IBM DS3400 1726-HC4 FC Storage Array 12 x 300Gb SAS HDD’s, 2 x 4Gb Controller4

REQUEST A PRICE QUOTE:

IBM DS3400 Fibre Channel 3.6Tb Storage Array Shelf

Included

1 x IBM DS3400 1726-HC4 FC Storage Array Shelf 39R6545
9 x 300Gb 10k SAS Hard Drives 39R7344
2 x 300Gb 15k SAS Hard Drives 43X0805
1 x 300Gb 15k 6Gbps SAS Hard Drive 44W2235
2 x 4Gb Fibre Channel RAID Controllers 39R6502
2 x Avago AFBR-57R5AEZ 4.25Gb Fibre Optic Transceiver Module
2 x 515w Power Supplies 42C2140

Features

Four Gigabits per second (Gbps) FC interface technology
Start with a Direct Attached Storage (DAS) configuration and seamlessly transition to a FC SAN when ready
Easy to deploy and manage with the DS3000 Storage Manager
Combination of 12 Serial Attached SCSI (SAS) – up to 7.2 TeraByte (TB) – or Serial Advanced Technology Attachment (SATA) – up to 24.0 TB – drives per enclosure
Expandable to 28.8 TB with SAS or up to 96.0 TB SATA with up to three EXP3000 enclosures
Flexible power options for Telco applications and Network Equipment Building System (NEBS) and European Telecommunication Standards Institute (ETSI) compliance.

Specifications

RAID controller: Dual active
Cache per controller: 512 MB battery-backed cache with 1GB upgrade option
Host interface: Two host ports per controller, Fibre Channel (FC) 4GBps auto-sensing 1GBps/2GBps
Drive interface: Serial Attached SCSI (SAS)
RAID levels: RAID 0, -1, -3, -5, -6, -10
Storage partitions: 4, 8, 16, 32
Maximum drives supported: 48 SAS or SATA drives (using three EXP3000 Expansion Units)
Management software: IBM System Storage DS3000 Storage Manager
SAN support: IBM supported FC switches
Fans and power supplies: Dual-redundant, hot-swappable
Rack support: 19″ industry-standard rack
Size (H x W x D): 8.7 x 44.7 x 55.0 cm (3.4 x 17.6 x 21.6 in)
Weight: standard unit 17.2 kg (38.0 lb); fully configured, 29.2 kg (64.5 lb)

Supported drives

3GBps SAS: 146GB, 300GB, and 450GB SAS drives at 15,000 rpm speeds
6GBps SAS: 300GB, 450GB, 600GB SAS drives at 15,000 rpm speeds
3GBps SATA: 500GB, 750GB, 1.0TB, 2.0TB SATA drives at 7,200 rpm speed
