Oracle Sun X4540 Server

Oracle Sun X4540 Server Oracle Sun X4540 Server Sun Servers SUN FIRE X4540 copy

REQUEST A PRICE QUOTE:

Name*

Phone

Details*





Processor
Number 2
Architecture Type: AMD Opteron
  • 2.3GHz Quad Core AMD Opteron 2356
  • 2.7GHz Quad Core AMD Opteron 2384
  • 2.6GHz 6-Core AMD Opteron 2435
Cache memory 512 KB L2 Cache per core, 2 MB L3 Cache per processor
Main Memory
Capacities DIMM slots per CPU Socket: 8
DIMM sizes: 2 GB, 4 GB, 8 GB
DIMM type: DDR2/600 MHz ECC registered DIMMs
Maximum capacity: 128 GB (when configured with 8 GB DIMMs and 2 CPU Modules)
Standard Integrated Interfaces
Network Four 10/100/1000Base-T Ethernet ports, RJ-45 connectors
Network Management One dedicated 10/100Base-T Ethernet port, RJ-45 connector
Serial Management One TIA/EIA-232-F asynchronous RJ-45 Serial Connector
SATA Six 8-port SATA controllers, internal access only.
Video ATI Rage XL Video Chip, VGA Video Port
USB Front: Two USB 2.0 ports
Rear: Two USB 2.0 ports
Expansion bus Three x8 (eight-lane) PCI Express Slots.
Internal Mass Storage
Disks Internal: forty-eight hot-swappable disk drives for a total of 48 TB of raw storage.
SW RAID enabled by RAID-Z in Solaris ZFS.
Drive Type Density Speed Form Factor
SATA II 250 GB, 500 GB and 1 TB * 7,200 RPM 3.5″
* – Mixing disk drive capacities is not supported.
Power Supplies
Two dual redundant, hot-swappable power supplies, or three 110V PSUs.
UL Maximum( AC Input) 1800W
Power Supply Rating (DC output) 1500 W
Typical Power Consumption 1000 W, with 200CFM, max measured is 1100W
Environment
AC power Source 200-240 V AC @ 10 Amps
or 100-110 V AC
Temperature Operating: 5° C to 31° C (37° F to 90° F)
Nonoperating: -40° C to 65° C (-40° F to 149° F)
Humidity Operating: 10% to 90% relative humidity noncondensing, 27° C (80.6° F) max wet bulb
Nonoperating: up to 93% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
Altitude Operating:Up to 3048 m, maximum ambient temperature is derated by 1 degree C per 300 m above 900 m.
Nonoperating: Up to 4000 m.
Acoustic noise
(Measure and Environment)
Declared noise emissions in accordance with ISO 9296, A-weighted, operating and idling:
Less than 83 dB sound power in ambient temperature of up to 24° C
Regulations
Meets or exceeds the following requirements:
RoHS Compliance Level RoHS:YL
Safety IEC60950, UL/CSA60950-1, EN60950, CB Scheme with all country differences
RFI/EMI FCC Class A, Part 15 47 CFR, EN55022, CISPR 22, EN300-386:v1.3.2, ICES-003.
Immunity EN55024,EN300-386:v1.3.2.
Certifications Safety: cULus Mark, UL/Demko GS Mark, CE Mark, CCC, GOST R, S-Mark
CE Mark (93/68/EEC), Emissions and Immunity Class A Emissions Levels: FCC, VCCI, C-Tick, MIC,
CCC, GOST R, BSMI.
Other: Labeled per WEEE (Waste Electrical and Electrical Equipment) Directive
Dimensions and Weight
Height 175 mm (6.75 in.) (4 Rack Units)
Width 445 mm (17.0 in.) (19″ Rack Mountable)
Depth 736 mm (29.0 in.)
Weight 40 kg (88 lb.) Maximum standalone server
88 kg (170 lb.) Maximum with orderable rack-mount kit and cable management arm
Batteries
Option # Manufacturing
Part #
Description
n/a 371-2210 CR2032 3V Battery, RoHS:Y
CPU Module
Option # Manufacturing
Part #
Description
n/a 371-4042 2.3 GHz CPU, Opteron 2356 Quad Core, B3 Stepping, 75W, RoHS:Y
n/a 371-4438 2.7 GHz CPU, Opteron 2384 Quad Core, C2 Stepping, 75W, RoHS:Y
n/a 371-4681 2.6 GHz CPU, Opteron 2435 6-Core, D0 Stepping, 75W, RoHS:Y
Cables
Option # Manufacturing
Part #
Description
X312E Localized Power Code Kit – China, RoHS:Y
180-1982 IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
X317L Localized Power Cord Kit – U.K., RoHS:Y
180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
X320A Localized Power Cord Kit – North America/Asia, RoHS:Y
180-2164 IEC 320 C13 to NEMA 6-15P – 10A/250V 2.0M Black, RoHS:Y
X330A Power Cord 220V 15A US/Japan, RoHS:Y
180-2075 Power Cord 220V 15A US/Japan, RoHS:Y
X340L Power Kit for North America, L6-20 20A Twist Lock Plug, RoHS:Y
180-2070 NEMA L6-20P to IEC 320 C13 – 4.0M, RoHS:Y
X384L Localized Power Cord Kit – Italian, RoHS:Y
180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
X386L Localized Power Cord Kit – Australian, RoHS:Y
180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
n/a 180-1995 IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
Communication
Option # Manufacturing
Part #
Description
X4237A 375-3606 Sun Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express, RoHS:Y
X1236A-Z 375-3382 Dual Port 10Gb/sec 4x PCI Express Infiniband Host Channel Adapter – Low Profile, RoHS:Y
X4217A-Z 375-3549 Dual Port 20Gb/sec 4x PCI Express Infiniband Host Channel Adapter – Low Profile, RoHS:Y
Disks
Option # Manufacturing
Part #
Description
XRA-ST1CH-2T7K 541-4241 2TB – 7200RPM SATA, Disk Assemblywith 1 bracket and 1 of the following disk:, RoHS:Y
  • 390-0467
  • Hitachi H7220AA30 [H7220AA30SUN2.0T]
    (2TB – 7200 RPM – SATA Disk), RoHS:Y
  • 541-0456
  • Disk Drive Mounting Bracket, RoHS:Y
XTA7210-LOGZ18GB 540-7763 18GB Solid State Drive Assembly, SATA Interface, RoHS:Y
  • 371-4192
  • 18GB Solid State Drive, SATA Interface, RoHS:Y
  • 541-0456
  • Disk Drive Mounting Bracket, RoHS:Y
n/a 540-7507 1TB – 7200RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
  • 390-0381
  • Hitachi HUA721010KLA330 [HUA7210SASUN1.0T]
    (1TB – 7200 RPM – SATA Disk), RoHS:Y
  • 390-0479
  • Hitachi H7210CA30 [H7210CA30SUN1.0T] (1TB – 7200 RPM- SATA Disk), RoHS:Y
  • 541-0456
  • Disk Drive Mounting Bracket, RoHS:Y
n/a 541-1468 250GB – 7200RPM SATA, Disk Assembly with 1 of the following disks:, RoHS:Y
  • 390-0246
  • Hitachi HDT722525DLA380 [HDS7225SBSUN250G]
    (250GB – 7200 RPM – SATA Disk), RoHS:Y
  • 390-0354
  • Seagate ST3250820NS [ST32500NSSUN250G]
    (250GB – 7200 RPM – SATA Disk), RoHS:Y
  • 541-0456
  • Disk Drive Mounting Bracket, RoHS:Y
n/a 541-3050 500GB – 7200RPM SATA, Disk Assembly with 1 of the following disks:, RoHS:Y
  • 390-0383
  • Hitachi HUA721050KLA330 [HUA7250SBSUN500G]
    (500GB – 7200 RPM – SATA Disk), RoHS:Y
  • 541-0456
  • Disk Drive Mounting Bracket, RoHS:Y
n/a 541-3678 250GB – 7200RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:YL
  • 390-0354
  • Seagate ST3250820NS [ST32500NSSUN250G]
    (250GB – 7200 RPM – SATA Disk), RoHS:Y
  • 390-0411
  • Seagate ST3250310NS [ST32502NSSUN250G]
    (250GB – 7200 RPM – SATA Disk), RoHS:Y
  • 541-0456
  • Disk Drive Mounting Bracket, RoHS:Y
n/a 541-3679 500GB – 7200RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:YL
  • 390-0412
  • Seagate ST3500320NS [ST35002NSSUN500G]
    (500GB – 7200 RPM – SATA Disk), RoHS:Y
  • 541-0456
  • Disk Drive Mounting Bracket, RoHS:Y
n/a 541-3730 1TB – 7200RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
  • 390-0414
  • Seagate ST31000340NS [ST31000NSSUN1.0T]
    (1TB – 7200 RPM – SATA Disk), RoHS:Y
  • 541-0456
  • Disk Drive Mounting Bracket, RoHS:Y
Ethernet
Option # Manufacturing
Part #
Description
X1027A-Z 501-7283 PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y
X1106A-Z 375-3585 Intel PRO/10GbE-SR x8 PCI Express Low Profile Bracket, RoHS:Y
X4446A-Z 375-3481 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
X5558A 375-3301 10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
X5560A-Z 375-3495 10Gb/sec XFP Optical Transceiver Long Range (LR), RoHS:Y
X7280A-2 371-0905 PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
X7281A-2 371-0904 PCI Express Dual Gigabit Ethernet MMF, RoHS:Y
Fan
Option # Manufacturing
Part #
Description
n/a 541-0458 Fan Module, RoHS:YL
Fibre Channel
Option # Manufacturing
Part #
Description
SG-XPCIE1FC-EM4 375-3396 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-EM8-Z 371-4295 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF4 375-3355 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF8-Z 371-4324 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM4 375-3397 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM8-Z 371-4306 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF4 375-3356 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF8-Z 371-4325 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
Memory
Option # Manufacturing
Part #
Description
X5034 F541-1313 4GB (2 × 2GB) Memory, RoHS:Y
  • 371-1338
  • 2GB DDR667/PC2-5300 DIMM, RoHS:Y
X5035 F541-1304 8GB (2 × 4GB) Memory, RoHS:Y
  • 371-2956
  • 4 GB DDR667/PC2-5300 DIMM, RoHS:Y
n/a 541-3419 16GB (2 × 8GB DDR2-667 Registered ECC dual-rank DIMMs)
  • 371-4387
  • 8GB DDR2-667 dual-rank Memory DIMM, RoHS:Y
n/a F541-3360 4GB (2 × 2GB) Memory, RoHS:Y
  • 371-4180
  • 2GB DDR667/PC2-5300 DIMM, RoHS:Y
Power
Option # Manufacturing
Part #
Description
X5037 300-2161 Power Supply Type A240, RoHS:YL
n/a 300-1787 Power Supply Type A205, RoHS:YL
n/a 371-4650 Energy Storage Module (ESM), RoHS:Y
n/a 501-7104 Power Distribution Board, RoHS:YL
n/a 511-1101 Power Distribution Board, RoHS:YL
Rack
Option # Manufacturing
Part #
Description
X4541 350-1393 Slide Rail, RoHS:Y
X4542 350-1363 Cable Management Arm, RoHS:Y
X4228A-Z 371-3493 Slide Rail, RoHS:Y
n/a 371-2886 Slide Rail and Cable Management Arm Combo Kit, RoHS:Y
SCSI
Option # Manufacturing
Part #
Description
SG-XPCIE2SCSIU320Z 375-3357 Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
SG-XPCIE8SAS-E-Z 375-3487 PCI Express 8-Port Host Adapter, RoHS:Y
SGXPCIESAS-R-EXT-Z 371-3253 Lithium Ion Battery Module
375-3537 8-Port SAS RAID External HBA, RoHS:Y
XTA-FAS-S3IE96GB 541-3731 96GB PCI Express Flash Accelerator F20 SAS HBA, RoHS:Y
  • 371-4415
  • 24GB Solid State Flash Memory Module, RoHS:Y
  • 371-4650
  • Energy Storage Module (ESM), RoHS:Y
  • 511-1500
  • PCI Express Flash Board, RoHS:Y
System Board
Option # Manufacturing
Part #
Description
n/a 541-1219 System Controller Assembly (32GB, 2× 2.3GHz), RoHS:YL
  • 310-0141
  • Heatsink with Captive Screws and Springs, RoHS:Y
  • 371-1338
  • 2GB DDR667/PC2-5300 DIMM, RoHS:Y
  • 371-4042
  • 2.3 GHz CPU, Opteron 2356 Quad Core, B3 Stepping, 75W, RoHS:Y
  • 541-3758
  • System Controller Assembly, RoHS:YL
  • 501-7818
  • CPU/Memory Board, RoHS:YL
  • 371-2210
  • CR2032 3V Battery, RoHS:Y
  • 501-7819
  • I/O Board, RoHS:YL
  • 541-0487
  • System Controller Enclosure, RoHS:Y
n/a 541-3241 System Controller Assembly (64GB, 2× 2.3GHz), RoHS:YL
  • 310-0141
  • Heatsink with Captive Screws and Springs, RoHS:Y
  • 371-2956
  • 4 GB DDR667/PC2-5300 DIMM, RoHS:Y
  • 371-4042
  • 2.3 GHz CPU, Opteron 2356 Quad Core, B3 Stepping, 75W, RoHS:Y
  • 541-3758
  • System Controller Assembly, RoHS:YL
  • 501-7818
  • CPU/Memory Board, RoHS:YL
  • 371-2210
  • CR2032 3V Battery, RoHS:Y
  • 501-7819
  • I/O Board, RoHS:YL
  • 541-0487
  • System Controller Enclosure, RoHS:Y
n/a 541-3750 System Controller Assembly (32GB, 2× 2.7GHz), RoHS:YL
  • 310-0141
  • Heatsink with Captive Screws and Springs, RoHS:Y
  • 371-4180
  • 2GB DDR667/PC2-5300 DIMM, RoHS:Y
  • 371-4438
  • 2.7 GHz CPU, Opteron 2384 Quad Core, C2 Stepping, 75W, RoHS:Y
  • 541-3758
  • System Controller Assembly, RoHS:YL
  • 501-7818
  • CPU/Memory Board, RoHS:YL
  • 371-2210
  • CR2032 3V Battery, RoHS:Y
  • 501-7819
  • I/O Board, RoHS:YL
  • 541-0487
  • System Controller Enclosure, RoHS:Y
n/a 541-3751 System Board Assembly (64GB, 2× 2.7GHz), RoHS:YL
  • 310-0141
  • Heatsink with Captive Screws and Springs, RoHS:Y
  • 371-2956
  • 4 GB DDR667/PC2-5300 DIMM, RoHS:Y
  • 371-4438
  • 2.7 GHz CPU, Opteron 2384 Quad Core, C2 Stepping, 75W, RoHS:Y
  • 541-3758
  • System Controller Assembly, RoHS:YL
  • 501-7818
  • CPU/Memory Board, RoHS:YL
  • 371-2210
  • CR2032 3V Battery, RoHS:Y
  • 501-7819
  • I/O Board, RoHS:YL
  • 541-0487
  • System Controller Enclosure, RoHS:Y
n/a 541-4144 System Controller Assembly (32GB, 2 × 2.6GHz), RoHS:YL
  • 310-0141
  • Heatsink with Captive Screws and Springs, RoHS:Y
  • 371-4180
  • 2GB DDR667/PC2-5300 DIMM, RoHS:Y
  • 371-4681
  • 2.6 GHz CPU, Opteron 2435 6-Core, D0 Stepping, 75W, RoHS:Y
  • 541-3758
  • System Controller Assembly, RoHS:YL
  • 501-7818
  • CPU/Memory Board, RoHS:YL
  • 371-2210
  • CR2032 3V Battery, RoHS:Y
  • 501-7819
  • I/O Board, RoHS:YL
  • 541-0487
  • System Controller Enclosure, RoHS:Y

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

Request Quote
Greentec Systems We geek out helping you with your IT infrastructure.
Request a quote or product information
Send
