Oracle Sun 12K Server

Oracle Sun 12K Server Oracle Sun 12K Server Sun Servers SUN FIRE 12K copy

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*


    Processor
    Number Sun Fire 12K: 4 to 52
    Sun Fire 15K: 16 to 106
    Architecture UltraSPARC[tm] III Cu: 900MHz, 1050MHz or 1200MHz
    UltraSPARC IV: 1050MHz, 1200MHz or 1350MHz
    ECC protected
    Cache per processor
    Level 1
    Level 2
    ECC protected 32 KB instruction and 64 KB data on chip
    ECC protected 8 MB external cache
    System Interconnect 150 MHz Sun[tm] Fireplane redundant 18X18 data, address, and response crossbar interconnect
    System Boards
    CPU/Memory Boards Sun Fire 12K: Up to 9 CPU/Memory boards, each holding 4 processors and up to 32GB memory (32 DIMMs per board, 8 banks of 4 DIMMS), providing up to 288GB memory per system, and common design across the entire Sun Fire 3800 – 15K server line. Also up to 8 MaxCPU boards, each holding 2 processors.
    Sun Fire 15K: Up to 18 CPU/Memory boards, each holding 4 processors and up to 32GB memory (32 DIMMs per board, 8 banks of 4 DIMMS), providing up to 576GB memory per system, and common design across the entire Sun Fire 3800 – 15K server line. Also up to 17 MaxCPU boards, each holding 2 processors.
    I/O Sun Fire 12K: 9 I/O hubs support up to 36 I/O hot-swappable PCI slots. 18 slots are 66MHz, 18 slots are 33MHz.
    Sun Fire 15K: 18 I/O hubs support up to 72 I/O hot-swappable PCI slots. 36 slots are 66MHz, 36 slots are 33MHz.
    System Controller (SC) 2 redundant system controllers. Automatic system failover of system controllers, automatic failover of SC clock and management functions, with no service interruption to users.
    Main Memory
    Sun Fire 12K: 8GB to 288GB memory capacity per system, up to 288 DIMMs total per system
    Sun Fire 15K:16GB to 576GB memory capacity per system, up to 576 DIMMs total per system1GB, 2GB, and 4GB memory expansion options (each a group of 4 DIMMs)

    Up to eight memory expansion options per CPU/Memory board

    Standard Interfaces
    Ethernet One ethernet/fast ethernet (10BASE-T/100BASE-TX) standard twisted-pair port (RJ-45) per system controller board.
    PCI Four slots per hsPCI assembly supporting up to two 33-MHz and two 33/66-MHz industry standard PCI boards. Four slots per hsPCI-X assembly supporting one 33-MHz and three 90-MHz industry standard PCI-X boards.
    Serial One RS-232 serial TTYA port (mini-DIN8) per system controller board.
    Internal Mass Storage
    Disks (Internal – System Controller Peripheral Board) 2 mirrored 18.2GB or 73.4GB 10000 RPM Disk Drives (system controller boot disks)
    Disk Arrays (External – Peripheral Cabinet) Sun StorEdge[tm] S1 *
    DVD-ROM (Internal – System Controller Peripheral Board) 10X DVD-ROM Drive
    Tape (Internal – System Controller Peripheral Board) 20-40 GB 4 mm DDS-4 Tape Drive
    * – Primary boot device for Sun Fire 12K / 15K.
    Power Supplies
    N+1 redundant
    6 dual-input AC-to-48 volt DC power supplies
    Two power cables go to each supply, so they can connect to separate power grids (12 power cords)
    Environment
    AC power 200 – 240 VAC, single phase, 47 – 63 Hz; requires 12 – 30 A circuits
    Input power Sun Fire 12K: 12,965 W
    Sun Fire 15K: 23,927 W
    Heat output 44,081 BTU /hr (up to 9 slots occupied)
    81,352 BTU/hr (up to 18 slots occupied)
    Temperature ¹ Optimal: 21° C to 23° C (70° F to 74° F)
    Operating: 10° C to 35° C (50° F to 95° F)
    Nonoperating: -20° C to 60° C (-4° F to 140° F)
    Humidity Optimal: 45% to 50% relative humidity, noncondensing
    Operating: 20% to 80% relative humidity, noncondensing
    Nonoperating: up to 93% relative humidity, noncondensing
    Altitude Operating: 3000 m (10,000 ft.)
    Nonoperating: 12,000 m (40,000 ft.)
    1 – derate 2° C for every 1 km up to 3 km
    Regulations
    Meets or exceeds the following requirements:
    Safety UL 1950, CUL CAN/CSA 22:2 M950, TUV EN60950
    RFI/EMI FCC Immunity Class A, EN50021-1 Class A, EN50082-1
    Dimensions and Weights
    Height 191.8 cm (75.5 in.)
    203.2 cm (80.0 in.) shipping
    Width 84.6 cm (33.3 in.)
    121.9 cm (48.0 in.) shipping
    Depth 163.8 cm (64.5 in.)
    191.8 cm (75.5 in.) shipping
    Weight Sun Fire 12K: 996.1 kg (2191.5 lb.); 1198.4 kg (2636.5 lb.) shipping
    Sun Fire 15K: 1142.6 kg (2513.7 lb.); 1344.9 kg (2958.7 lb.) shipping
    Power cord 457 cm (15.0 ft.)
    Backplane/Centerplane
    Option # Manufacturing
    Part #
    Description
    4500A 501-6028 System Expander Board
    • 501-5179
    • System Expander Board
    • 370-4012
    • CDC SRAM DIMM
    370-5877 Starcat Service Cart, for storage of FRUs during centerplane replacement
    n/a 501-4936 Sun Fireplane Interconnect
    n/a 501-5378 Centerplane Support Board FRU
    (IBM SDI5/6 ASIC)
    n/a 501-6376 System Expander Board
    • 370-4012
    • CDC SRAM DIMM
    n/a 501-6803 Sun Fireplane Interconnect
    n/a 501-6818 Centerplane Support Board FRU
    (NEC SDI6 ASIC)
    n/a 501-6835 System Expander Assembly
    • 501-6827
    • System Expander Board
    • 370-4012
    • CDC SRAM DIMM
    n/a 501-6884 System Expander Assembly
    • 501-6802
    • System Expander Board
    • 370-4012
    • CDC SRAM DIMM
    n/a 501-7156 Centerplane Support Board FRU
    (NEC SDI7 ASIC)
    n/a 501-7238 System Expander Board, RoHS:YL
    n/a 540-3993 System Controller/Centerplane Support Board Carrier Plate
    n/a 540-4085 System Expander Carrier Plate (Slots 1, 2, 3, 6, 7, 8, 10, 11, 12, 15, 16, and 17)
    n/a 540-4427 Carrier Plate (Slots 0, 9)
    n/a 540-5736 Carrier Plate (Slots 4, 5, 13, 14)
    n/a 540-6291 System Controller/Centerplane Support Board Carrier Plate
    n/a 541-0119 Carrier Plate (Slots 1 2 3 6 7 8 10 11 12 15 16 17)
    n/a 541-0120 Carrier Plate (Slots 0 9)
    n/a 541-0121 Carrier Plate (Slots 4 5 13 14)
    n/a 541-1396 Carrier Plate (Slots 1 2 3 6 7 8 10 11 12 15 16 17), RoHS:Y
    n/a 541-1398 Carrier Plate (Slots 0 9), RoHS:Y
    n/a 541-1399 Carrier Plate (Slots 4 5 13 14), RoHS:Y
    Blade
    Option # Manufacturing
    Part #
    Description
    XUSBRDT-5240-128Z 594-5253 Sun Fire USBRDT 5240 Uniboard with 128 GB Memory (32 x 4GB), 2 CPUs (1.2GHz, 8-core UltraSPARC T2+), and 2 Drives, RoHS:Y
    XUSBRDT-5240-64Z 594-5252 Sun Fire USBRDT 5240 Uniboard with 64 GB Memory (32 x 4GB), 2 CPUs (1.2GHz, 8-core UltraSPARC T2+), and 2 Drives, RoHS:Y
    Cables
    Option # Manufacturing
    Part #
    Description
    X3800A AC Input Power Cable Option (North American, Asian), RoHS:Y
    180-1943 AC Input Power Cable, Harting Han 6HsB to NEMA L6-30P (North American, Asian), RoHS:Y
    X3808A Watertight Power Cord (INTL), Blue 32A Watertight IEC 309 to Han 6HsB, RoHS:Y
    180-2063 Power Cord, Blue 32A Watertight IEC 309 to Han 6HsB (INTL), RoHS:Y
    X3848A AC Input Power Cable, Harting Han 6HsB to IEC309 (International), RoHS:Y
    180-1944 AC Input Power Cable, Harting Han 6HsB to IEC309 (INTL), RoHS:Y
    X3858A AC Power Cord, Han 6HsB to NEMA L6-30P (US) 4M, RoHS:Y
    180-1954 Han 6HsB to NEMA L6-30P,4M (US), RoHS:Y
    X3859A Han 6HsB to Blue 32A IEC309 (Intl), RoHS:Y
    180-1955 Han 6HsB to Blue 32A IEC309 (INTL), RoHS:Y
    X8889 565-1750 Sun Fire High End Server Cable Management Kit, RoHS:Y
    X3806A Watertight Power Cord (US), Blue 30A Watertight IEC 309 to Han 6HsB, RoHS:Y
    180-2058 Power Cord, Blue 30A Watertight IEC 309 to Han 6HsB (US), RoHS:Y
    X3807A Watertight Power Cord (US), Blue 30A Watertight IEC 309 to Han 6HsB, RoHS:Y
    180-2059 Power Cord, Blue 30A Watertight IEC 309 to Han 6HsB (US), RoHS:Y
    X3809A Watertight Power Cord (INTL), Blue 32A Watertight IEC 309 to Han 6HsB, RoHS:Y
    180-2064 Power Cord, Blue 32A Watertight IEC 309 to Han 6HsB (INTL), RoHS:Y
    Communication
    Option # Manufacturing
    Part #
    Description
    X1355A-2 371-0982 2M, 80-Pin, 4-Port, DB37, RS449 Breakout Cable,RoHS:Y
    375-3296 Quad Port High Speed Serial Interface PCI-X (HSI/U), RoHS:Y
    X1071A 370-3878 HIPPI/P 1.1 High Performance Interface Board
    X1074A 370-3868 SCI Adapter (SCI/P)
    X1155A 370-2728 High Speed Serial Interface PCI (HSI/P) 2.0
    X1157A 501-3028 SunATM-155/MFiber PCI 4.0
    X1158A 501-3027 SunATM-155/UTP PCI 4.0
    X1159A 501-3029 SunATM-622/MFiber PCI 4.0
    X3895A 370-3922 Cluster 4 port SCI switch, Dolphin Model D515
    X3901A 530-2869 Cluster SCI Cable, 2M
    X3903A 530-2871 Cluster SCI Cable, 7.5M
    X3904A 530-2872 Cluster SCI Cable, 10M
    X4011A 501-6039 Crypto Accelerator 4000 UTP (copper)
    X4012A 501-6040 Crypto Accelerator 4000 MMF (fiber)
    Disks
    Option # Manufacturing
    Part #
    Description
    n/a 390-0106 Seagate ST373307LC [ST373307LSUN72G]
    (73.4GB – 10000 RPM – SCSI Disk)
    n/a 390-0108 Hitachi DK32EJ-72NC [DK32EJ72NSUN72G]
    (73.4GB – 10000 RPM – SCSI Disk)
    n/a 390-0157 Fujitsu MAP3735NC [MAP3735N SUN72G]
    (73.4GB – 10000 RPM – SCSI Disk)
    n/a 390-0174 Seagate ST373207LC [ST373207LSUN72G]
    (73.4GB – 10000 RPM – SCSI Disk)
    n/a 390-0175 Fujitsu MAT3073NC [MAT3073N SUN72G]
    (73.4GB – 10000 RPM – SCSI Disk)
    n/a 390-0038 Seagate ST318404LC [ST318404LCSUN18G]
    (18.2GB – 10000 RPM – SCSI Disk)
    n/a 390-0043 Fujitsu MAJ3182MC [MAJ3182M SUN18G]
    (18.2GB – 10000 RPM – SCSI Disk)
    n/a 390-0085 Seagate ST318305LC [ST318305LSUN18G]
    (18.2GB – 10000 RPM – SCSI Disk)
    Ethernet
    Option # Manufacturing
    Part #
    Description
    X4445A 501-6738 Quad GigaSwift PCI-X Ethernet (QGE-X), RoHS:Y
    X1034A 501-5406 Quad FastEthernet PCI (QFE/P)
    X1141A 501-4373 Gigabit Ethernet PCI (GBE/P) 2.0
    X1150A 501-5902 Sun GigaSwift Ethernet UTP (Copper)
    X1151A 501-5524 Sun GigaSwift Ethernet MMF (Fiber)
    X3150A 501-5902 Sun GigaSwift Ethernet UTP (Copper)
    X3151A 501-5524 Sun GigaSwift Ethernet MMF (Fiber)
    X4150A 501-6719 GigaSwift Ethernet UTP (GCS)
    X4151A 501-6762 GigaSwift Ethernet MMF (GFS)
    X4444A 501-6522 Quad GigaSwift Ethernet UTP (QGE)
    Fan
    Option # Manufacturing
    Part #
    Description
    n/a 540-4050 Fan Tray
    n/a 540-5304 Fan Tray, Dual Fan
    Fibre Channel
    Option # Manufacturing
    Part #
    Description
    SG-XPCI1FC-EM4-Z 375-3398 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QF4 375-3354 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM4-Z 375-3399 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF4 375-3294 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XFCE-6410-N 370-5701 JNI 1Gb PCI Single FC HBA
    SG-XFCE-6460-N 370-5702 JNI 2Gb PCI Single FC HBA
    SG-XFCE2-6412-N 370-5700 JNI 1Gb PCI Dual FC HBA
    SG-XPCI1FC-EM2 375-3304 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-JF2 375-3156 JNI 2Gb PCI Single FC Host Adapter
    SG-XPCI1FC-QF2 375-3102 2Gb PCI Single FC Host Adapter
    SG-XPCI1FC-QL2 375-3383 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM2 375-3305 2Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-JF2 375-3157 JNI 2Gb PCI Dual FC Host Adapter
    SG-XPCI2FC-QF2 375-3108 2Gb PCI Dual FC Host Adapter
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    SG-XPCI2FC-QF2-Z 375-3363 2Gb PCI Dual FC Host Adapter, RoHS:Y
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    X6727A 375-3030 PCI Dual FC Host Adapter+, RoHS:YL
    X6767A 375-3102 2Gb PCI Single FC Host Adapter
    X6768A 375-3108 2Gb PCI Dual FC Host Adapter
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    X6799A 375-3019 PCI Single FC Host Adapter
    I/O
    Option # Manufacturing
    Part #
    Description
    X4576A-Z 501-7483 hsPCI+ Assembly, RoHS:YL
    • 501-7364
    • 5.0V hsPCI Cassette, RoHS:YL
    • 501-7365
    • 3.3V hsPCI Cassette, RoHS:YL
    • 501-7394
    • hsPCI+ I/O Board without PCI Cassettes, RoHS:YL
    X4577A-Z 501-7895 hsPCI-X Assembly, RoHS:YL
    • 501-7364
    • 5.0V hsPCI Cassette, RoHS:YL
    • 501-7365
    • 3.3V hsPCI Cassette, RoHS:YL
    • 501-7873
    • hsPCI-X I/O Board without Cassettes, RoHS:YL
    4121A 501-5966 Sun Fire Link Assembly
    • 375-0093
    • cPCI Fire Link Optical Module (Paroli)
    • 501-5600
    • 5.0 V hsPCI Cassette
    • 501-5694
    • Sun Fire Link I/O Assy w/o WCI ASIC
    • 370-4224
    • 10MB SRAM I/O DIMM (2X)
    • 501-6086
    • 3.3V hsPCI Cassette
    • 501-6303
    • Sun Fire Link I/O Assy, without Optical Module
    X4170A 540-4946 Sun Fire Link Switch
    • 300-1518
    • 150W Power Supply
    • 370-4393
    • Fan Tray
    • 501-5637
    • System Controller
    • 501-5939
    • WCIX Module
    • 540-5205
    • Backplane + AC Harness + AC Module
    X4175A 540-5477 Sun Fire Link Optical Module
    • 375-0093
    • cPCI Fire Link Optical Module (Paroli)
    X4180A 537-1022 Sun Fire Link Optical Cable, 5m
    X4181A 537-1023 Sun Fire Link Optical Cable, 12m
    X4182A 537-1024 Sun Fire Link Optical Cable, 20m
    X4575A 501-6030 hsPCI I/O Board with PCI Cassettes
    • 501-5397
    • hsPCI Board without PCI Cassettes
    • 501-5600
    • 5.0 V hsPCI Cassette
    • 501-6086
    • 3.3V hsPCI Cassette
    X4576A 501-6440 hsPCI+ I/O Board with PCI Cassettes
    • 501-5600
    • 5.0 V hsPCI Cassette
    • 501-6082
    • hsPCI+ I/O Board without PCI Cassettes
    • 501-6086
    • 3.3V hsPCI Cassette
    501-7282 hsPCI+ I/O Board with PCI Cassettes
    • 501-5600
    • 5.0 V hsPCI Cassette
    • 501-6086
    • 3.3V hsPCI Cassette
    • 501-7274
    • hsPCI+ I/O Board without PCI Cassettes
    n/a 501-7602 hsPCI-X Assembly
    • 501-7357
    • hsPCI-X I/O Board without Cassettes
    • 501-7364
    • 5.0V hsPCI Cassette, RoHS:YL
    • 501-7365
    • 3.3V hsPCI Cassette, RoHS:YL
    n/a 501-7874 hsPCI+ I/O Board without PCI Cassettes, RoHS:YL
    Memory
    Option # Manufacturing
    Part #
    Description
    X7056A 4 GB (4 × 1GB SDRAM DIMMs)
    501-7386 1GB SDRAM DIMM, RoHS:YL
    X7051A 2 GB (4 × 512MB SDRAM DIMMs)
    501-7385 512MB SDRAM DIMM, RoHS:YL
    X7053A 1 GB (4 × 256MB SDRAM DIMMs)
    501-5401 256MB SDRAM DIMM
    n/a 501-5030 512MB SDRAM DIMM
    n/a 501-6109 1GB SDRAM DIMM
    n/a 540-5086 1GB SDRAM DIMM
    F511-1030 Package of 25 × 512MB SDRAM DIMMs
    • 501-7385
    • 512MB SDRAM DIMM, RoHS:YL
    F511-1031 Package of 25 × 1GB SDRAM DIMMs
    • 501-7386
    • 1GB SDRAM DIMM, RoHS:YL
    Miscellaneous
    Option # Manufacturing
    Part #
    Description
    C-F1XK-USIV-KIT-Z 556-4440 Sun Fire 12K/15K USIV Upgrade Kit, includes 18 carrier plates (12× 541-1396, 2× 541-1398, & 4× 541-1399), RoHS:Y
    • 541-1396
    • Carrier Plate (Slots 1 2 3 6 7 8 10 11 12 15 16 17), RoHS:Y
    • 541-1398
    • Carrier Plate (Slots 0 9), RoHS:Y
    • 541-1399
    • Carrier Plate (Slots 4 5 13 14), RoHS:Y
    C-F1XK-USIV-KIT 556-4435 Sun Fire 12K/15K USIV Upgrade Kit, includes 18 carrier plate (12 × 541-0119, 2× 541-0120, & 4× 541-0121)
    • 541-0119
    • Carrier Plate (Slots 1 2 3 6 7 8 10 11 12 15 16 17)
    • 541-0120
    • Carrier Plate (Slots 0 9)
    • 541-0121
    • Carrier Plate (Slots 4 5 13 14)
    X9660A 595-5204 72″ StorEdge Cabinet 1RU Air Baffle
    n/a 340-5614 Top Honeycomb Filter, RoHS:Y
    n/a 340-5615 Front Honeycomb Filter, RoHS:Y
    n/a 370-4364 Air Filter (x6), RoHS:Y
    n/a 370-4347 Plenum Air Filter
    Power
    Option # Manufacturing
    Part #
    Description
    C-HE-PWR2-KIT-Z Power Supply Upgrade Kit for 1.95GHz USIV+
    300-1813 Dual AC Input 52 Volt Output Power Supply, A211, RoHS:Y
    n/a 300-1413 Artesyn 4000W Power Supply, A141
    n/a 300-1705 Artesyn 4000/4700W Power Supply, A196
    Rack
    Option # Manufacturing
    Part #
    Description
    9819AR5 595-4954 72 inch Sun StorEdge Expansion Cabinet Cooling Kit
    SR9-XKL038A-IP 595-6712 Sun Rack 900, Empty X-Option Rack without Power, RoHS:Y
    SG-XARY030A 595-4706 72 inch Sun StorEdge Expansion Cabinet
    X9818A 595-4999 72 inch StorEdge Expansion Cabinet Front Door Kit
    n/a 540-3985 Processor Cabinet (replaced 540-5151-01 – 01/02)
    n/a 540-4080 Front Access Door (right)
    n/a 540-4081 Rear Access Door (right)
    n/a 540-4357 Kick Plate Assembly
    n/a 540-4560 Rear Plenum Panel
    n/a 540-4561 Front Plenum Panel
    n/a 540-5046 Left Front Door with logo
    n/a 540-5077 Left Rear Door with EMI
    n/a 540-5151 Processor Cabinet (replaced 540-3985-07 – 09/01)
    n/a 540-5704 Top Cap
    n/a 540-5737 Processor Cabinet (replaced 540-3985-09 – 02/03)
    n/a 541-0008 Rear Plenum Panel
    n/a 541-0009 Front Plenum Panel
    Removable Media
    Option # Manufacturing
    Part #
    Description
    n/a 390-0025 10X DVD-ROM Drive
    n/a 390-0027 20-40GB 4 mm DDS-4 Tape Drive (Medium Grey Bezel)
    SCSI
    Option # Manufacturing
    Part #
    Description
    SG-XPCI2SCSI-LM320 375-3191 PCI/PCI-X Dual Ultra320 SCSI Adapter
    X2222A 501-5727 Dual FastEthernet / Dual SCSI PCI Adapter
    X4422A 501-6635 Dual GigabitEthernet / Dual SCSI PCI Adapter
    X6541A 375-0006 Dual Differential Ultra/Wide SCSI (UDWIS/P)(HVD)
    X6758A 375-3057 PCI Dual Ultra3 SCSI Host Adapter (LVD)
    X1032A 501-5656 Single-Ended Ultra/Wide SCSI/FastEthernet (SunSwift PCI)
    System Board
    Option # Manufacturing
    Part #
    Description
    4525-1050A 501-6465 MaxCPU Board 1050MHz
    4525-1200A 501-6466 MaxCPU Board 1.2GHz
    C4525-1050A 501-6465 MaxCPU Board 1050MHz
    C4525-1200A 501-6466 MaxCPU Board 1.2GHz
    X4006A-CDP 540-5821 CPU/Memory Uniboard w/ 2× US III Cu 900MHZ, 0MB
    X4007A-CDP 540-5825 CPU/Memory Uniboard w/ 4× US III Cu 900MHZ, 0MB
    XCPUBD-2-1050-CDP 540-5795 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 0MB
    XCPUBD-222-1200 540-5682 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz, 4GB
    XCPUBD-4-1050-CDP 540-5799 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 0MB
    XS400BRD-482-1050 540-5662 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 16GB
    XS400BRD-482-1050C Capacity On Demand (COD) Uniboard w/4× unlicensed US IV 1.05GHz, 16GB
    540-6070 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 16GB
    XS400BRD-484-1050 540-5663 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 32GB
    XS400BRD-484-1050C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.05GHz, 32GB
    540-6072 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 32GB
    XUS3BD-222-1200-Z 540-6843 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz, 4GB, RoHS:YL
    XUS4BD-448-1950-Z CPU/Memory Uniboard w/4× US IV+ 1.95GHz, 32GB, RoHS:YL
    540-7133 CPU/Memory Uniboard w/4× US IV+ 1.95GHz, 32GB, RoHS:YL
    XUS4BD-482-1050-Z 540-6989 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 16GB, RoHS:YL
    XUS4BD-482-1050C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.05GHz, 16GB
    540-6989 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 16GB, RoHS:YL
    XUS4BD-482-1800-Z CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-6754 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7071 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7201 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7528 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7535 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    XUS4BD-484-1050-Z 540-6847 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 32GB, RoHS:YL
    XUS4BD-484-1050C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.05GHz, 32GB
    540-6847 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 32GB, RoHS:YL
    XUS4BD-484-1800-Z CPU/Memory Uniboard w/4× US IV+ Cu 1.8GHz, 32GB, RoHS:YL
    540-6755 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7072 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7202 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7529 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7536 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    X4006A 540-5051 CPU/Memory Uniboard w/ 2× US III Cu 900MHZ, 0MB
    X4007A 540-5052 CPU/Memory Uniboard w/ 4× US III Cu 900MHZ, 0MB
    X4525A 501-6701 MaxCPU Board 900MHz
    XCPUBD-2029 540-5822 CPU/Memory Uniboard w/ 2× US III Cu 900MHZ, 2GB
    XCPUBD-2049 540-5823 CPU/Memory Uniboard w/ 2× US III Cu 900MHZ, 4GB
    XCPUBD-2089 540-5824 CPU/Memory Uniboard w/ 2× US III Cu 900MHZ, 8GB
    XCPUBD-221-1050 540-5796 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 2GB
    XCPUBD-222-1050 540-5797 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 4GB
    XCPUBD-224-1050 540-5798 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 8GB
    XCPUBD-4049 540-5826 CPU/Memory Uniboard w/ 4× US III Cu 900MHZ, 4GB
    XCPUBD-441-1050 540-5800 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 4GB
    XCPUBD-441-1200 540-5684 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 4GB
    XCPUBD-442-1050 540-5858 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 8GB
    XCPUBD-442-1200 540-5859 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 8GB
    XCPUBD-481-1050 540-5801 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 8GB
    XCPUBD-481-1050-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 1050MHz, 8GB
    540-5819 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 8GB
    XCPUBD-481-1200 540-5685 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 8GB
    XCPUBD-481-1200-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 1.2GHz, 8GB
    540-5732 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 8GB
    XCPUBD-482-1050 540-5780 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 16GB
    XCPUBD-482-1050-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 1050MHz, 16GB
    540-5820 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 16GB
    XCPUBD-482-1200 540-5603 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 16GB
    XCPUBD-482-1200-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 1.2GHz, 16GB
    540-5740 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 16GB
    XCPUBD-484-1050 540-5803 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 32GB
    XCPUBD-484-1200 540-5604 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 32GB
    XCPUBD-484-1200-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 1.2GHz, 32GB
    540-6010 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 32GB
    XCPUBD-F4089 540-5827 CPU/Memory Uniboard w/ 4× US III Cu 900MHZ, 8GB
    XCPUBD-F4089-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 900MHz, 8GB
    540-5474 CPU/Memory Uniboard w/ 4× US III Cu 900MHz, 8GB
    XCPUBD-F4169 540-5829 CPU/Memory Uniboard w/ 4× US III Cu 900MHz, 16GB
    XCPUBD-F4329 540-5830 CPU/Memory Uniboard w/ 4× US III Cu 900MHz, 32GB
    XUS3BD-442-1200-Z 540-6844 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 8GB, RoHS:YL
    XUS3BD-482-1200-Z 540-6845 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 16GB, RoHS:YL
    XUS3BD-484-1200-Z 540-6846 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 32GB, RoHS:YL
    XUS4BD-444-1950-Z CPU/Memory Uniboard w/4× US IV+ 1.95GHz, 16GB, RoHS:YL
    540-7132 CPU/Memory Uniboard w/4× US IV+ 1.95GHz, 16GB, RoHS:YL
    XUS4BD-482-1350-Z 540-6830 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 16GB, RoHS:YL
    XUS4BD-482-1350C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.35GHz, 16GB
    540-6830 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 16GB, RoHS:YL
    XUS4BD-482-1500-Z 540-6833 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 16GB, RoHS:YL
    XUS4BD-482-1500C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV+ 1.5GHz, 16GB
    540-6833 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 16GB, RoHS:YL
    XUS4BD-482-1800C-Z Capacity On Demand (COD) Uniboard w/4× unlicensed US IV+ 1.8GHz, 16GB, RoHS:YL
    540-6754 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7071 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7201 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7528 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7535 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    XUS4BD-484-1350-Z 540-6831 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 32GB, RoHS:YL
    XUS4BD-484-1350C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.35GHz, 32GB
    540-6831 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 32GB, RoHS:YL
    XUS4BD-484-1500-Z 540-6834 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 32GB, RoHS:YL
    XUS4BD-484-1500C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV+ 1.5GHz, 32GB
    540-6834 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 32GB, RoHS:YL
    XUS4BD-484-1800C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV+ 1.8GHz, 32GB, RoHS:YL
    540-6755 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7072 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7202 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7529 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7536 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    XUS4BD-488-1350-Z CPU/Memory Uniboard w/4× US IV 1.35GHz, 64GB, RoHS:YL
    540-7024 CPU/Memory Uniboard w/4× US IV 1.35GHz, 64GB, RoHS:YL
    XUS4BD-488-1350C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.35GHz, 64GB, RoHS:YL
    540-7024 CPU/Memory Uniboard w/4× US IV 1.35GHz, 64GB, RoHS:YL
    XUS4BD-488-1500-Z CPU/Memory Uniboard w/4× US IV+ 1.5GHz, 64GB, RoHS:YL
    540-6802 CPU/Memory Uniboard w/4× US IV+ 1.5GHz, 64GB, RoHS:YL
    XUS4BD-488-1500C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV+ 1.5GHz, 64GB, RoHS:YL
    540-6802 CPU/Memory Uniboard w/4× US IV+ 1.5GHz, 64GB, RoHS:YL
    XUS4BD-488-1800-Z CPU/Memory Uniboard w/4× US IV+ Cu 1.8GHz, 64GB, RoHS:YL
    540-6756 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7073 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7203 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7530 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7537 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    XUS4BD-488-1800C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV+ 1.8GHz, 64GB, RoHS:YL
    540-6756 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7073 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7203 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7530 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7537 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    XUS4BRD-482-1200 540-6253 CPU/Memory Uniboard w/ 4× US IV 1.2GHz, 16GB
    XUS4BRD-482-1200C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.2GHz, 16GB
    540-6280 CPU/Memory Uniboard w/ 4× US IV 1.2GHz, 16GB
    XUS4BRD-482-1350 540-6296 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 16GB
    XUS4BRD-482-1350C Capacity On Demand (COD) Uniboard w/4x unlicensed US IV 1.35GHz, 16GB
    540-6296 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 16GB
    XUS4BRD-484-1200 540-6254 CPU/Memory Uniboard w/ 4× US IV 1.2GHz, 32GB
    XUS4BRD-484-1200C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.2GHz, 32GB
    540-6281 CPU/Memory Uniboard w/ 4× US IV 1.2GHz, 32GB
    XUS4BRD-484-1350 540-6297 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 32GB
    XUS4BRD-484-1350C Capacity On Demand (COD) Uniboard w/4x unlicensed US IV 1.35GHz, 32GB
    540-6297 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 32GB
    n/a 501-6138 MaxCPU Board 900MHz
    n/a 501-6365 MaxCPU Board 1050MHz
    n/a 501-6430 MaxCPU Board 900MHz
    n/a 540-5267 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 0MB
    n/a 540-5605 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 0MB
    n/a 540-5623 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 0MB
    n/a 540-5691 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz, 0MB
    n/a 540-6078 CPU/Memory Uniboard w/ 2× US III Cu 900MHz, 0MB
    n/a 540-6079 CPU/Memory Uniboard w/ 4× US III Cu 900MHz, 0MB
    n/a 540-6080 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 0MB
    n/a 540-6081 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 0MB
    n/a 540-6082 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz, 0MB
    n/a 540-6083 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 0MB
    n/a 540-6233 CPU/Memory UniBoard w/ 4× US IV 1200MHz, 0MB
    n/a 540-6248 CPU/Memory UniBoard w/ 4× US IV 1050MHz, 0MB
    n/a 540-6251 CPU/Memory Uniboard w/ 4× US IV 1.2GHz, 0GB
    n/a 540-6295 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 0GB
    n/a 540-6439 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 0MB
    n/a 540-6753 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 0MB, RoHS:YL
    n/a 540-6803 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 0GB, RoHS:YL
    n/a 540-6832 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 0MB, RoHS:YL
    n/a 540-6848 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz, 0GB, RoHS:YL
    n/a 540-6849 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 0GB, RoHS:YL
    n/a 540-6853 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 0GB, RoHS:YL
    n/a 540-7123 CPU/Memory Uniboard w/4× US IV+ 1.95GHz, 0MB, RoHS:YL
    n/a 540-7527 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 0MB, RoHS:YL
    n/a 559-0067 CPU/Memory Uniboard w/ 4× US III Cu 900MHz,
    0MB (L2 Cache rework)
    n/a 559-0068 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz,
    0MB (L2 Cache rework)
    n/a 559-0069 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz,
    0MB (L2 Cache rework)
    n/a 559-0072 CPU/Memory Uniboard w/ 2× US III Cu 900MHz,
    0MB (L2 Cache rework)
    n/a 559-0073 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz,
    0MB (L2 Cache rework)
    n/a 559-0074 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz,
    0MB (L2 Cache rework)
    n/a 540-5664 CPU/Memory Uniboard w/ 4 × US IV 1.05GHz,
    0GB
    System Controller
    Option # Manufacturing
    Part #
    Description
    n/a 370-4214 256MB Memory Module for System Controller
    n/a 375-3025 512MB Memory Module for System Controller
    n/a 501-5121 System Controller Board
    n/a 501-5209 128MB Memory Module for System Controller
    n/a 501-5388 256MB Memory Board FRU
    n/a 501-5473 System Controller CPU board (CP1500) with 440MHz CPU, 0MB (requires memory)
    n/a 501-6358 System Controller CPU board (CP2140) with 650MHz CPU, 0MB (requires memory)
    n/a 501-6772 System Controller CPU board (CP2140) with 650MHz CPU, 0MB (requires memory)
    n/a 540-4813 System Control Peripheral Assembly with 2 disks, 1 tape drive, and 1 DVD-ROM
    • 501-5418
    • System Control Peripheral Board
      (w/out drives)
    • 530-2920
    • System Control Peripheral Board Power Cable
    • 530-3045
    • System Control Peripheral Board SCSI Cable, RoHS:YL

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
