Oracle Sun 3500 Server
REQUEST A PRICE QUOTE:
| Processor | |
| Number | One to eight |
| Architecture | 167 MHz UltraSPARC[tm]; 250 MHz, 336 MHz, 400 MHz, or 464 MHz UltraSPARC II |
| Cache per processor | Primary: 16-KB instruction, and 16-KB data on chip Secondary: Up to 8-MB external cache |
| CPU interface | One to eight, 128-bit Ultra Port Architecture (UPA) slots |
| System Interconnect | Gigaplane[tm], 2.68 GB/sec (at 84 MHz), 3.2 GB/sec (at 100 MHz) |
| System Boards | |
| Number of boards | Maximum of five boards per system (four CPU/Memory boards and one I/O board)
Minimum configuration requires one CPU/Memory board and one I/O board |
| CPU/Memory board | Holds up to two processors and 16 memory SIMMs |
| SBus I/O board | Offers two SBus channels, three SBus slots, SunFastEthernet[tm], fast/wide SCSI-2, two FC-AL sockets |
| Graphics I/O board | Offers one SBus channel, two SBus slots, one UPA slot for Creator and Creator3D graphics, SunFastEthernet, fast/wide SCSI-2, two FC-AL sockets |
| PCI I/O board | Offers four PCI channels, two (short) PCI slots, SunFastEthernet, fast/wide SCSI-2 |
| Main Memory | |
| 64-MB to 4-GB memory capacity per CPU/Memory board
Up to 2-GB memory expansion options (each a group of 8 SIMMs) |
|
| Standard Interfaces | |
| Ethernet | One ethernet/fast ethernet (10BASE-T/100BASE-T) twisted-pair standard connector (RJ-45) One MII for external transceiver connection (available only on SBus and Graphics I/O boards) |
| FC-AL | Two on-board sockets for GBIC modules (100 MB/sec, full duplex) supporting Fibre Channel Arbitrated Loop (FC-AL) (available only on SBus and Graphics I/O boards) |
| Keyboard and mouse | One standard keyboard/mouse port (mini DIN-8) on clock board |
| PCI | Two PCI short slots per PCI I/O board operating at 33- or 66-MHz, 32- or 64-bit data bus width, 3.3 or 5 volts (Note: Install appropriate voltage riser card in slot before installing PCI card.) |
| SBus | Three slots operating at 25-MHz, 64-bit data bus width |
| Serial | Two RS-232C/RS423 serial ports (DB25) on clock board |
| SCSI | One 20-MB/sec, 68-pin, fast/wide SCSI-2 (synchronous) per I/O board |
| Internal Mass Storage | |
| Internal disk | Maximum eight 3.5-in. hot-swappable FC-AL disk drives with dual connections |
| Internal tape | 8mm, 4mm, and 1/4″ tape options available |
| CD-ROM/DVD-ROM | SunCD[tm] 32 drive standard (last order December 2000)
10X DVD-ROM drive standard (capable of reading CD-ROM media only) |
| Power Supplies | |
| One 184-watt AC Inlet/Peripheral Power Supply standard. Optional, 195-watt Second Peripheral Power Supply available. Up to three hot swappable 300-watt Power Cooling Modules (PCM) with redundant, dual-speed fans. One PCM required per two systems boards. Fully-redundant power and cooling available on this system. |
|
| Environment | |
| AC input | 100 – 240 VAC, 47 – 63 Hz, 9.5 A(max) |
| Input power | 875 W |
| Heat output | 3000 BTU/hr |
| Temperature1 |
Optimal: 21° C to 23° C (70° F to 73.5° F) Operating: 5° C to 40° C (41° F to 104° F) Nonoperating: -20° C to 60° C (-4° F to 140° F) |
| Humidity |
Optimal: 45% to 50% relative humidity Operating: 20% to 80% relative humidity, noncondensing Nonoperating: 5% to 93% relative humidity, noncondensing |
| Altitude |
Operating: 3000 m (10,000 ft.) Nonoperating: 12,000 m (40,000 ft.) |
| Number of cords | 1 |
| 1 Maximum operating temperature is 35°C (95°F) when using tape media. | |
|
Regulations Meets or exceeds the following requirements: |
|
| Safety | UL 1950, CSA 950, TUV EN60950, CB Scheme (Nordic Deviation) |
| RFI/EMI | FCC Class A, DOC Class A, EN55022 Class A, VCCI Class 1 |
| Immunity | EN50082-1 |
| Harmonics | EN61000-3-2 |
| Dimensions and Weights | |
| Height | 64.5 cm (25.5 in.) 86 cm (34 in.) shipping |
| Width | 43.2 cm (17 in.) 74 cm (29 in.) shipping |
| Depth | 59.7 cm (23.5 in.) 57 cm (22.5 in.) shipping |
| Weight | 84 kg (185 lb.) approximate 100 kg (220 lb.) approximate shipping |
| Power Cord | 1.83 m (6 ft.) |
| Backplane/Centerplane | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 501-4799 | 5-Slot Centerplane | ||
| Boot PROM | ||
|---|---|---|
| Socket | Manufacturing Part # |
Patch |
| U3101 | 525-1387 | 103346 |
| CPU Module | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X2590A | 501-6620 | 464MHz UltraSPARC II Module (8MB Cache Blaze) Mirrored Data SRAM Mirrored Tag SRAM |
||
| 501-6623 | 464MHz UltraSPARC II Module (8MB Cache Blaze) Mirrored SRAM Mirrored Tag SRAM |
|||
| X2500A | 501-2941 | 167MHz UltraSPARC Module (512KB Cache Blackbird) |
||
| X2510A | 501-2959 | 167MHz UltraSPARC Module (1MB Cache Blackbird) |
||
| X2530A | 501-4178 | 250MHz UltraSPARC II Module (1MB Cache Blackbird) |
||
| X2550A | 501-4836 | 250MHz UltraSPARC II Module (4MB Cache Blackbird) SRAM 100-5528 |
||
| X2560A | 501-4363 | 336MHz UltraSPARC II Module (4MB Cache Sapphire-Black) |
||
| X2570A | 501-4995 | 400MHz UltraSPARC II (4MB Cache Sapphire-Black) |
||
| 501-5425 | 400MHz UltraSPARC II (4MB Cache Sapphire-Black) |
|||
| 501-5585 | 400MHz UltraSPARC II Module (4MB Cache Sapphire-Black) |
|||
| X2580A | 501-5235 | 400MHz UltraSPARC II Module (8MB Cache Sapphire-Black) |
||
| 501-5661 | 400MHz UltraSPARC II Module (8MB Cache Sapphire-Black) |
|||
| 501-5762 | 400MHz UltraSPARC II Module (8MB Cache Sapphire-Black) |
|||
| X2580A | 501-5838 | 400MHz UltraSPARC II Module (8MB Cache Sapphire-Black) Mirrored Data SRAM |
||
| 501-6008 | 400MHz UltraSPARC II Module (8MB Cache Sapphire-Black) Mirrored Data SRAM |
|||
| X2580A | 501-6624 | 400MHz UltraSPARC II Module (8MB Cache Blaze) Mirrored Data SRAM Mirrored Tag SRAM |
||
| Communication | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X1008A | 501-1931 | Serial Parallel Controller SBus (SPC/S) | ||
| X1012A | 501-2603 | SunLink ISDN | ||
| X1014A | 501-1932 | Token Ring Interface/SBus (TRI/S) | ||
| X1019A | 501-1725 | High Speed Serial Interface/SBus (HSI/S) | ||
| X1023A | 370-2715 | FDDI/S Single-Attach SBus (SAS) 4.0 | ||
| X1024A | 370-2716 | FDDI/S Dual-Attach SBus (DAS) 4.0 | ||
| X1025A | 370-2339 | FDDI/S Single-Attach SBus (SAS) 5.0 | ||
| X1026A | 370-2340 | FDDI/S Dual-Attach SBus (DAS) 5.0 | ||
| X1035A | 370-2811 | FDDI/P SAS Adapter PCI 1.0 | ||
| X1036A | 370-2812 | FDDI/P DAS Adapter PCI 1.0 | ||
| X1039A | 375-0001 | Token Ring Interface PCI (TRI/P) 1.0 | ||
| X1040A | 370-2728 | High Speed Serial Interface PCI (HSI/P) 1.0 | ||
| X1041A | 370-2810 | Serial Asynchronous Interface PCI (SAI/P) 1.0 | ||
| X1050A | 501-2523 | SunATM-155/MFiber SBus 1.0 | ||
| X1051A | 501-2665 | SunATM-155/UTP5 SBus 1.0 | ||
| X1060A | 501-2794 | SunATM-155/MFiber SBus 2.X | ||
| X1061A | 501-2795 | SunATM-155/UTP SBus 2.X | ||
| X1064A | 501-2864 | SunATM-622/MFiber SBus 2.X | ||
| X1066A | 501-3028 | SunATM-155/MFiber PCI 3.0 | ||
| X1067A | 501-3027 | SunATM-155/UTP PCI 3.0 | ||
| X1068A | 501-3029 | SunATM-622/MFiber PCI 3.0 | ||
| X1070A | 370-3878 | HIPPI/P 1.0 High Performance Interface Board | ||
| X1071A | 370-3878 | HIPPI/P 1.1 High Performance Interface Board | ||
| X1080A | 370-4273 | Enterprise System Interface (ESI/P) | ||
| X1133A | 375-0130 | Crypto Accelerator I | ||
| X1142A | 370-3142 | FDDI/S Single-Attach SBus (SAS) 5.0/6.0 | ||
| X1143A | 370-3143 | FDDI/S Dual-Attach SBus (DAS) 5.0/6.0 | ||
| X1144A | 501-1932 | Token Ring Interface/SBus (TRI/S) 4.0 | ||
| X1145A | 501-1725 | High Speed Serial Interface/SBus (HSI/S) 3.0 | ||
| X1146A | 501-1931 | Serial Parallel Controller SBus (SPC/S) 3.0 | ||
| X1147A | 501-2794 | SunATM-155/MFiber SBus 4.0 | ||
| X1148A | 501-2795 | SunATM-155/UTP SBus 4.0 | ||
| X1149A | 501-2864 | SunATM-622/MFiber SBus 4.0 | ||
| X1152A | 370-2811 | FDDI/P SAS Adapter PCI 2.0 | ||
| X1153A | 370-2812 | FDDI/P DAS Adapter PCI 2.0 | ||
| X1154A | 375-0001 | Token Ring Interface PCI (TRI/P) 4.0 | ||
| X1155A | 370-2728 | High Speed Serial Interface PCI (HSI/P) 2.0 | ||
| X1156A | 370-2810 | Serial Asynchronous Interface PCI (SAI/P) 2.0 | ||
| X1157A | 501-3028 | SunATM-155/MFiber PCI 4.0 | ||
| X1158A | 501-3027 | SunATM-155/UTP PCI 4.0 | ||
| X1159A | 501-3029 | SunATM-622/MFiber PCI 4.0 | ||
| X2144A | 501-1932 | Token Ring Interface/SBus (TRI/S) 5.0 | ||
| X2154A | 375-0073 | Token Ring Interface (TRI/P) 5.0 | ||
| X2156A | 375-0100 | Serial Asynchronous Interface PCI (SAI/P) 3.0 | ||
| Disks | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X6709A | 540-3852 | 9.1GB – 7200 RPM FC-AL, Disk Assembly with 1 bracket, 1 shield, 1 of the following plates, and 1 disk: | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| X6710A | 540-3869 | 9.1GB – 10000 RPM FC-AL, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks: | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| X6711A | 540-3923 | 18.2GB – 7200 RPM FC-AL, Disk Assembly with 1 bracket, 1 disk, and 1 of the following plates: | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| X6720A | 540-4191 | 18.2GB – 10000 RPM FC-AL, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks: | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| X6724A | 540-4525 | 36.4GB – 10000 RPM FC-AL, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks: | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| X6728A | 540-4673 | 18.2GB – 10000 RPM FC-AL, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks: | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| Ethernet | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X1033A | 501-5019 | Sun FastEthernet PCI Adapter (FE/P) 2.0 | ||
| X1034A | 501-5406 | Quad FastEthernet PCI (QFE/P) | ||
| X1042A | 501-4302 | Sun Quad FastEthernet SBus (SQFE/S) 1.0 | ||
| X1044A | 375-0002 | Gigabit Ethernet PCI (GBE/P) 1.0 | ||
| X1045A | 375-0003 | Gigabit Ethernet SBus (GBE/S) 1.0 | ||
| X1049A | 501-5443 | Sun Quad FastEthernet SBus (SQFE/S) 2.0 | ||
| X1056A | 501-2655 | SunFastEthernet 1.0 Adapter | ||
| X1058A | 501-2062 | SBus Quad Ethernet Controller (SQEC/S) | ||
| X1059A | 501-2919 | SunFastEthernet Adapter 2.0 (Colossus Lite) | ||
| X1140A | 501-4375 | Gigabit Ethernet SBus (GBE/S) 2.0 | ||
| X1141A | 501-4373 | Gigabit Ethernet PCI (GBE/P) 2.0 | ||
| X1150A | 501-5902 | Sun GigaSwift Ethernet UTP (Copper) | ||
| X1151A | 501-5524 | Sun GigaSwift Ethernet MMF (Fiber) | ||
| X3150A | 501-5902 | Sun GigaSwift Ethernet UTP (Copper) | ||
| X3151A | 501-5524 | Sun GigaSwift Ethernet MMF (Fiber) | ||
| X467A | 595-3780 | MII to AUI Converter | ||
| Fibre Channel | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X6731A | 370-2303 | FC-AL SW-GBIC Module | ||
| SG-XPCI1FC-QF2 | 375-3102 | 2Gb PCI Single FC Host Adapter | ||
| SG-XPCI1FC-QL2 | 375-3383 | 2Gb PCI-X Single FC Host Adapter, RoHS:Y | ||
| SG-XPCI2FC-QF2 | 375-3108 | 2Gb PCI Dual FC Host Adapter | ||
|
|
|||
| X1057A | 501-2069 | SBus Optical Channel Host Adapter (SOCHA) | ||
| X2652A | 501-4820 | FC-AL Interface Board Kit | ||
| 501-5144 | FC-AL Interface Board Kit | |||
| X595A | 370-1426 | Fibre Channel Optical Module (FC/OM) | ||
| X6727A | 375-3030 | PCI Dual FC Host Adapter+, RoHS:YL | ||
| X6730A | 540-2989 | FC-AL SBus Card (FC100/S) | ||
|
|
|||
| X6757A | 375-3048 | SBus Dual FC Network Adapter | ||
| X6767A | 375-3102 | 2Gb PCI Single FC Host Adapter | ||
| X6768A | 375-3108 | 2Gb PCI Dual FC Host Adapter | ||
|
|
|||
| X6799A | 375-3019 | PCI Single FC Host Adapter | ||
| Graphics | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X1085A | 501-3019 | SunVideo Board | ||
| X3653A | 501-4127 | Creator Series 1 (FFB) 24-Bit Frame Buffer | ||
| X3655A | 501-2955 | TurboGXplus 8-Bit Frame Buffer | ||
| X3657A | 501-4173 | Creator3D Series 2 (FFB2) 24-Bit Frame Buffer | ||
| X3667A | 540-3979 | Elite3D-m6 24-Bit Frame Buffer | ||
| X3668A | 370-3753 | PGX32 8/24-Bit Color Frame Buffer | ||
| X3671A | 501-4790 | Creator3D Series 3 (FFB2+) 24-Bit Frame Buffer | ||
| X3768A | 370-4362 | PGX64 8/24-Bit Color Frame Buffer | ||
| X7110A | 501-2922 | TurboGX 8-Bit Frame Buffer | ||
| I/O | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X2610A | 501-4287 | SBus I/O Board | ||
| X2611A | 501-4266 | SBus I/O Board with SOC+ | ||
| X2612A | 501-4883 | SBus I/O Board with SOC+ | ||
| X2620A | 501-4288 | Graphics I/O Board | ||
| X2622A | 501-4884 | Graphics I/O Board with SOC+ | ||
| X2630A | 501-4325 | PCI I/O Board | ||
| X2632A | 501-4926 | PCI I/O Board | ||
| n/a | 501-4128 | PCI I/O Riser Board (3.3V) | ||
| n/a | 501-4169 | PCI I/O Riser Board (5V) | ||
| IDPROM | |||
|---|---|---|---|
| Socket | Manufacturing Part # |
Component Type | Host ID |
| U0205 (Clock), U2501 (I/O) | 100-4007 | 48T59 NVRAM | 80xxxxxx |
| Input Device | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X485A | 370-1804 | Color Video Camera (to add to X1085A) | ||
| X487A | 595-3277 | SunVideo SBus Kit (X1085A + X485A) | ||
| X495A | 370-1414 | SunMicrophone | ||
| Memory | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X6738A | 375-0087 | 32MB SBus Fast Write Cache | ||
| X7021A | 64 MB (8 × 8MB DIMMs) | |||
| 501-2652 | 8MB DIMM | |||
| X7022A | 256 MB (8 × 32MB DIMMs) | |||
| 501-2653 | 32MB DIMM | |||
| X7023A | 1 GB (8 × 128MB DIMMs) | |||
| 501-2654 | 128MB DIMM | |||
| X7026A | 2 GB (8 × 256MB DIMMs) | |||
| 501-5658 | 256MB DIMM | |||
| n/a | 501-6901 | 256MB DIMM | ||
| n/a | 501-6902 | 256MB DIMM | ||
| Miscellaneous | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X1030A | 501-2367 | PCMCIA Interface/SBus Card | ||
| n/a | 595-4182 | E3x00 Floor Mount Brackets | ||
| Power | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X954A | 300-1444 | FDK PEX690-31 300 Watt Power/Cooling Module (Type A146) | ||
| X9689A | 300-1358 | FDK PEX750-30 195 Watt Peripheral Power Supply (Type A129) Front Unit | ||
| n/a | 300-1400 | FDK PEX705-40 184 Watt Peripheral Power Supply (Type A109) Rear Unit | ||
| Removable Media | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X6104A | 370-2202 | 2.5GB 1/4″ Tape Drive (Medium Grey Bezel) | ||
| X6213A | 370-2882 | 7-14GB 8 mm Tape Drive (Medium Grey Bezel) | ||
| X6238A | 370-2184 | 20-40GB 8 mm Tape Drive (Medium Grey Bezel) | ||
| X6259A | 370-2177 | 4-8GB 4 mm DDS-2 Tape Drive (Medium Grey Bezel) | ||
| X6283A | 370-2376 | 12-24GB 4 mm DDS-3 Tape Drive (Medium Grey Bezel) | ||
| X6296A | 390-0027 | 20-40GB 4 mm DDS-4 Tape Drive (Medium Grey Bezel) | ||
| n/a | 370-3416 | SunCD 32 CD-ROM | ||
| n/a | 390-0025 | 10X DVD-ROM Drive | ||
| SCSI | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X1018A | 501-2739 | Single-Ended Fast/Wide SCSI/FastEthernet (SunSwift/S) | ||
| X1032A | 501-5656 | Single-Ended Ultra/Wide SCSI/FastEthernet (SunSwift PCI) | ||
| X1052A | 501-1902 | Fast Differential SCSI-2/Buffered Ethernet (DSBE/S) | ||
| X1053A | 501-2981 | Fast SCSI-2/Buffered Ethernet (FSBE/S) | ||
| X1062A | 370-1704 | Differential Fast/Wide SCSI-2 Host Adapter (DWIS/S) | ||
| X1063A | 370-1703 | Single-Ended Fast/Wide SCSI-2 Host Adapter (SWIS/S) | ||
| X1065A | 370-2443 | Differential Ultra/Wide SCSI Host Adapter (UDWIS/S) (HVD) | ||
| Switch/Hub | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X6746A | Redundant FC 8-port Switch Option (two 8-port switches) | |||
| 540-4372 | StorEdge Network FC Switch-8 | |||
Industry Leading Quality, Support and Integrity
Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.
Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.
Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.
Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
