Oracle Sun M9000 Server

Oracle Sun M9000 Server Oracle Sun M9000 Server Sun Servers SUN FIRE m9000 copy

REQUEST A PRICE QUOTE:

Name*

Phone

Details*





Processor
Number M9000-32 SPARC64 VI: Up to 32 CPUs (64 Cores)
M9000-32 SPARC64 VII: Up to 32 CPUs (128 Cores)
M9000-64 SPARC64 VI: Up to 64 CPUs (128 Cores)
M9000-64 SPARC64 VII: Up to 64 CPUs (256 Cores)
Architecture SPARC64 VI: 2.28GHz and 2.4GHz SPARC V9, ECC protected
SPARC64 VII: 2.52GHz SPARC V9, ECC protected
Cache memory SPARC64 VI: 6MB Shared Level 2 on Chip Cache per Processor, 128KB I-Cache and 128KB D-Cache Level 1 per Core
SPARC64 VII: 6MB Shared Level 2 on Chip Cache per Processor, 64KB I-Cache and 64KB D-Cache Level 1 per Core
System Boards
CPU/Memory Units (CMU) M9000-32: Up to 8
M9000-64: Up to 16
I/O M9000-32: Up to 16 External I/O Expansion Units
M9000-64: Up to 16 External I/O Expansion Units
eXtended System Control Facility Unit (XSCFU) M9000-32: 2
M9000-64: 4
Maximum Number of Domains 24
Main Memory
M9000-32: Maximum 2TB using 8GB DIMMs, 256 DIMM slots
M9000-64: Maximum 4TB using 8GB DIMMs, 512 DIMM slots
Standard Interfaces
Ethernet 2 &215; 10/100 XSCF-LAN Ports per XSCFU
PCI Express M9000-32: 64 Slots, expandable up to 224 Slots, via optional external I/O Expansion Units
M9000-64: 128 Slots, expandable up to 288 Slots, via optional external I/O Expansion Units
Serial 1 RJ-45 per XSCFU
USB 1 port per XSCFU that a field engineer can use to download hardware information
Internal Mass Storage
Disks M9000-32: Up to 32 disks, 4 per I/O Unit
M9000-64: Up to 64 disks, 4 per I/O Unit
DVD-ROM 1 per cabinet
Tape 1 Optional DAT72 Tape Drive per cabinet
Power Supplies
M9000-32: 15 Power Supply Units (PSU) M9000-32 Base
M9000-64: 30 Power Supply Units (PSU) M9000-64 Base
Environment
AC power 200 to 240 VAC, 50-60Hz
Power Consumption M9000-32: 21.3 kW (8 CMUs and 8 IOUs installed)
M9000-64: 42.6 kW (16 CMUs and 16 IOUs installed)
Apparent Power M9000-32: 22.4 kVA (8 CMUs and 8 IOUs installed)
M9000-64: 44.8 kVA (16 CMUs and 16 IOUs installed)
Power Factor 0.9 or higher
Rush Current 100A0-p or less (current for each cable)
Leak Current 30mA or less
Heat output (cooling requirement) See Sun SPARC Enterprise M8000/M9000 Servers Site Planning Guide (819-4203)
There are a number of different power options available for the M9000. For more specific details on the specifications related to them, please see the Sun SPARC Enterprise M8000/M9000 Servers Site Planning Guide (819-4203).
Power cords See Sun SPARC Enterprise M8000/M9000 Servers Site Planning Guide (819-4203).
Temperature Operating:
Altitude 0 to less than 1500 Meters (0 – 4920 ft):
5° C to 32° C ( 41° F to 89.6° F)
Altitude 1500 to less than 2000 Meters (4921 – 6561 ft): 5° C to 30° C ( 41° F to 86° F)
Altitude 2000 to less than 2500 Meters (6562 – 8201 ft): 5° C to 28° C ( 41° F to 82.4° F)
Altitude 2500 to less than 3000 Meters (8202 – 9843 ft): 5° C to 26° C ( 41° F to 78.8° F)
Nonoperating: 0° C to 50° C ( 32° F to 122° F)
Humidity Operating: 20% to 80% relative humidity, noncondensing
Nonoperating: 8% to 80% relative humidity, noncondensing
Altitude Up to 3000M (9843 ft)
Regulations
Meets or exceeds the following requirements:
Safety CSA/UL-60950, EN60950, IEC950 CB Scheme with all national deviations
RFI/EMI EN55022/CISPR22 Class A, FCC CFR47 Part 15 Class A, EN61000-3-2, EN61000-3-3
Immunity EN55024, EN61000-4-2, -4-3. -4-5. -4-6, -4-8, and -4/11
Regulatory Markings CE, FCC, ICES, C-tick, VCCI, GOST-R, BSMI, MIC, CSA/UL
RoHS Compliance Level RoHS:YL
Other Marks WEEE and China RoHS
Dimensions and Weights
Height M9000-32: 180 cm (70.9 in)
M9000-64: 180 cm (70.9 in)
Width M9000-32: 85 cm (33.5 in)
M9000-64: 167.4 cm (65.9 in)
Depth M9000-32: 126 cm (49.6 in)
M9000-64: 126 cm (49.6 in)
Weight M9000-32: 940 kg (2072 lbs)
M9000-64: 1880 kg (4145 lbs)
Backplane/Centerplane
Option # Manufacturing
Part #
Description
n/a 371-2220 Power Supply Backplane A, PSUBP_A, RoHS:Y
n/a 371-2222 Fan Backplane A, FANBP_A, RoHS:Y
n/a 371-2223 Fan Backplane B, FANBP_B, RoHS:Y
n/a 371-2226 Backplane B, BP_B, RoHS:Y
n/a 371-2243 Switch Backplane, SWBP, RoHS:Y
n/a 371-2244 Media Backplane, MEDBP, RoHS:Y
CPU Module
Option # Manufacturing
Part #
Description
SEMX1A1Z 2× 2.28GHz SPARC64 VI CPU Module X-Option, RoHS:YL
371-2215 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
SEMX1B1Z 2× 2.4GHz SPARC64 VI CPU Module X-Option, RoHS:YL
371-2216 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
SEMX1D1Z 2× 2.88GHz SPARC64 VII CPU Module X-Option, RoHS:YL
371-4616 2.88GHz/6MB Cache SPARC64 VII CPU Module, RoHS:YL
SEMX1C1Z 2× 2.52GHz SPARC64 VII CPU Module X-Option, RoHS:YL
375-3580 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
Cables
Option # Manufacturing
Part #
Description
SEMX9P31Z 371-2430 AC Power Cord US,1-Phase NEMA L6-30P, RoHS:Y
SEMX9P41Z 180-2192 AC Power Cord INTL, 1-Phase IEC 320, 32A,250V plug, RoHS:Y
SEMX9P11Z 371-2430 AC Power Cord US,1-Phase NEMA L6-30P, RoHS:Y
SEMX9P1Z 371-2430 AC Power Cord US,1-Phase NEMA L6-30P, RoHS:Y
SEMX9P21Z 371-2431 AC Power Cord INTL, 1-Phase IEC 320, 32A,250V plug, RoHS:Y
SEMX9P2Z 371-2431 AC Power Cord INTL, 1-Phase IEC 320, 32A,250V plug, RoHS:Y
n/a 371-2231 CLKU B Clock Cable, RoHS:Y
n/a 371-2232 CLKU B Data Cable, RoHS:Y
n/a 371-2233 XBU B Clock Cable, RoHS:Y
n/a 371-2234 XBU B Data Cable, RoHS:Y
n/a 371-2235 XSCFU B B/C Data Cable, RoHS:Y
n/a 537-1070 Fibre Channel Optical Cable 25M, RoHS:Y
n/a 537-1100 Fibre Channel Optical Cable 10M, RoHS:Y
Communication
Option # Manufacturing
Part #
Description
X4237A 375-3606 Sun Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express, RoHS:Y
X6000A 375-3424 PCI Express Sun Crypto Accelerator 6000, RoHS:Y
X2156A 375-0100 Serial Asynchronous Interface PCI (SAI/P) 3.0
Disks
Option # Manufacturing
Part #
Description
SEMX3B11Z 540-7407 146GB 10000 RPM SAS Disk Drive Assembly, RoHS:Y
  • 390-0324
  • Seagate ST9146802SS [ST914602SSUN146G]
    (146GB – 10000 RPM – SAS Disk), RoHS:Y
  • 390-0375
  • Fujitsu MBB2147RC [MBB2147RCSUN146G]
    (146GB – 10000 RPM – SAS Disk), RoHS:Y
  • 390-0448
  • Seagate ST9146803SS [ST914603SSUN146G]
    (146GB – 10000 RPM – SAS Disk), RoHS:Y
  • 390-0450
  • Hitachi HUC103014CSS600 [H103014SCSUN146G]
    (146GB – 10000 RPM – SAS Disk), RoHS:Y
  • 541-0239
  • Nemo Bracket, RoHS:Y
  • 541-3004
  • Nemo Bracket with Insulator, RoHS:Y
SEMX3C11Z 540-7988 300GB 10000 RPM SAS Disk Drive Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
  • 390-0449
  • Seagate ST93000SSUNG [ST930003SSUN300G]
    (300GB – 10000 RPM – SAS Disk), RoHS:Y
  • 541-3004
  • Nemo Bracket with Insulator, RoHS:Y
SEMX3A11Z 540-7296 73GB 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
  • 390-0285
  • Fujitsu MAY2073RC [MAY2073RCSUN72]
    (73GB – 10000 RPM – SAS Disk), RoHS:Y
  • 390-0323
  • Seagate ST973402SS [ST973402SSUN72G]
    (73GB – 10000 RPM – SAS Disk), RoHS:Y
  • 390-0374
  • Fujitsu MBB2073RC [MBB2073RCSUN72G]
    (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
  • 541-0239
  • Nemo Bracket, RoHS:Y
Ethernet
Option # Manufacturing
Part #
Description
SG-XPCIEFCOE2-Q-SR 375-3681 Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR, RoHS:Y
SG-XPCIEFCOE2-Q-TA 375-3682 Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – Direct Attach, RoHS:Y
X1027A-Z 501-7283 PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y
X4447A-Z 511-1422 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
  • 371-2207
  • Bracket Low-Profile, RoHS:Y
560-2884 Ship Kit for Gigabit Ethernet options
  • 371-2348
  • Bracket Standard, RoHS:Y
X5558A 375-3301 10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
X5560A-Z 375-3495 10Gb/sec XFP Optical Transceiver Long Range (LR), RoHS:Y
X7280A-2 371-0905 PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
X7281A-2 371-0904 PCI Express Dual Gigabit Ethernet MMF, RoHS:Y
n/a 501-7606 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
  • 371-2207
  • Bracket Low-Profile, RoHS:Y
  • 371-2348
  • Bracket Standard, RoHS:Y
Fan
Option # Manufacturing
Part #
Description
n/a 371-2237 3-Fan Fan Assembly, FAN_A, RoHS:Y
n/a 555-1947 Fan Tray Retention Kit for M9000
  • 240-7136
  • Hinge Pin, 2mm
  • 345-1443
  • Hinge Pin Extraction Tool
  • 541-3407
  • Fan Tray Bracket Assembly – Rear Right (M8000) or Front (M9000)
  • 541-3410
  • Fan Tray Bracket Assembly – Rear (M9000)
Fibre Channel
Option # Manufacturing
Part #
Description
SG-XPCI1FC-EM4-Z 375-3398 4Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-QF4 375-3354 4Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI2FC-EM4-Z 375-3399 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
SG-XPCI2FC-QF4 375-3294 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
SG-XPCIE1FC-EM4 375-3396 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-EM8-Z 371-4295 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF4 375-3355 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF8-Z 371-4324 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM4 375-3397 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM8-Z 371-4306 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF4 375-3356 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF8-Z 371-4325 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
I/O
Option # Manufacturing
Part #
Description
SEMX61Z 371-2217 I/O Unit, RoHS:Y
  • 371-2575
  • I/O Unit Air Filter, 290mm × 28mm
  • 371-2576
  • I/O Unit Air Filter, 99mm × 23mm
SEMX7BS1Z 371-2245 IOU Device Mounting Card A, IOUA, RoHS:Y
SENX8LK2Z 596-6258 Fibre Link Card Kit w/ 2 × Cards & 2 × 10M Cables (for External I/O Expansion Unit), RoHS:Y
  • 501-7040
  • Fibre Link Card, RoHS:Y
  • 537-1100
  • Fibre Channel Optical Cable 10M, RoHS:Y
SENX8LK3Z 596-6228 Fibre Link Card Kit w/ 2 × Cards & 2 × 25M Cables (for External I/O Expansion Unit), RoHS:Y
  • 501-7040
  • Fibre Link Card, RoHS:Y
  • 537-1070
  • Fibre Channel Optical Cable 25M, RoHS:Y
n/a 371-2246 PCI Cassette, PCICS, RoHS:Y
Memory
Option # Manufacturing
Part #
Description
SEMX2B2Z 16× 2GB Memory Expansion X-Option, RoHS:YL
511-1284 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX2C1Z 16× 4GB Memory Expansion X-Option, RoHS:YL
501-7793 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX2D1Z 16× 8GB Memory Expansion X-Option, RoHS:YL
511-1379 8GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX2A1Z 16× 1GB Memory Expansion X-Option, RoHS:YL
501-7791 1GB DDR2-533/DDR2-667 1-Rank DIMM, RoHS:Y
SEMX2B1Z 16× 2GB Memory Expansion X-Option, RoHS:YL
501-7792 2GB DDR2-533/DDR2-667 2-Rank DIMM, RoHS:Y
Miscellaneous
Option # Manufacturing
Part #
Description
n/a 371-2230 Clock Control Unit B, CLKU_B, RoHS:YL
n/a 371-2239 Operator Panel, OPNL, RoHS:Y
  • n/a
  • Operator Panel Key
n/a 371-2240 Crossbar Unit, XBU_B, RoHS:Y
n/a 371-2242 Temperature/Humidity Sensor Unit, SNSU, RoHS:Y
n/a 371-2574 M9000 Air Filter, RoHS:YL
n/a 555-1959 XBU Mitigation Kit
  • 250-1974
  • 28 In-Oz Preset Torque Driver for XBU
Power
Option # Manufacturing
Part #
Description
SEHX9DP1Z 371-2720 M9000 Single Phase Dual Feed Power Assembly, RoHS:Y
  • 371-2219
  • Power Supply, PSU, RoHS:Y
  • 371-2220
  • Power Supply Backplane A, PSUBP_A, RoHS:Y
  • 371-2387
  • AC Section B, Single Phase, ACS_B, RoHS:Y
n/a 371-2383 AC Section D, Three Phase, ACS_D, RoHS:Y
n/a 371-2388 AC Section C, Three Phase Delta, ACSTPH_C, RoHS:Y
n/a 371-2389 AC Power Section D, Three Phase Star, ACSTPH_D, RoHS:Y
n/a 371-4650 Energy Storage Module (ESM), RoHS:Y
Removable Media
Option # Manufacturing
Part #
Description
SEMX9DT1Z 390-0342 DAT72 Tape Drive, RoHS:Y
n/a 390-0343 DVD-ROM, ROHS:Y
n/a 390-0478 DVD-ROM, ROHS:Y
SCSI
Option # Manufacturing
Part #
Description
SG-XPCI2SCSI-LM320 375-3191 PCI/PCI-X Dual Ultra320 SCSI Adapter
SG-XPCI8SAS-E-Z 375-3488 3Gb PCI-X SAS 8-Port Host Adapter, RoHS:Y
SG-XPCIE2SCSIU320Z 375-3357 Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
SG-XPCIE8SAS-E-Z 375-3487 PCI Express 8-Port Host Adapter, RoHS:Y
SGXPCIESAS-R-EXT-Z 371-3253 Lithium Ion Battery Module
375-3537 8-Port SAS RAID External HBA, RoHS:Y
XTA-FAS-S3IE96GB 541-3731 96GB PCI Express Flash Accelerator F20 SAS HBA, RoHS:Y
  • 371-4415
  • 24GB Solid State Flash Memory Module, RoHS:Y
  • 371-4650
  • Energy Storage Module (ESM), RoHS:Y
  • 511-1500
  • PCI Express Flash Board, RoHS:Y
System Board
Option # Manufacturing
Part #
Description
SEMX4AC2Z 594-5985 CPU/Memory Unit (CMU) w/ 2× SPARC64 VI 2.28GHz, 32GB (16× 2GB 1-Rank)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4AE1Z 596-6658 CPU/Memory Unit (CMU) w/ 2× SPARC64 VI 2.28GHz, 64GB (16× 4GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4BC2Z 594-5986 CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.28GHz, 32GB (16× 2GB 1-Rank)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4BE1Z 596-6664 CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.28GHz, 64GB (16× 4GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4CC2Z 594-5987 CPU/Memory Unit (CMU) w/ 2× SPARC64 VI 2.4GHz, 32GB (16× 2GB 1-Rank)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4CE1Z 596-6661 CPU/Memory Unit (CMU) w/ 2× SPARC64 VI 2.4GHz, 64GB (16× 4GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4DC2Z 594-5988 CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.4GHz, 32GB (16× 2GB 1-Rank)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4DE1Z 596-6667 CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.4GHz, 64GB (16× 4GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4GC1Z 594-6276 CPU/Memory Unit (CMU) w/ 2× SPARC64 VII 2.88GHz, 32GB (16× 2GB), RoHS:YL
  • 371-4616
  • 2.88GHz/6MB Cache SPARC64 VII CPU Module, RoHS:YL
  • 371-4617
  • CPU/Memory Unit (CMU) with MAC+, 0MB, RoHS:YL
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4GE1Z 594-6277 CPU/Memory Unit (CMU) w/ 2× SPARC64 VII 2.88GHz, 64GB (16× 4GB), RoHS:YL
  • 371-4616
  • 2.88GHz/6MB Cache SPARC64 VII CPU Module, RoHS:YL
  • 371-4617
  • CPU/Memory Unit (CMU) with MAC+, 0MB, RoHS:YL
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4GG1Z 594-6278 CPU/Memory Unit (CMU) w/ 2× SPARC64 VII 2.88GHz, 128GB (16× 8GB), RoHS:YL
  • 371-4616
  • 2.88GHz/6MB Cache SPARC64 VII CPU Module, RoHS:YL
  • 371-4617
  • CPU/Memory Unit (CMU) with MAC+, 0MB, RoHS:YL
  • 511-1379
  • 8GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4HC1Z 594-6279 CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.88GHz, 32GB (16× 2GB), RoHS:YL
  • 371-4616
  • 2.88GHz/6MB Cache SPARC64 VII CPU Module, RoHS:YL
  • 371-4617
  • CPU/Memory Unit (CMU) with MAC+, 0MB, RoHS:YL
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4HE1Z 594-6280 CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.88GHz, 64GB (16× 4GB), RoHS:YL
  • 371-4616
  • 2.88GHz/6MB Cache SPARC64 VII CPU Module, RoHS:YL
  • 371-4617
  • CPU/Memory Unit (CMU) with MAC+, 0MB, RoHS:YL
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4HG1Z 594-6281 CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.88GHz, 128GB (16× 8GB), RoHS:YL
  • 371-4616
  • 2.88GHz/6MB Cache SPARC64 VII CPU Module, RoHS:YL
  • 371-4617
  • CPU/Memory Unit (CMU) with MAC+, 0MB, RoHS:YL
  • 511-1379
  • 8GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX5BD2Z 597-0020 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.28GHz, 64GB (32× 2GB 1-Rank)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX5BF1Z 596-6673 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.28GHz, 128GB (32× 4GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX5DF1Z 596-6676 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.4GHz, 128GB (32× 4GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX5HD1Z 594-6282 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.88GHz, 64GB (32× 2GB), RoHS:YL
  • 371-4616
  • 2.88GHz/6MB Cache SPARC64 VII CPU Module, RoHS:YL
  • 371-4617
  • CPU/Memory Unit (CMU) with MAC+, 0MB, RoHS:YL
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX5HF1Z 594-6283 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.88GHz, 128GB (32× 4GB), RoHS:YL
  • 371-4616
  • 2.88GHz/6MB Cache SPARC64 VII CPU Module, RoHS:YL
  • 371-4617
  • CPU/Memory Unit (CMU) with MAC+, 0MB, RoHS:YL
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX5HH1Z 594-6284 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.88GHz, 256GB (32× 8GB), RoHS:YL
  • 371-4616
  • 2.88GHz/6MB Cache SPARC64 VII CPU Module, RoHS:YL
  • 371-4617
  • CPU/Memory Unit (CMU) with MAC+, 0MB, RoHS:YL
  • 511-1379
  • 8GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4AA1Z 596-6656 CPU/Memory Unit (CMU) w/ 2× SPARC64 VI 2.28GHz, 16GB (16× 1GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7791
  • 1GB DDR2-533/DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4AC1Z 596-6657 CPU/Memory Unit (CMU) w/ 2× SPARC64 VI 2.28GHz, 32GB (16× 2GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7792
  • 2GB DDR2-533/DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4BA1Z 596-6662 CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.28GHz, 16GB (16× 1GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7791
  • 1GB DDR2-533/DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4BC1Z 596-6663 CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.28GHz, 32GB (16× 2GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7792
  • 2GB DDR2-533/DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4CA1Z 596-6659 CPU/Memory Unit (CMU) w/ 2× SPARC64 VI 2.4GHz, 16GB (16× 1GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7791
  • 1GB DDR2-533/DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4CC1Z 596-6660 CPU/Memory Unit (CMU) w/ 2× SPARC64 VI 2.4GHz, 32GB (16× 2GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7792
  • 2GB DDR2-533/DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4DA1Z 596-6665 CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.4GHz, 16GB (16× 1GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7791
  • 1GB DDR2-533/DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4DC1Z 596-6666 CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.4GHz, 32GB (16× 2GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7792
  • 2GB DDR2-533/DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4EA1Z 596-7527 CPU/Memory Unit (CMU) w/ 2× SPARC64 VII 2.52GHz, 16GB (16× 1GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 501-7791
  • 1GB DDR2-533/DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4EC1Z 596-7544 CPU/Memory Unit (CMU) w/ 2× SPARC64 VII 2.52GHz, 32GB (16× 2GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 501-7792
  • 2GB DDR2-533/DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4EC2Z 594-5989 CPU/Memory Unit (CMU) w/ 2× SPARC64 VII 2.52GHz, 32GB (16× 2GB 1-Rank)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4EE1Z 596-7545 CPU/Memory Unit (CMU) w/ 2× SPARC64 VII 2.52GHz, 64GB (16× 4GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4EG1Z 594-6150 CPU/Memory Unit (CMU) w/ 2× SPARC64 VII 2.52GHz, 128GB (16× 8GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 511-1379
  • 8GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4FA1Z 596-7539 CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.52GHz, 16GB (16× 1GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 501-7791
  • 1GB DDR2-533/DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4FC1Z 596-7540 CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.52GHz, 32GB (16× 2GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 501-7792
  • 2GB DDR2-533/DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4FC2Z 594-5990 CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.52GHz, 32GB (16× 2GB 1-Rank)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX4FE1Z 596-7541 CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.52GHz, 64GB (16× 4GB), RoHS:Y
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX4FG1Z 594-6151 CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.52GHz, 128GB (16× 8GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 511-1379
  • 8GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX5BB1Z 596-6671 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.28GHz, 32GB (32× 1GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7791
  • 1GB DDR2-533/DDR2-667 1-Rank DIMM, RoHS:Y
SEMX5BD1Z 596-6672 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.28GHz, 64GB (32× 2GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2215
  • 2.28GHz/5MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7792
  • 2GB DDR2-533/DDR2-667 2-Rank DIMM, RoHS:Y
SEMX5DB1Z 596-6674 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.4GHz, 32GB (32× 1GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7791
  • 1GB DDR2-533/DDR2-667 1-Rank DIMM, RoHS:Y
SEMX5DD1Z 596-6675 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VI 2.4GHz, 64GB (32× 2GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 371-2216
  • 2.4GHz/6MB Cache SPARC64 VI CPU Module, RoHS:Y
  • 501-7792
  • 2GB DDR2-533/DDR2-667 2-Rank DIMM, RoHS:Y
SEMX5FB1Z 596-7546 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.52GHz, 32GB (32× 1GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 501-7791
  • 1GB DDR2-533/DDR2-667 1-Rank DIMM, RoHS:Y
SEMX5FD1Z 596-7547 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.52GHz, 64GB (32× 2GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 501-7792
  • 2GB DDR2-533/DDR2-667 2-Rank DIMM, RoHS:Y
SEMX5FD2Z 597-0022 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.52GHz, 64GB (32× 2GB 1-Rank)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 511-1284
  • 2GB DDR2-667 1-Rank DIMM, RoHS:Y
SEMX5FF1Z 596-7548 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.52GHz, 128GB (32× 4GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 501-7793
  • 4GB DDR2-667 2-Rank DIMM, RoHS:Y
SEMX5FH1Z 594-6152 Capacity On Demand (COD) CPU/Memory Unit (CMU) w/ 4× SPARC64 VII 2.52GHz, 256GB (32× 8GB)
  • 371-2214
  • CPU/Memory Unit (CMU), 0MB, RoHS:Y
  • 375-3580
  • 2.52GHz/6MB Cache SPARC64 VII CPU Module, RoHS:Y
  • 511-1379
  • 8GB DDR2-667 2-Rank DIMM, RoHS:Y
System Service Processor
Option # Manufacturing
Part #
Description
n/a 371-2228 eXtended System Control Facility Unit B, XSCF_B, RoHS:Y
n/a 371-2229 eXtended System Control Facility Unit C, XSCF_C, RoHS:Y

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

Request Quote
Greentec Systems We geek out helping you with your IT infrastructure.
Request a quote or product information
Send
