Tape Drives
|
|||||||||||||
LTO-2 | LTO2 SCSI Tape Drive, Half Height, RoHS:Y | ||||||||||||
LTO-3 | LTO3 SCSI Tape Drive, RoHS:Y | ||||||||||||
LTO-3 FC | LTO3 FC Tape Drive, RoHS:Y | ||||||||||||
LTO4 | LTO4 SAS Tape Drive, Half Height, RoHS:Y | ||||||||||||
LTO4 | LTO4 SCSI Tape Drive, RoHS:Y | ||||||||||||
LTO4 FC | LTO4 FC Tape Drive, RoHS:Y | ||||||||||||
The Sun StorageTek SL48 Tape Library, RoHS:YL:
|
|||||||||||||
Environment
|
|||||||||||||
AC Voltage Range | 88 to 264 VAC, single phase | ||||||||||||
Frequency | 47 to 63 Hz | ||||||||||||
Input Power, Maximum | 312 watts maximum (max drive load) | ||||||||||||
Maximum AC Inrush (per psu) | 100 to 240 VAC, 50 to 60 Hz, 2.0 Amperes | ||||||||||||
Power Consumption |
Typical: Maximum: |
||||||||||||
Temperature & Humidity |
Operating: 5° C to 35° C (41° F to 95° F), 20% to 80% noncondensing Nonoperating: -30° C to 60° C (-22° F to 140° F), 10% to 90% noncondensing |
||||||||||||
Temperature Shock Immunity | Maximum rate of change 10° C per hour | ||||||||||||
Altitude |
Operating: 3048 m (10,000 ft.) Nonoperating: 10,675 m (35,023 ft.) |
||||||||||||
Dust Concentration | Less than 200 microgram/cubic meter | ||||||||||||
Shock |
Operating:4g 11ms pulse (+/-) half sine Nonoperating:152 cm/sec (60 inches/sec) |
||||||||||||
Vibration |
Operating:0.25 gRMS, 15 minutes per axis (random) 0.25 gRMS, 1.0 octave per minute, 0-300-0Hz, 5 cycles, 3 axis (swept sine) Nonoperating:Ten sweeps, 5 to 300Hz, at 0.5G peak-to-peak. |
||||||||||||
Dimensions and Weights
|
|||||||||||||
Height | 174 mm (6.85 in.) 344 mm (13.54 in.) shipping |
||||||||||||
Width | 445 mm (17.5 in.) 596 mm (23.46 in.) shipping |
||||||||||||
Depth | 776 mm (30.55 in.) 994 mm (39.13 in.) shipping |
||||||||||||
Weight | 20.6 kg (45.32 lb.) 33.2 kg (73.04 lb.) shipping |
Cables | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
X-SL24-48-SAS-CBLZ | 530-4045 | 2M SAS Cable, RoHS:Y | ||
X3830A-Z | 530-3626 | External SCSI Cable, HD68 to VHDC, 4M, RoHS:Y | ||
X3832A-Z | 530-3625 | External SCSI Cable, HD68 to VHDCI, 2M, RoHS:Y | ||
n/a | n/a | SCSI Terminator 252000226830 |
Fibre Channel | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
SG-XPCI1FC-EM4-Z | 375-3398 | 4Gb PCI-X Single FC Host Adapter, RoHS:Y | ||
SG-XPCI1FC-QF4 | 375-3354 | 4Gb PCI-X Single FC Host Adapter, RoHS:Y | ||
SG-XPCI2FC-EM4-Z | 375-3399 | 4Gb PCI-X Dual FC Host Adapter, RoHS:Y | ||
SG-XPCI2FC-QF4 | 375-3294 | 4Gb PCI-X Dual FC Host Adapter, RoHS:Y | ||
SG-XPCIE1FC-EM4 | 375-3396 | 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y | ||
SG-XPCIE1FC-EM8-Z | 371-4295 | 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y | ||
SG-XPCIE1FC-QF4 | 375-3355 | 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y | ||
SG-XPCIE1FC-QF8-Z | 371-4324 | 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y | ||
SG-XPCIE2FC-EB4-Z | 375-3386 | 4Gb/sec PCI Express Dual Fibre Channel ExpressModule Host Adapter, Emulex, RoHS:Y | ||
SG-XPCIE2FC-EM4 | 375-3397 | 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y | ||
SG-XPCIE2FC-EM8-Z | 371-4306 | 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y | ||
SG-XPCIE2FC-QB4-Z | 375-3384 | 4Gb/sec PCI Express Dual Fibre Channel ExpressModule Host Adapter, QLogic, RoHS:Y | ||
SG-XPCIE2FC-QF4 | 375-3356 | 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y | ||
SG-XPCIE2FC-QF8-Z | 371-4325 | 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y | ||
SG-XPCIEFCGBE-E8-Z | 371-4666 | 8Gb/sec PCI Express Dual Fibre Channel ExpressModule Host Adapter, Emulex, RoHS:Y | ||
SG-XPCIEFCGBE-Q8-Z | 371-4522 | 8Gb/sec PCI Express Dual Fibre Channel ExpressModule Host Adapter, QLogic, RoHS:Y | ||
SG-XPCI1FC-EM2 | 375-3304 | 2Gb PCI-X Single FC Host Adapter, RoHS:Y | ||
SG-XPCI1FC-QF2 | 375-3102 | 2Gb PCI Single FC Host Adapter | ||
SG-XPCI1FC-QL2 | 375-3383 | 2Gb PCI-X Single FC Host Adapter, RoHS:Y | ||
SG-XPCI1FC-QLC-Z | 375-3364 | Entry-Level 2Gb PCI-X Single FC Host Adapter, RoHS:Y | ||
SG-XPCI2FC-EM2 | 375-3305 | 2Gb PCI-X Dual FC Host Adapter, RoHS:Y | ||
SG-XPCI2FC-QF2-Z | 375-3363 | 2Gb PCI Dual FC Host Adapter, RoHS:Y | ||
|
|
Miscellaneous | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
XSL48-LHMAG-3MS-Z | 380-1569 | Left Side 3-Mail Slot Magazine, RoHS:Y | ||
XSL48-LHMAG-Z | 380-1568 | Left Side No Mail Slot Magazine, RoHS:Y | ||
XSL48-TBL-KIT-Z | 380-1570 | Tabletop Conversion Kit, RoHS:Y | ||
XSLX-LHMAG-1MS-Z | 380-1562 | Left Side 1-Mail Slot Magazine, RoHS:Y | ||
XSLX-RH-MAG-Z | 380-1561 | Right Side 12-Slot Magazine, RoHS:Y | ||
n/a | 380-1567 | Sun SL48 Chassis FRU w/o Tape Drive | ||
n/a | 380-1577 | OEM SL48 Chassis FRU w/o Tape Drive, RoHS:Y |
Power | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
XSL48-PWR-Z | 380-1571 | Power Supply, RoHS:Y |
Removable Media | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
LTO4-HP4FC-SL2-4Z | 380-1590 | LTO4 FC Tape Drive, RoHS:Y | ||
LTO4-HPSC-SL24-48Z | 380-1589 | LTO4 SCSI Tape Drive, RoHS:Y | ||
LTO4H-HPSAS-SLXX-Z | 380-1601 | LTO4 HH SAS Tape Drive, RoHS:Y | ||
LTO4H-HPSC-SLXX-Z | 380-1592 | LTO4 HH SCSI Tape Drive, RoHS:Y | ||
LTO5-HP8FC-SLXX-Z | 380-1643 | LTO5 FC Tape Drive, RoHS:Y | ||
LTO5H-HPSAS-SLXX-Z | 380-1644 | LTO5 HH SAS Tape Drive, RoHS:Y | ||
LTO2HH-HPSC-SL2-4Z | 380-1566 | LTO2 SCSI Tape Drive, Half Height, RoHS:Y | ||
LTO3-HP4FC-SL2-4Z | 380-1565 | LTO3 FC Tape Drive, RoHS:Y | ||
LTO3-HPSC-SL24-48Z | 380-1564 | LTO3 SCSI Tape Drive, RoHS:Y | ||
LTO3HH-HPSA-SL2-4Z | 380-1593 | LTO3 SAS Tape Drive, Half Height, RoHS:Y | ||
LTO3HH-HPSC-SL2-4Z | 380-1587 | LTO3 SCSI Tape Drive, Half Height, RoHS:Y |
SCSI | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
SG-XPCI8SAS-E-Z | 375-3488 | 3Gb PCI-X SAS 8-Port Host Adapter, RoHS:Y | ||
SG-XPCIE2SCSIU320Z | 375-3357 | Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y | ||
SG-XPCIE8SAS-E-Z | 375-3487 | PCI Express 8-Port Host Adapter, RoHS:Y | ||
SG-XPCIE8SAS-EB-Z | 375-3486 | Sun StorageTek SAS Host Bus Adapter PCI Express ExpressModule, RoHS:Y | ||
SGXPCI1SCSILM320-Z | 375-3366 | PCI Single Ultra320 SCSI Adapter | ||
SGXPCI2SCSILM320-Z | 375-3365 | PCI Dual Ultra320 SCSI Adapter, RoHS:YL | ||
X6758A | 375-3057 | PCI Dual Ultra3 SCSI Host Adapter (LVD) |
System Controller | ||||
---|---|---|---|---|
Option # | Manufacturing Part # |
Description | ||
n/a | 380-1572 | Controller Board, RoHS:Y | ||
n/a | 380-1581 | OEM SL48 Controller Board, RoHS:Y |
