Oracle Sun X4170 Server

Oracle Sun X4170 Server Oracle Sun X4170 Server Sun Servers SUN FIRE X4170 copy

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*




    Processor
    Number 1 to 2 Quad-Core or 6-Core
    Architecture Type: Intel Xeon Quad-Core or 6-Core Processors
    CPUs Intel 2.40GHz Quad-Core Xeon L5620 (12MB L2, 80W)
    Intel 2.26GHz 6-Core Xeon L5640 (12MB L2, 60W)
    Intel 2.93GHz 6-Core Xeon E5670 (12MB L2, 95W)
    Main Memory
    Capacities Total DIMM slots: 18
    DIMM type: DDR3 1066MHz or 1333MHz Registered DIMMs
    DIMM size: 4-GB 1333MHz or 8-GB 1066MHz
    Maximum capacity: 144GB (when configured with 8-GB DIMMs)
    Standard Integrated Interfaces
    Network Four 10/100/1000 Base-T Ethernet Ports
    Network Management One dedicated 10/100Base-T Ethernet port
    Serial Management One dedicated TIA/EIA-232-F asynchronous RJ45 port
    SAS Four channel SAS interface, internal access only
    USB Front: Two USB 2.0 ports
    Rear: Two USB 2.0 ports
    Internal: One USB 2.0 port (for a USB thumb drive)
    PCI Expansion Slots Three low profile PCI Express 2.0 slots (1 x16 electrical/mechanical, 2 x8 electrical/mechanical)
    Internal Mass Storage
    Disks SAS: Up to eight 2.5″ SAS Disks or four solid-state drives (SSDs) with add-on SAS Host Bus Adapter
    (300GB – 10000 RPM SAS or 146GB – 10000 RPM SAS or 32GB SOLID STATE SATA)
    FMOD: Up to two 24GB flash memory modules (An optional energy storage module (ESM) is required).
    DVD-ROM One SATA DVD+/-RW drive
    Power Supplies
    Dual redundant, hot swappable power supplies
    (Power supply rating output = 760W)
    (UL Maximum AC input = 760W x 1.33 efficiency = 1010W)
    (9.0 Amps RMS at 100 VAC)
    Environment
    AC power 100-120 / 200-240 VAC (50-60 Hz)
    Temperature Single, non-rack system:
    Operating: 5° C to 35° C (41° F to 95° F)
    Nonoperating: -40° C to 70° C (-40° F to 158° F)
    Humidity Single, non-rack system:
    Operating: 10% to 90% relative humidity noncondensing, 27° C (80.6° F) max wet bulb
    Nonoperating: up to 93% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
    Altitude Single, non-rack system:
    Operating: up to 3000 m (9,843 ft.), maximum ambient temperature is derated by 1° C per 300 m above 900 m
    Nonoperating: up to 12,000 m (40,000 ft.)
    Regulations
    Meets or exceeds the following requirements:
    RoHS Compliance Level RoHS:YL
    Safety UL 60950-1 2nd Ed, EN60950-1:2006 2nd Ed, CB Scheme with all country differences
    RFI/EMI FCC CFR 47 Part 15 Subpart B Class A, EN55022:2006+A1:2007 Class A, EN 61000-3-2, EN61000-3-3, EN 300-386
    Immunity EN55024, EN300-386
    Certifications Safety: UL/cUL, UL DEMKO, CE, BSMI, CCC, GOST-R, S-Mark
    EMC: CE, FCC, VCCI, ICES, C-Tick, MIC, CCC, GOST-R, BSMI Class A
    Dimensions and Weight
    Height 43.43 mm (1.71 in.)
    Width 425.5 mm (16.75 in.)
    Depth 685.8 mm (27.0 in.)
    Weight 16.36 kg (36 lb.) maximum assuming PCI-Express card weighs 0.12 kg
    (0.25 lb) each, and without the rack mounting slide rail kit installed.
    CPU Module
    Option # Manufacturing
    Part #
    Description
    X5921A-1U 371-4889 2.93GHz Intel 6-Core Xeon X5670, 12MB, 95W, RoHS:Y
    541-2545 Xeon Heatsink w/Grease, RoHS:Y
    X5924A-1U 371-4885 2.4GHz Intel Quad-Core Xeon E5620, 12MB, 80W, RoHS:Y
    541-2545 Xeon Heatsink w/Grease, RoHS:Y
    X5925A-1U 371-4887 2.26GHz Intel 6-Core Xeon L5640, 12MB, 60W, RoHS:Y
    541-2545 Xeon Heatsink w/Grease, RoHS:Y
    Communication
    Option # Manufacturing
    Part #
    Description
    X4237A-N 375-3606 Sun Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express, RoHS:Y
    Disk Backplane
    Option # Manufacturing
    Part #
    Description
    n/a 511-1548 8-Slot Disk Backplane, SATA DVD, RoHS:Y
    Disks
    Option # Manufacturing
    Part #
    Description
    XRA-SS2CF300G10K-N 540-7869 300GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0449
    • Seagate ST93000SSUNG [ST930003SSUN300G]
      (300GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0451
    • Hitachi HUC103030CSS600 [H103030SCSUN300G]
      (300GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRA-ST2CF32G2SSD-N 540-7841 32GB Solid State Drive Assembly, SATA Interface, RoHS:Y
    • 371-4196
    • 32GB Solid State Drive, SATA Interface, RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRB-SS2CF146G10K-N 540-7868 146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0448
    • Seagate ST9146803SS [ST914603SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0450
    • Hitachi HUC103014CSS600 [H103014SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRB-ST2CF-500G7K 542-0371 500GB – 7200 RPM SATA Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0468
    • Seagate ST9500530NS [ST95000NSSUN500G]
      (500GB – 7200 RPM – SATA Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #
    Description
    X1109A-Z 375-3617 Dual 10-Gigabit Ethernet SFP+ LP, RoHS:Y
    X2129A-N 530-4449 10Gbps Short Wave Pluggable (SFP+) Transceiver, RoHS:Y
    X2130A-10M-N 530-4454 Sun 10Gbps SFP+ TwinX Cable, 10m, RoHS:Y
    X2130A-1M-N 530-4441 Sun 10Gbps SFP+ TwinX Cable, 1m, RoHS:Y
    X2130A-3M-N 530-4442 Sun 10Gbps SFP+ TwinX Cable, 3m, RoHS:Y
    X2130A-5M-N 530-4443 Sun 10Gbps SFP+ TwinX Cable, 5m, RoHS:Y
    X4446A-Z-N 375-3481 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    Fan
    Option # Manufacturing
    Part #
    Description
    n/a 541-4274 Fan Board Assembly, RoHS:Y
    • 330-5274
    • Fan Deck, RoHS:Y
    • 511-1490
    • Fan Board, RoHS:Y
    n/a 541-4276 Fan Module, RoHS:Y
    • 371-4789
    • 40x56mm, 15300 RPM Fan, RoHS:Y
    Fibre Channel
    Option # Manufacturing
    Part #
    Description
    SG-XPCIE1FC-EM8-Z 371-4295 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-QF8-Z 371-4324 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-EM8-Z 371-4306 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-QF8-Z 371-4325 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    I/O
    Option # Manufacturing
    Part #
    Description
    n/a 541-2883 1-Slot x8 PCI Express Riser Assembly, RoHS:Y
    • 501-7967
    • 1-Slot x8 PCI Express Riser, RoHS:Y
    • 541-2924
    • Riser Mounting Bracket, RoHS:Y
    n/a 541-2885 1-Slot x16 PCI Express Riser Assembly, RoHS:Y
    • 501-7965
    • 1-Slot x16 PCI Express Riser, RoHS:Y
    • 541-2924
    • Riser Mounting Bracket, RoHS:Y
    Memory
    Option # Manufacturing
    Part #
    Description
    X4851A 371-4899 8GB Registered DDR3-1066 DIMM, RoHS:Y
    X4910A 371-4965 4GB Registered DDR3-1333 DIMM, RoHS:Y
    X4911A 371-4966 8GB Registered DDR3-1333 DIMM, RoHS:Y
    XRA-S-4G2-USB2 371-4743 4GB USB 2.0 Flash Drive, RoHS:Y
    X4850A 371-4898 4GB Registered DDR3-1333 DIMM, RoHS:Y
    XRA-ST3C-24G2FMD 371-4531 24GB SATA-based Sun Flash Module, RoHS:Y
    Power
    Option # Manufacturing
    Part #
    Description
    X5932A 300-2233 Type A247 760 Watt Power Supply, RoHS:Y
    n/a 511-1489 Power Distribution Board, RoHS:Y
    Rack
    Option # Manufacturing
    Part #
    Description
    X6324A-N 371-2742 Cable Management Arm, RoHS:Y
    X6325A-N 371-2740 Snap-In Slide Rail Rackmount Kit, 730mm, RoHS:Y
    X6326A-N 371-2741 Screw-Mount Slide Rail Rackmount Kit, 730mm, RoHS:Y
    Removable Media
    Option # Manufacturing
    Part #
    Description
    X8325A-N 541-3493 SATA DVD-Writer/CD-Writer – USB Board Assembly, RoHS:Y
    • 330-5056
    • DVD Interconnect Holder, RoHS:Y
    • 390-0442
    • 8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
    • 390-0443
    • 8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
    • 501-7698
    • USB Board, RoHS:Y
    • 541-3686
    • DVD Bezel, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #
    Description
    SGX-SAS6-INT-Z 375-3640 8-Port 6Gbps SAS-2 HBA, RoHS:Y
    SGX-SAS6-R-INT-Z 371-4746 6Gigabit SAS RAID PCI Battery Module, BBU07, RoHS:Y
    375-3644 6Gigabit SAS RAID PCI Express HBA, B2 ASIC, RoHS:Y
    System Board
    Option # Manufacturing
    Part #
    Description
    n/a 541-4081 System Board Assembly/FRU, RoHS:Y
    • 511-1213
    • System Board, RoHS:Y
    • 150-3993
    • Panasonic BR2032 Battery, RoHS:Y
    • 541-2543
    • System Board Tray, RoHS:Y
