Blade T6320 Server Specs and Information:

Sun Blade T6320 Server Processor

Number

Single Socket.

Architecture

Type:UltraSPARC T2 processor with CoolThreads technology.

Model/Speed:4-Core, 1.2 GHz
Model/Speed:6-Core, 1.2 GHz
Model/Speed:8-Core, 1.2 GHz
Model/Speed:8-Core, 1.4 GHz
Model/Speed:8-Core, 1.6 GHz

Cache Memory

4 MB L2 Cache.

Blade T6320 Server Memory

Memory Type

FB DDR2 ECC Registered DIMMs.

Capacities

Maximum memory: 128GB.
Total DIMM slots:16.
DIMM sizes: 1GB, 2GB, 4GB and 8GB.

Optional Storage for Sun T6320 Server

Internal Disk

Up to four optional, hot swappable, hot pluggable, small form factor (SFF) SAS drive bays per blade.

Drive Type	Density	Speed	Form Factor	RAID
SATA	200 GB	5,400 RPM	SFF 2.5″	RAID 0 or 1
SAS	300 GB	10,000 RPM	SFF 2.5″	RAID 0 or 1
SAS	146 GB	10,000 RPM	SFF 2.5″	RAID 0 or 1
SAS	73 GB	10,000 RPM	SFF 2.5″	RAID 0 or 1
SAS	73 GB	15,000 RPM	SFF 2.5″	RAID 0 or 1

Solid State Drives

Up to 4 32GB solid state drives

Management Environment

Sun Blade Server Module Service Processor (SP)

The SP card is installed with Integrated Lights-Out Manager (ILOM) software.
ILOM can be accessed via a Dongle cable assembly connection to the Universal Connector Port (UCP) on the front of the Sun Blade T6320.
There are 2 different Dongle cables. A three connector and a four connector.
To connect to ILOM using the four connector dongle cable, use the DB-9 serial connector.
To connect to ILOM using the three connector dongle cable, use the RJ-45 serial connector.
The Dongle cable assembly is provided with the Sun Blade 6000 and Sun Blade 6048 chassis.
Support for Sun Management Center with add-on software.
Compatibility for third-party SNMP system managers with requirements for SNMP (v1, v2C, v3).
Graphical user interface and comprehensive command line interface (CLI) to emulate Advanced Lights Out (ALOM).

Standard Integrated Interfaces

Universal Connector Port (UCP)

Provides Serial Management connection to ILOM via Dongle cable. Also provides dual USB ports for keyboard, mouse or storage.

Network management

Two 10/100Base-T Ethernet port connections via midplane to the Chassis Monitoring Module (CMM). Only one connection (NET 0) is used.

Ethernet

Two 10/100/1000Base-T Ethernet ports routed through midplane to 2 NEM slots.

PCI Interfaces with the Sun Blade Modular System (chassis)

I/O is offered in two form factors:
- PCI Express ExpressModules (EM)
  and
- PCI Express Network Express Modules (NEM).
Each Sun Blade T6320 has four, x8 lane PCI Express links allocated to:
- Two EMs
  and
- Two NEMs.
Each NEM has one link assigned to each server module. All server modules share the NEM. For example, Blade 0 has access to NEM 0/slot 0, and NEM 1/slot 0. Blade 1 to NEM 0/slot 1 and NEM 1/slot 1, etc.
EM slots are not shared between server modules. Each EM slot is specific to one server module.

Regulations
Meets or exceeds the following requirements:

Dimensions and Weights

Height

44.5mm (1.75 in).

Width

327.15mm (12.88 in).

Depth

496.82 (19.56 in).

Weigh (empty ? no disks or memory)t

6.68 kg (14.7 lbs).

Weight (fully configured)

7.86 kg (17.3 lbs).

Batteries
Option #	Manufacturing Part #	Description	Previous Part #
n/a	150-1204 [C]	3V Lithium Coin Cell Battery	n/a

Blade
Option #	Manufacturing Part #	Description	Previous Part #
X5710A [S]	594-4525	Sun Blade T6320 Server Module with 4GB Memory (4 × 1GB), and 1 CPU (1.2GHz, 4-core UltraSPARC T2)	n/a
	501-7821 [C]	RAID Expansion Module (REM)	n/a
	501-7822 [C]	Service Processor Assembly	n/a
	150-1204 [C]	3V Lithium Coin Cell Battery	n/a
	525-2515	IDPROM	n/a
	501-7952 [C]	1GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	541-2514 [C]	0MB, 4-Core, UltraSPARC T2, 1.2GHz CPU Assembly	n/a
	310-0112	Heat Sink	n/a
	501-7842	Blade Motherboard	n/a
	501-7843	2-Slot Disk Backplane	n/a
X5710B [S]	594-5666	Sun Blade T6320 Server Module with 4GB Memory (4 × 1GB), and 1 CPU (1.2GHz, 4-core UltraSPARC T2)	n/a
	510-1170 [C]	Service Processor Assembly	n/a
	511-1098 [C]	RAID 0/1 Expansion Module	n/a
	511-1264 [C]	1GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	541-2514 [C]	0MB, 4-Core, UltraSPARC T2, 1.2GHz CPU Assembly	n/a
	310-0112	Heat Sink	n/a
	501-7842	Blade Motherboard	n/a
	501-7843	2-Slot Disk Backplane	n/a
X5710C [S]	594-6075	Sun Blade T6320+ Server Module with 8GB Memory (4 × 2GB), and 1 CPU (1.2GHz, 4-core UltraSPARC T2)	n/a
	511-1098 [C]	RAID 0/1 Expansion Module	n/a
	511-1161 [C]	2GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	511-1304 [C]	Service Processor Assembly, Sun Blade T6320+	n/a
	150-1204 [C]	3V Lithium Coin Cell Battery	n/a
	525-2515	IDPROM	n/a
	541-3837 [C]	0MB, 4-Core, UltraSPARC T2, 1.2GHz CPU Assembly	n/a
	310-0241	Heat Sink	n/a
	501-7843	2-Slot Disk Backplane	n/a
	541-3841	Blade Motherboard, 1.2GHz	n/a
X5711A [S]	594-4526	Sun Blade T6320 Server Module with 16GB Memory (8 × 2GB), and 1 CPU (1.2GHz, 8-core UltraSPARC T2)	n/a
	501-7821 [C]	RAID Expansion Module (REM)	n/a
	501-7822 [C]	Service Processor Assembly	n/a
	150-1204 [C]	3V Lithium Coin Cell Battery	n/a
	525-2515	IDPROM	n/a
	501-7953 [C]	2GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	541-2515 [C]	0MB, 8-Core, UltraSPARC T2, 1.2GHz CPU Assembly	n/a
	501-7842	Blade Motherboard	n/a
	501-7843	2-Slot Disk Backplane	n/a
X5711B [S]	594-5667	Sun Blade T6320 Server Module with 16GB Memory (8 × 2GB), and 1 CPU (1.2GHz, 8-core UltraSPARC T2)	n/a
	510-1170 [C]	Service Processor Assembly	n/a
	511-1098 [C]	RAID 0/1 Expansion Module	n/a
	511-1161 [C]	2GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	541-2515 [C]	0MB, 8-Core, UltraSPARC T2, 1.2GHz CPU Assembly	n/a
	501-7842	Blade Motherboard	n/a
	501-7843	2-Slot Disk Backplane	n/a
X5712A [S]	594-4527	Sun Blade T6320 Server Module with 32GB Memory (16 × 2GB), and 1 CPU (1.2GHz, 8-core UltraSPARC T2)	n/a
	501-7821 [C]	RAID Expansion Module (REM)	n/a
	501-7822 [C]	Service Processor Assembly	n/a
	150-1204 [C]	3V Lithium Coin Cell Battery	n/a
	525-2515	IDPROM	n/a
	501-7953 [C]	2GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	541-2515 [C]	0MB, 8-Core, UltraSPARC T2, 1.2GHz CPU Assembly	n/a
	501-7842	Blade Motherboard	n/a
	501-7843	2-Slot Disk Backplane	n/a
X5712B [S]	594-5668	Sun Blade T6320 Server Module with 32GB Memory (16 × 2GB), and 1 CPU (1.2GHz, 8-core UltraSPARC T2)	n/a
	510-1170 [C]	Service Processor Assembly	n/a
	511-1098 [C]	RAID 0/1 Expansion Module	n/a
	511-1161 [C]	2GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	541-2515 [C]	0MB, 8-Core, UltraSPARC T2, 1.2GHz CPU Assembly	n/a
	501-7842	Blade Motherboard	n/a
	501-7843	2-Slot Disk Backplane	n/a
X5712C [S]	594-6076	Sun Blade T6320+ Server Module with 32GB Memory (16 × 2GB), and 1 CPU (1.4GHz,8-core UltraSPARC T2)	n/a
	511-1098 [C]	RAID 0/1 Expansion Module	n/a
	511-1161 [C]	2GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	511-1304 [C]	Service Processor Assembly, Sun Blade T6320+	n/a
	150-1204 [C]	3V Lithium Coin Cell Battery	n/a
	525-2515	IDPROM	n/a
	541-3838 [C]	0MB, 8-Core, UltraSPARC T2, 1.4GHz CPU Assembly	n/a
	310-0241	Heat Sink	n/a
	501-7843	2-Slot Disk Backplane	n/a
	541-3842	Blade Motherboard, 1.4GHz	n/a
X5713A [S]	594-4684	Sun Blade T6320 Server Module with 64GB Memory (16 × 4GB), and 1 CPU (1.4GHz, 8-core UltraSPARC T2)	n/a
	501-7821 [C]	RAID Expansion Module (REM)	n/a
	501-7822 [C]	Service Processor Assembly	n/a
	150-1204 [C]	3V Lithium Coin Cell Battery	n/a
	525-2515	IDPROM	n/a
	501-7954 [C]	4GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	541-2516 [C]	0MB, 8-Core, UltraSPARC T2, 1.4GHz CPU Assembly	n/a
	310-0112	Heat Sink	n/a
	501-7842	Blade Motherboard	n/a
	501-7843	2-Slot Disk Backplane	n/a
X5713B [S]	594-5669	Sun Blade T6320 Server Module with 64GB Memory (16 × 4GB), and 1 CPU (1.4GHz, 8-core UltraSPARC T2)	n/a
	501-7954 [C]	4GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	510-1170 [C]	Service Processor Assembly	n/a
	511-1098 [C]	RAID 0/1 Expansion Module	n/a
	541-2516 [C]	0MB, 8-Core, UltraSPARC T2, 1.4GHz CPU Assembly	n/a
	310-0112	Heat Sink	n/a
	501-7842	Blade Motherboard	n/a
	501-7843	2-Slot Disk Backplane	n/a
X5713C [S]	594-6077	Sun Blade T6320+ Server Module with 64GB Memory (16 × 4GB), and 1 CPU (1.6GHz, 8-core UltraSPARC T2)	n/a
	501-7954 [C]	4GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
	511-1098 [C]	RAID 0/1 Expansion Module	n/a
	511-1304 [C]	Service Processor Assembly, Sun Blade T6320+	n/a
	150-1204 [C]	3V Lithium Coin Cell Battery	n/a
	525-2515	IDPROM	n/a
	541-3839 [C]	0MB, 8-Core, UltraSPARC T2, 1.6GHz CPU Assembly	n/a
	310-0241	Heat Sink	n/a
	501-7843	2-Slot Disk Backplane	n/a
	541-3843	Blade Motherboard, 1.6GHz	n/a
n/a	541-2517 [C]	0MB, 6-Core, UltraSPARC T2, 1.2GHz CPU Assembly	n/a
	501-7842	Blade Motherboard	n/a
	501-7843	2-Slot Disk Backplane	n/a

Cables
Option #	Manufacturing Part #	Description	Previous Part #
X4622A [S]	Dongle II Cable Assembly for Universal Connector Port (UCP) with three connectors: 1 VGA HD15, 1 RJ45, 2×USB, and 1 DB9 to RJ45 Adapter
	530-3100	RJ45F to DB9F Adapter	n/a
	7046680 [C]	USB/VGA/RJ45 Dongle Cable Adapter	530-3936 [C]
n/a	530-3888	Hard Disk Drive Power Cable	n/a
n/a	530-3931 ¹⁰	Dual SAS Cable, Blue HDD0/Black HDD1, 320mm	n/a
n/a	530-3932 ¹¹	Dual SAS Cable, Blue HDD2/Black HDD3, 270mm	n/a
n/a	530-3936 [C]	USB/VGA/RJ45 Dongle Cable Adapter	n/a
n/a	530-3993	HDD Data Cable, 150mm	n/a
n/a	530-4047	SAS Cable, Blue HDD0, 290mm	n/a
n/a	530-4048	SAS Cable, Black HDD1, 320mm	n/a
n/a	530-4049	SAS Cable, Blue HDD2, 247mm	n/a
n/a	530-4050	SAS Cable, Black HDD3, 270mm	n/a

¹⁰ Replaced by single cables 530-4047 and 530-4048 in March 2008.
¹¹ Replaced by single cables 530-4049 and 530-4050 in March 2008.

Disks
Option #	Manufacturing Part #	Description	Previous Part #
XRA-SS2CF-146G10K [S]	540-7355 [C]	146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	390-0375	Fujitsu MBB2147RC [MBB2147RCSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRA-SS2CF-73G10K [S]	540-7354 [C]	73GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0285	Fujitsu MAY2073RC [MAY2073RCSUN72] (73GB – 10000 RPM – SAS Disk)	n/a
	390-0323	Seagate ST973402SS [ST973402SSUN72G] (73GB – 10000 RPM – SAS Disk)	n/a
	390-0374	Fujitsu MBB2073RC [MBB2073RCSUN72G] (73.4GB – 10000 RPM – SAS Disk)	n/a
	390-0376	Hitachi HUC101473CSS300 [H101473SCSUN72G] (73.4GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRA-SS2CF-73G15K [S]	540-7361 [C]	73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks	n/a
	390-0382	Seagate ST973451SS [ST973451SSUN72G] (73GB – 15000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRA-ST2CF-200G5K [S]	540-7555 [C]	200GB – 5400 RPL SATA Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0407	Fujitsu MHY2200BS [MHY2200BSSUN200G] (200GB – 5400 RPM – SATA Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRA-ST2CF-32G2SSD [S]	540-7841 [C]	32GB Solid State SATA Drive Assembly	n/a
	371-4196	Intel SSDSA2SH032G1SB [Inquiry Unknown] (32GB – 2.5″ Solid State – SATA Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRA-ST2CF-500G7K [S]	542-0184 [C]	500GB – 7200 RPM SATA Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0468	Seagate ST9500530NS [ST95000NSSUN500G] (500GB – 7200 RPM – SATA Disk)	n/a
	541-4199	Marlin Bracket	n/a
XRB-SS2CF-146G10K [S]	540-7868 [C]	146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	390-0448	Seagate ST9146803SS [ST914603SSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	390-0450	Hitachi HUC103014CSS600 [H103014SCSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
n/a	540-7869 [C]	300GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0449	Seagate ST9300603SS [ST930003SSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	390-0451	Hitachi HUC103030CSS600 [H103030SCSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a

Ethernet
Option #	Manufacturing Part #	Description	Previous Part #
X4822A [S]	501-7968 [C]	10-Gigabit XAUI Pass-Thru Fabric Expansion Module (FEM)	n/a
X4835A [S]	511-1495 [C]	Pass-Through Fabric Expansion Module (FEM)	511-1171 [C]
X4871A-Z [S]	7051229 [C]	Dual 10Gbps Ethernet Fabric Expansion Module (FEM)	375-3648 [C]
n/a	375-3648 [C]	Dual 10-Gigabit Ethernet Fabric Expansion Module (FEM)	n/a
n/a	511-1171 [C]	Pass-Through Fabric Expansion Module (FEM)	n/a

IDPROM
Socket	Manufacturing Part #	Component Type	Host ID
J1601	525-2515	SEEPROM 2x MAC	8xxxxxxx

Memory
Option #	Manufacturing Part #	Description	Previous Part #
X4200A [S]	2 GB (2 × 1GB DDR2 DIMMs)
X4200A [S]	501-7952 [C]	1GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
X4200AF [S]	2 GB (2 × 1GB DDR2 DIMMs)
X4200AF [S]	511-1264 [C]	1GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
X4203A [S]	4 GB (2 × 2GB DDR2 DIMMs)
X4203A [S]	501-7953 [C]	2GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
X4203AF [S]	4 GB (2 × 2GB DDR2 DIMMs)
X4203AF [S]	511-1161 [C]	2GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
X4204A [S]	8 GB (2 × 4GB DDR2 DIMMs)
X4204A [S]	501-7954 [C]	4GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
X4290AF [S]	16 GB (2 × 8GB DDR2 DIMMs)
X4290AF [S]	511-1262 [C]	8GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
n/a	7059409 [C]	2GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a
n/a	7059410 [C]	4GB DDR2-667/PC2-5300 1.8V FBDIMM	n/a

SCSI
Option #	Manufacturing Part #	Description	Previous Part #
SGX-SAS6-REM-Z [S]	7047855 [C]	6Gbps SAS-2 RAID Expansion Module (REM)	375-3643 [C]
X4601A [S]	501-7821 [C]	RAID Expansion Module (REM)	n/a
X4607A [S]	511-1098 [C]	RAID 0/1 Expansion Module	n/a
n/a	375-3643 [C]	6Gbps SAS-2 RAID Expansion Module (REM)	n/a

System Service Processor
Option #	Manufacturing Part #	Description	Previous Part #
X5725A [S]	510-1170 [C]	Service Processor Assembly	n/a
n/a	501-7822 [C]	Service Processor Assembly	n/a
	150-1204 [C]	3V Lithium Coin Cell Battery	n/a
	525-2515	IDPROM	n/a
n/a	511-1304 [C]	Service Processor Assembly, Sun Blade T6320+	n/a
	150-1204 [C]	3V Lithium Coin Cell Battery	n/a
	525-2515	IDPROM	n/a

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
