Cisco WS-X5234-RJ45 24 Port 10/100 Base TX Switching Module
REQUEST A PRICE QUOTE:
Cisco WS-X5234-RJ45 24 Port 10/100 Base TX Switching Module
| Product Information | |
| The 10/100-Mbps Fast Ethernet switching module (10/100BaseTX 24 port) provides 24 switched, 10/100-Mbps (10/100BaseTX Category 5 UTP), full- or half-duplex Fast Ethernet ports using 24 RJ-45 connectors.The WS-X5234-RJ45 module supports Fast EtherChannel. On all Fast EtherChannel-capable hardware, port groups determine which ports can form a channel. Channels must be composed of contiguous ports from the same port group. A channel cannot have some ports from one group and some ports from another. However, you can configure multiple channels within a single group. On the WS-X5234-RJ45, the ports form six groups of four ports each (ports 1-4, 5-8, 9-12, 13-16, 17-20, and 21-24). The LEDs provide status information for the module and individual 10/100-Mbps Fast Ethernet port connections. | |
| Product Identifiers | |
| Brand | Cisco |
| Model | 5234 |
| MPN | WSX5234RJ45 |
| UPC | 0746320228310 |
| Key Features | |
| Form Factor | Plug-in module |
| Ports Qty | 24 |
| Data Transfer Rate | 100 Mbps |
| Data Link Protocol | Ethernet, Fast Ethernet |
| Compatibility | PC |
| Features | |
| Other Features | Auto-negotiation, VLAN support, Modular design, full duplex capability, uplink, manageable |
| Status Indicators | Port status, port transmission speed, Port status, test mode |
| Networking | |
| Networking Type | Switch |
| Connectivity Technology | Wired |
| Switching Protocol | Ethernet |
| Connectors | |
| Interfaces | 24 x network node – Ethernet 10Base-T/100Base-TX – RJ-45 female – 24 |
| System Requirements | |
| OS Required | None |
| Memory | |
| RAM Memory | 4.6 MB |
| Dimensions | |
| Width | 14 in. |
| Height | 1 in. |
| Depth | 16 in. |
| Weight | 5 lbs |
| Miscellaneous | |
| Enclosure Type | Plug-in module |
| Humidity Range Operating (Range) | 10 – 90% |
| Max Operating Temperature_Display | 104 ?F |
| Min Operating Temperature_Display | 32 ?F |
| Rack Mounting Kit | N/A |
