Oracle Sun BLADE X8450 SERVER MODULE

Oracle Sun BLADE X8450 SERVER MODULE Oracle Sun BLADE X8450 SERVER MODULE SUN BLADE X8450 SERVER MODULE FULL

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*



    Processor
    Number Up to four.
    Architecture Type:Quad-core, Intel Xeon series processors.
    • Model/Speed: E7320, Quad Core, 2.13 GHz, 80W
    • Model/Speed: E7340, Quad Core, 2.40 GHz, 80W
    • Model/Speed: L7345, Quad Core, 1.86 GHz, 50W
    Main Memory
    Memory Type Fully Buffered DDR2-667MHz / PC2-5300 ECC Registered DIMMs.
    Capacities
    • Maximum memory: 128GB.
    • Total DIMM slots: 32.
    • DIMM sizes: 1GB, 2GB and 4GB.
    Optional Storage
    Disk
    • Up to two optional, front accessible, hot swappable, hot pluggable, disk drives per blade. Onboard LSI 1064 disk controller.
    • Mixing disk types (i.e. one SAS disk and one SATA disk) on same X8450 Server Module is not supported.
    Drive Type Density Speed Form Factor RAID
    SAS 146 GB 10,000 RPM 2.5″ RAID 0 or 1
    SAS 73 GB 10,000 RPM 2.5″ RAID 0 or 1
    SAS 73 GB 15,000 RPM 2.5″ RAID 0 or 1
    SATA 200 GB 5,400 RPM 2.5″ RAID 0 or 1
    Solid State Drives
    • Up to two 32GB solid state drives
    Management Environment
    Service Processor (SP)
    • The Sun Blade X6450’s SP is installed with Integrated Lights-Out Manager (LOM), IPMI 2.0-compatible software. Connectivity is provided by the NET MGT DB9 serial port connector.
    Standard Integrated Interfaces
    USB 2 USB 2.0 Ports with front-accessible connectors.
    Graphics Embedded graphics using an ATI ES100 video controller. 15-pin VGA connector.
    Serial 1 RS-232 Serial Port DB9 connector.
    Ethernet Two 10/100/1000Base-T Ethernet ports routed through midplane to 2 NEM slots.
    PCI Interfaces with the Sun Blade Modular System (chassis)
    • I/O is offered in two form factors:
      • PCI Express ExpressModules (EM)
        and
      • PCI Express Network Express Modules (NEM).
    • Each Sun Blade X8450 has four, PCI Express links allocated to:
      • Two EMs (X8)
        and
      • Two NEMs (X4).
    • Each NEM has one link assigned to each server module. All server modules share the NEM. For example, Blade 0 has access to NEM 0/slot 0, and NEM 1/slot 0. Blade 1 to NEM 0/slot 1 and NEM 1/slot 1, etc.
    • EM slots are not shared between server modules. Each EM slot is specific to one server module.
    Regulations
    RoHS Compliance Level RoHS:YL
    Dimensions and Weights
    Height 42.67mm (1.68 in).
    Width 499.36mm (19.66 in).
    Depth 465.58mm (18.33 in).
    Weight 28 lbs fully configured. 24 lbs empty.
    Blade
    Option # Manufacturing
    Part #    		 Description
    X8450-44L1860-82 594-5308 Sun Blade X8450 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs, RoHS:YL
    • 310-0146
    • CPU Heatsink, RoHS:Y
    • 371-3456
    • 1.86 GHz CPU, Xeon L7345 Quad Core, 50W, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 541-2538
    • 0MB Sun Blade X8450 Server Module Assembly, RoHS:Y
    X8450-44M2130-82 594-5309 Sun Blade X8450 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs, RoHS:YL
    • 310-0146
    • CPU Heatsink, RoHS:Y
    • 371-3457
    • 2.13 GHz CPU, Xeon E7320 Quad Core, 80W, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 541-2538
    • 0MB Sun Blade X8450 Server Module Assembly, RoHS:Y
    X8450-44M2400-B2 594-5310 Sun Blade X8450 Server Module with 32GB Memory (16 × 2GB) and 4 CPUs, RoHS:YL
    • 310-0146
    • CPU Heatsink, RoHS:Y
    • 371-3458
    • 2.40 GHz CPU, Xeon E7340 Quad Core, 80W, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 541-2538
    • 0MB Sun Blade X8450 Server Module Assembly, RoHS:Y
    n/a F541-2538 0MB Sun Blade X8450 Server Module Assembly, RoHS:Y
    • 150-3993
    • Panasonic BR2032 Battery, RoHS:Y
    • 250-1802
    • Alcohol Wipe Cleaner
    • 310-0065
    • Thermal Grease, Syringe, RoHS:Y
    • 501-7870
    • SAS Backplane, RoHS:Y
    • 501-7871
    • Service Processor Mezzanine, RoHS:Y
    • 530-3938
    • Disk Data Cable, RoHS:Y
    • 530-3939
    • Disk Power Cable, RoHS:Y
    CPU Module
    Option # Manufacturing
    Part #    		 Description
    X8450-AA-AIRBAF Air Baffle and Dust Cover Kit, RoHS:YL
    541-2921 Air Baffle and Dust Cover Kit, RoHS:Y
    X8450-X-22M2930 2 × 2.93 GHz CPU, Xeon E7220 Dual Core, 80W, RoHS:YL
    310-0146 CPU Heatsink, RoHS:Y
    371-3455 2.93 GHz CPU, Xeon E7220, Dual Core, 80W, RoHS:Y
    X8450-X-24L1860 2 × 1.86 GHz CPU, Xeon L7345 Quad Core, 50W, RoHS:Y
    310-0146 CPU Heatsink, RoHS:Y
    371-3456 1.86 GHz CPU, Xeon L7345 Quad Core, 50W, RoHS:Y
    X8450-X-24M2130 2 × 2.13 GHz CPU, Xeon E7320 Quad Core, 80W, RoHS:YL
    310-0146 CPU Heatsink, RoHS:Y
    371-3457 2.13 GHz CPU, Xeon E7320 Quad Core, 80W, RoHS:Y
    X8450-X-24M2400 2 × 2.40 GHz CPU, Xeon E7340 Quad Core, 80W, RoHS:YL
    310-0146 CPU Heatsink, RoHS:Y
    371-3458 2.40 GHz CPU, Xeon E7340 Quad Core, 80W, RoHS:Y
    n/a 310-0065 Thermal Grease, Syringe, RoHS:Y
    n/a F371-3455 2.93 GHz CPU, Xeon E7220, Dual Core, 80W, RoHS:Y
    • 371-3455
    • 2.93 GHz CPU, Xeon E7220, Dual Core, 80W, RoHS:Y
    n/a F371-3456 1.86 GHz CPU, Xeon L7345 Quad Core, 50W, RoHS:Y
    • 371-3456
    • 1.86 GHz CPU, Xeon L7345 Quad Core, 50W, RoHS:Y
    n/a F371-3457 2.13 GHz CPU, Xeon E7320 Quad Core, 80W, RoHS:Y
    • 371-3457
    • 2.13 GHz CPU, Xeon E7320 Quad Core, 80W, RoHS:Y
    n/a F371-3458 2.40 GHz CPU, Xeon E7340 Quad Core, 80W, RoHS:Y
    • 371-3458
    • 2.40 GHz CPU, Xeon E7340 Quad Core, 80W, RoHS:Y
    Cables
    Option # Manufacturing
    Part #    		 Description
    n/a 530-3938 Disk Data Cable, RoHS:Y
    n/a 530-3939 Disk Power Cable, RoHS:Y
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRA-SS2CF-146G10K 540-7355 146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRA-SS2CF-73G10K 540-7354 73GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0374
    • Fujitsu MBB2073RC [MBB2073RCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0376
    • Hitachi HUC101473CSS300 [H101473SCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRA-SS2CF-73G15K 540-7361 73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0382
    • Seagate ST973451SS [ST973451SSUN72G]
      (73GB – 15000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRA-ST2CF-200G5K 540-7555 200GB – 5400 RPL SATA Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0407
    • Fujitsu MHY2200BS [MHY2200BSSUN200G]
      (200GB – 5400 RPM – SATA Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    Memory
    Option # Manufacturing
    Part #    		 Description
    X4400A 540-7251 2 GB (2 × 1GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2654
    • 1 GB PC2-5300 DDR2 DIMM, RoHS:Y
    X4401A 540-7252 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    X4402A 540-7253 8 GB (2 × 4GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2656
    • 4 GB PC2-5300 DDR2 DIMM, RoHS:Y
