Oracle Sun Netra X4200 M2 DC Power Telco NEBS SERVER
REQUEST A PRICE QUOTE:
With up to two Dual-Core or Quad-Core AMD Opteron processors, the Sun Netra X4200 M2 server packs massive compute power into its less-than-20 in.-deep 2U enclosure. Its high compute density and energy-efficient processors can help relieve space, power, and cooling constraints in today’s infrastructures and data centers.
The carrier-grade Sun Netra X4200 M2 server offers flexibility and choice. It runs both 32-bit and 64-bit applications on multiple operating systems, with either two or four internal hard drives to maximize storage capacity. In addition to running Oracle’s Solaris operating system, the server also provides support for Linux and Windows Server 2003, providing customers with unmatched agility, efficiency, and investment protection. The Sun Netra X4200 M2 server also integrates four Gigabit Ethernet ports to enable connectivity for high-speed, high-bandwidth networking.
As with other Sun Netra servers, the Sun Netra X4200 M2 server is a ruggedized NEBS Level 3-certified and ETSI-compliant server, making it ideal for the most demanding applications in the toughest environments. System uptime is also enhanced by redundant, hot-swappable AC/DC power supplies and hot-pluggable hard disk drives. Additionally, the Sun Netra X4200 M2 server comes with ILOM, enabling simple remote monitoring and management from anywhere on the network.
| Processor | |
| Number | Up to 2 Dual-core |
| Architecture | Type: AMD Opteron Processor model 2214 HE embedded-class (2214-2.2GHz) |
| Cache memory | 1 MB Level 2 Cache per core |
| Main Memory | |
| Capacities |
DIMM slots per CPU socket: 4 DIMM slots per System Board: 8 DIMM type: DDR2-667 registered ECC DIMMs (128-bit plus ECC databus) DIMM size: 1-GB, 2-GB or 4-GB Maximum capacity: 32 GB (max 16GB for single processor systems) |
| Standard Integrated Interfaces | |
| Network | Four 10/100/1000Base-T Ethernet ports |
| Network Management | One 10/100Base-T Ethernet port |
| Serial Management | One TIA/EIA-232-F asynchronous RJ45 port |
| SAS | Four-Channel SAS Interface, internal access only |
| USB (2.0) |
Rear: 2 (500 mA=max output supply current of each USB port) |
| Video | One VGA Video port (HD-15) |
| Alarms | Four DB-15 dry contact (critical, major, minor and user) |
| Expansion Bus | Three full-height internal 64-bit 133MHz PCI-X slots
One internal x8 PCI-Express MD2 low profile slot |
| Internal Mass Storage | |
| Option 1 | DVD, up to two 146GB 2.5in 10K RPM SAS disks, maximum capacity 292 GB |
| Option 2 | No DVD, Up to four 146GB 2.5in 10K RPM SAS disks, maximum capacity 584 GB |
| DVD-ROM | One Slimline DVD/RW |
| NOTE: A two-disk Netra X4200 M2 chassis with DVD-ROM (or w/out DVD-ROM) cannot be field converted to a four-disk Netra X4200 M2, or vice versa. | |
| Power Supplies | |
| Two 500W (1+1) hot-swappable AC or DC Note: To ensure redundant operation of the power supplies, the two power inputs should be connected to separate power sources. |
|
| Operating input voltage range | AC=100-240 VAC, 50-60 Hz DC=-48VDC or -60VDC (nominal) / -40VDC – -75VDC (range) |
| Max operating input current | AC=6.4A at 100-120 VAC / 3.2A at 200-240 VAC DC=12.7A at -48VDC / 10.2A at -60VDC |
| Max heat dissipation | AC=2150 BTU/hr DC=2085 BTU/hr |
| Nominal Power | AC & DC=Estimated 475 W |
| Maximum Power | 550 W |
| Environment | |
| Temperature |
Operating: 5° C to 40° C (41° F to 104° F)/Short term: 5° C to 55° C (23° F to 131° F) Nonoperating: -40° C to 70° C (-40° F to 158° F) Storage: 40° C to -70° C (-40° F to 158° F) |
| Humidity |
Operating: 5% to 85% relative humidity noncondensing, max wet bulb. Short term: 5% to 90% relative humidity noncondensing, but not to exceed 0.024kg water/kg dry air (0.053 lbs. water 2.205 lb. dry air) Nonoperating: up to 93% relative humidity noncondensing, 38° C (100.4° F) max wet bulb |
| Altitude |
Operating: up to 3,000m (9,850 ft.) @40° C (104° F) Nonoperating: up to 12,000m (40,000 ft.) |
| Acoustic noise | Operating/Idling Acoustic Noise 7.0B (LwAd, 1B=10dB) |
|
Regulations Meets or exceeds the following requirements: |
|
| RoHS Compliance Level | RoHS:YL |
| Safety | UL/CSA-60950-1, EN60950-1, IEC60950-1 CB Scheme with all country deviations, IEC825-1, 2, and CFR21 part 1040, CNS14336, GB4943 |
| RFI/EMC | EN55022/CISPR22 Class A, FCC CFR47 Part 15 Class A, EN61000-3-2, EN61000-3-3 ICES-003 Class A, VCCI Class A, AS/NZ 3548 Class A, CNS13438 Class A, KSC 5858 Class A, GB9254 Class A, GB17625.1 |
| Immunity | EN55024/CISPR24 IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11 |
| Telecommunications | EN 300 386, Telecordia SR 3580 NEBS Level 3 |
| Regulatory Markings (Pending) | CE, FCC, ICES-003, C-tick, VCCI, GOST-R, BSMI, MIC, UL/cUL, UL/DEMKO/GS, UL/S-mark, CCC |
| ETSI | EN 300 019-2-1,2,3, Class 1.2, 2.3, 3.1E – Except -5C cold start – Except condensing humidity – Except rain |
| Seismic | GR-63-CORE requirements for earthquake zone 4 |
| Dimensions and Weight | |
| Height | 89 mm (3.5 in.) 2 RU |
| Width | 442 mm (17.4 in.) including bezel / 424 mm (16.7 in.) not including bezel |
| Depth | 508 mm (20 in.) max depth / 483 mm (19 in.) to the connector plane |
| Weight | Approximate (without PCI cards or rack mounts) 16 kg (35 lb.) 2 disk version 17 kg (37.2 lb.) 4 disk version |
| CPU Module | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| 4232A-Z | 310-0102 | Heatsink, RoHS:Y | ||
| 371-2481 | HyperTransport Termination Adapter, RoHS:Y | |||
| X4351A-Z | 371-2630 | 2.2GHz CPU, Next-Generation AMD Opteron 2214HE, F3 Stepping, 68W, RoHS:Y | ||
|
|
|||
| X5339A-Z | 310-0049 | G751 Thermal Grease Syringe, RoHS:Y | ||
| 371-4305 | 1.8GHz CPU, AMD Opteron Quad-Core 23HF HE, B3 Stepping, 79W, RoHS:Y | |||
| Cables | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X311L | Localized Power Cord Kit – North America/Asia, RoHS:Y | |||
| 180-1097 | IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y | |||
| X312E | Localized Power Code Kit – China, RoHS:Y | |||
| 180-1982 | IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y | |||
| X312F | Localized Power Cord Kit – Argentina, RoHS:Y | |||
| 180-1999 | IEC 320 C13 to IRAM 2073 – 10A/250V 2.5M Black, RoHS:Y | |||
| X312G | Localized Power Cord Kit – Korea, RoHS:Y | |||
| 180-1662 | IEC 320 C13 to KSC 8305 – 15A/250V 2.5M Black, RoHS:Y | |||
| X312L | Localized Power Cord Kit – Continental Europe, RoHS:Y | |||
| 180-1993 | IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y | |||
| X314L | Localized Power Cord Kit – Swiss, RoHS:Y | |||
| 180-1994 | IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y | |||
| X317L | Localized Power Cord Kit – U.K., RoHS:Y | |||
| 180-1997 | IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y | |||
| X332A | Localized Power Cord Kit – Taiwan, RoHS:Y | |||
| 180-2121 | IEC 320 C13 to NEMA 5-15P – 10A/125V 2.5M Black, RoHS:Y | |||
| X383L | Localized Power Cord Kit – Danish, RoHS:Y | |||
| 180-1995 | IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y | |||
| X384L | Localized Power Cord Kit – Italian, RoHS:Y | |||
| 180-1996 | IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y | |||
| X386L | Localized Power Cord Kit – Australian, RoHS:Y | |||
| 180-1998 | IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y | |||
| n/a | 371-2638 | PCI Express Cable Kit Assembly, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
| n/a | 530-3100 | RJ45F to DB9F Adapter, RoHS:Y | ||
| Communication | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X6000A | 375-3424 | PCI Express Sun Crypto Accelerator 6000, RoHS:Y | ||
| X1333A-4 | 375-3418 | Infiniband PCI-X Card, RoHS:YL | ||
| n/a | 371-2877 | Telco Alarm Board, RoHS:YL | ||
| Disk Backplane | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 371-2556 | 2 Disk Slot Mass Storage Assembly with Flex Cable, RoHS:YL | ||
|
|
|||
|
|
|||
|
|
|||
| n/a | 371-2558 | 4 Disk Slot Mass Storage Assembly with Flex Cable, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
| n/a | 371-4728 | 2 Disk Slot SATA Mass Storage Assembly with Flex Cable, RoHS:YL | ||
|
|
|||
|
|
|||
|
|
|||
| Disks | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| XRA-SS2ND-300G10K | 540-7867 | 300GB – 10000 RPM SAS, NEBS Compliant Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y | ||
|
|
|||
|
|
|||
| XRA-SS2ND-146G10KZ | 540-7152 | 146GB – 10000 RPM SAS, NEBS Compliant Disk Assembly with 1 of the following disks and brackets, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| XRB-SS2ND-146G10K | 540-7866 | 146GB – 10000 RPM SAS, NEBS Compliant Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
| Ethernet | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X1027A-Z | 501-7283 | PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y | ||
| X4151A-2 | 501-7430 | GigaSwift Ethernet MMF (GFS), RoHS:Y | ||
| X4445A | 501-6738 | Quad GigaSwift PCI-X Ethernet (QGE-X), RoHS:Y | ||
| X4447A-Z | 511-1422 | PCI Express Quad Gigabit Ethernet UTP, RoHS:Y | ||
|
|
|||
| 560-2884 | Ship Kit for Gigabit Ethernet options | |||
|
|
|||
| X7280A-2 | 371-0905 | PCI Express Dual Gigabit Ethernet UTP, RoHS:Y | ||
| X7281A-2 | 371-0904 | PCI Express Dual Gigabit Ethernet MMF, RoHS:Y | ||
| X7285A | 371-0911 | Low Profile PCI-X Dual Gigabit Ethernet UTP, RoHS:Y | ||
| X7286A | 371-0912 | Low Profile PCI-X Single Gigabit Ethernet MMF, RoHS:Y | ||
| n/a | 375-3481 | PCI Express Quad Gigabit Ethernet UTP, RoHS:Y | ||
| n/a | 501-7606 | PCI Express Quad Gigabit Ethernet UTP, RoHS:Y | ||
|
|
|||
|
|
|||
| Fan | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 371-1955 | HDD Fan Tray Assembly, RoHS:Y | ||
| n/a | 371-2736 | System Fans Assembly, RoHS:Y | ||
| Fibre Channel | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| SG-XPCI2FC-EM4-Z | 375-3399 | 4Gb PCI-X Dual FC Host Adapter, RoHS:Y | ||
| SG-XPCI2FC-QF4 | 375-3294 | 4Gb PCI-X Dual FC Host Adapter, RoHS:Y | ||
| SG-XPCI2FC-QF2-Z | 375-3363 | 2Gb PCI Dual FC Host Adapter, RoHS:Y | ||
|
|
|||
| I/O | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | F371-2368 | PCI Assembly, RoHS:YL | ||
|
|
|||
|
|
|||
| Memory | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X4226A-C | 4GB (2 × 2GB DDR2-667 DIMM), Memory Kit, RoHS:YL | |||
| 371-4158 | 2GB DDR2-667 Registered DIMM, 1-Rank/512 Mbit SDRAM, RoHS:Y | |||
| X4233A | 8GB (2 × 4GB DDR2-667 DIMM) Option for Dual-Core and Quad-Core CPUs, RoHS:YL | |||
| 371-4322 | 4GB DDR2-667 DIMM, RoHS:Y | |||
| X4225A-Z | 2GB (2 × 1GB DDR2-667 DIMM) Option, RoHS:YL | |||
| 371-1919 | 1GB DDR2-667 DIMM, RoHS:Y | |||
| X4226A-Z | 4GB (2 × 2GB DDR2-667 DIMM) Option, RoHS:YL | |||
| 371-1920 | 2GB DDR2-667 DIMM, RoHS:Y | |||
| X4227A-Z | 8GB (2 × 4GB DDR2-667 DIMM) Option, RoHS:YL | |||
| 371-2205 | 4GB DDR2-667 DIMM, RoHS:Y | |||
| n/a | F540-7116 | 2GB (2 × 1GB DDR2-667 DIMM), RoHS:Y | ||
|
|
|||
| n/a | F540-7117 | 4GB (2 × 2GB DDR2-667 DIMM), RoHS:Y | ||
|
|
|||
| n/a | F540-7118 | 8GB (2 × 4GB DDR2-667 DIMM), RoHS:Y | ||
|
|
|||
| n/a | F540-7795 | 8GB (2 × 4GB DDR2-667 DIMM) for Quad-Core CPUs, RoHS:Y | ||
|
|
|||
| n/a | F540-7849 | 4GB (2 × 2GB DDR2-667 DIMM), RoHS:Y | ||
|
|
|||
| Miscellaneous | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X4234A-Z | 594-3954 | Air Filter 10-Pack, RoHS:Y | ||
|
|
|||
| X4353A-Z | 594-4536 | Air Filter for 4 Hard Disk Drive Chassis, RoHS:Y | ||
|
|
|||
| X949A-4 | 594-2682 | Wago DC Connector Set (10 pack), RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
| n/a | 130-4361 | DC Connector, RoHS:Y | ||
| n/a | 230-1708 | DC Connector Strain Relief | ||
| n/a | 230-1711 | DC Connector Opening Lever | ||
| Power | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X8051A-Z | 300-2006 | DC -48VDC 550W Power Supply (Type D193), RoHS:YL | ||
| X8052A-Z | 300-1848 | 550 Watt, Type A214 Power Supply, RoHS:YL | ||
| n/a | 371-1098 | Power Distribution Board, RoHS:YL | ||
| Rack | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X2089A | 350-1387 | 19″ 2-post Slide Rail Kit, RoHS:Y | ||
| X7901A-4 | 371-1478 | 19″ 2-post Rackmount Kit, RoHS:Y | ||
| X7902A-4 | 371-1481 | 23″ 2-post Rackmount Kit, RoHS:Y | ||
| X7904A-4 | 371-1479 | 600mm x 600mm Rackmount Kit, RoHS:Y | ||
| X8099A-4 | 371-1480 | 19″ 4-post Slide Mount Kit, RoHS:Y | ||
| SG-XARY030A | 595-4706 | 72 inch Sun StorEdge Expansion Cabinet | ||
| Removable Media | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X4356A-Z | DVD-Writer/CD-Writer, RoHS:YL | |||
| 371-2261 | DVD-ROM / CD-ROM Drive Bezel, RoHS:Y | |||
| 540-7563 | DVD-Writer/CD-Writer, PATA, RoHS:Y | |||
|
|
|||
|
|
|||
| X4358A-Z | SATA DVD-Writer/CD-Writer, RoHS:Y | |||
| 390-0443 | 8x SATA DVD-Writer/24x CD-Writer, RoHS:Y | |||
| X4352A-Z | 8× Slimline DVD-RW Drive Assembly, RoHS:YL | |||
| 390-0337 | 8x PATA DVD-Writer/24x CD-Writer, RoHS:Y | |||
| SCSI | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| SG-XPCI8SAS-E-Z | 375-3488 | 3Gb PCI-X SAS 8-Port Host Adapter, RoHS:Y | ||
| SG-XPCIE8SAS-E-Z | 375-3487 | PCI Express 8-Port Host Adapter, RoHS:Y | ||
| SGXPCI1SCSILM320-Z | 375-3366 | PCI Single Ultra320 SCSI Adapter | ||
| SGXPCI2SCSILM320-Z | 375-3365 | PCI Dual Ultra320 SCSI Adapter, RoHS:YL | ||
| System Board | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 501-7590 | System Board, RoHS:YL | ||
|
|
|||
| n/a | 501-7989 | System Board, RoHS:YL | ||
|
|
|||
| System Service Processor | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 371-2370 | Service Processor (GSP), RoHS:YL | ||
