.3
    • 527-1087
    • 1.064GHz USIIIi
    • F370-5126
    • CPU Fan/Heatsink FRU
    • 370-5126
    • CPU Fan/Heatsink
    • 370-7786
    • CPU Fan/Heatsink
    n/a 375-3150 Motherboard w/ 2 × US IIIi 1GHz, 0MB
    (Tomatillo 2.3)
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3148
    • 0MB Motherboard, Tomatillo 2.3
    • 527-1087
    • 1.064GHz USIIIi
    • F370-5126
    • CPU Fan/Heatsink FRU
    • 370-5126
    • CPU Fan/Heatsink
    • 370-7786
    • CPU Fan/Heatsink
    n/a 375-3225 Motherboard w/ 1 × US IIIi 1.336GHz, 0MB
    • 370-7016
    • CPU Fan/Heatsink
    • 370-7786
    • CPU Fan/Heatsink
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3228
    • 0MB Motherboard, Tomatillo 2.3
    • 527-1169
    • 1.336GHz US IIIi, RoHS:Y
    n/a 375-3226 Motherboard w/ 2 × US IIIi 1.336GHz, 0MB
    • 370-7016
    • CPU Fan/Heatsink
    • 370-7786
    • CPU Fan/Heatsink
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3228
    • 0MB Motherboard, Tomatillo 2.3
    • 527-1169
    • 1.336GHz US IIIi, RoHS:Y
    n/a 375-3248 Motherboard w/ 1 × US IIIi 1GHz, 0MB
    (Tomatillo 2.3)
    • 370-7786
    • CPU Fan/Heatsink
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3246
    • 0MB Motherboard, Tomatillo 2.3
    • 527-1087
    • 1.064GHz USIIIi
    n/a 375-3249 Motherboard w/ 2 × US IIIi 1GHz, 0MB
    (Tomatillo 2.3)
    • 370-7786
    • CPU Fan/Heatsink
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3246
    • 0MB Motherboard, Tomatillo 2.3
    • 527-1087
    • 1.064GHz USIIIi
    n/a 375-3344 Motherboard w/ 1 × US IIIi 1.336GHz, 0MB, RoHS:YL
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3325
    • 0MB Motherboard, Tomatillo 2.3, RoHS:YL
    • 527-1169
    • 1.336GHz US IIIi, RoHS:Y
    n/a 375-3345 Motherboard w/ 2 × US IIIi 1.336GHz, 0MB, RoHS:YL
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3325
    • 0MB Motherboard, Tomatillo 2.3, RoHS:YL
    • 527-1169
    • 1.336GHz US IIIi, RoHS:Y
    n/a 375-3465 Motherboard w/ 1 × US IIIi 1.336GHz, 0MB, RoHS:YL
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3459
    • 0MB Motherboard, Tomatillo 2.3, RoHS:YL
    n/a 375-3466 Motherboard w/ 2 × US IIIi 1.336GHz, 0MB, RoHS:YL
    • 371-0837
    • CPU Fan/Heatsink, RoHS:Y
    • 375-3459
    • 0MB Motherboard, Tomatillo 2.3, RoHS:YL
    • 527-1277
    • 1.386GHz US IIIi, RoHS:Y

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
